Input selection section

The Input Selection section allows to select
which input (#1 to #12) to display in a selected
layer. Select one of 12 simultaneous inputs, (8
analog inputs, 2 DVI-D inputs, 2 SDI inputs) by
simply pressing one of the Input buttons.
The [BLACK] button allows users to remove layer content on screen.

Freeze button

The [FREEZE] button of the
Main output current display or the active input, depending on the
freeze mode: FREEZE ALL or freeze the current selected input
INPUT FREEZE.

Audio-Video input 8

The handy front panel Audio-Video Input 8 lets users quickly access
an extra universal analog input source, without the hastle of re-
cabling the OPS300 rear panel, or for quick source changes during
a show or presentation.

T-Bar

The OPS300 T-Bar allows to switch from Preview to Main outputs
manually, and as gradually as you wish. By sliding the T-Bar, what
you have setup on your preview screen will go live on the Main
output display at the same speed as you slide it.

Effect selection button

OPS300
The [EFFECT]
layer.

Preset selection button

The OPS300 [PRESET]
recall a saved preset.
OPS300 allows users to freeze the
selection button is the shortcut to the current
selection button allows you to instantly
27
