Memorizing logos in the OPS300
1. In the Input Selection section, press the source button (#1 to #12) of the source you wish to record as a
logo. The source button will start blinking.
2. Select the Logos/Frames menu by scrolling through the menu with the scroll knob, then pressing the
[ENTER] button.
3. Select Record Logos in the Logos/Frames menu by rotating the scroll knob, then pressing [ENTER]. A
small white rectangle will appear on your main display, indicating the logo that will be captured.
4. Adjust logo size, position, and fine tune key attributes by rotating the scroll knob and pressing
to memorize logo settings.
5. Select an empty logo memory (empty logos are indicated in the sub-menu) to store the logo into. Press
the [ENTER] button. The
Logos setup menu
I
n the Logos/Frames menu, the logos can be deleted in the Erase menu:

Working with Logos

A Logo can be manipulated through the front panel. On the front panel, the logo# are associated to the input#
respectively. To assign a logo# to the logo layer:
Logos #1 to #6 are available directly by the input # button on the front panel. For logo #7 and #8, you have to
use shift button first:
Press [LOGO#1] Layer button → Press Shift button → Press Input#
You can change logos or delete logos on the preview screen using the same way the layers do:
Change: Press [LOGO(#1 or #2)] button → Press another Input#
Logos as Layer
Logos are under the Layer rules, you will have direct access to settings by pressing the Logo Layer button.
You have 2 logos layer buttons available.
You can use the Pos/Size/Zoom adjustment button and the
OPS300 will display a progress status bar on the VFD screen.
Logos/Frames menu → Erase menu → Select Logo#
Press [LOGO] Layer button → Press Input#
(For logo #7 or #8 use Shift then Input # button)
Clear: Press [LOGO (#1 or #2)] button → Press [BLACK]
[EFFECT] button from the front panel too.
[ENTER]
