LDC200C Series

5.1.4 LDC205C

Current Control (Constant Current Mode)
Control Range
Compliance Voltage
Resolution
Accuracy
Noise Without Ripple (10Hz to 10MHz, rms, typ.)
Ripple (50/60Hz, rms, typ.)
Transients (typ.)
Drift, 24hours
(typ., 0-10Hz, at constant ambient temperature)
Temperature Coefficient
Current Limit
Setting Range
Resolution
Accuracy
Power Control (Constant Power Mode)
Photo Current Control Range
Photo Current Resolution
Photo Current Accuracy
Analog Modulation Input
Input Resistance
Small Signal 3dB Bandwidth, CC Mode
Modulation Coefficient, CC Mode
Modulation Coefficient, CP Mode
Laser Current Monitor Output
Load Resistance
Transmission Coefficient
General data
Maximum Power Consumption
Weight
All technical data are valid at 23 ± 5°C and 45 ±15% humidity
28
0 to ±500 mA
>10 V
10 µA
±0.5 mA
< 3 µA
< 2 µA
< 0.5 mA
<10 µA
<50 ppm/°C
0 to >500 mA
10 µA
±1.5 mA
25 µA to 10 mA
1 µA
±10 µA
10 kW
DC to 150 kHz
50 mA/V ±5%
1 mA/V ±5%
>10 kW
20 V/A ±5%
30 VA
<3.1 kg
