Resetting:
The TRTD7 can be reset to factory defaults by pressing and holding + and
- simultaneously until the screen goes blank, and then shows all segments.
The time and date may need resetting.

Sleep Mode:

If power is removed for any reason, then the internal battery will preserve the
programming, and also the time / date. The screen will go blank ten seconds
after the power is turned off, to preserve the battery life. It can be woken up
by pressing the + or - button, or by reapplying mains power to the unit.

8. Specifications:

Manual Permissible loads:
Ingress protection:
Insulation:
6
Battery reserve:
Standards:
Compliant with:
Size:
Switch type:
9. Tariff Table:
ON
Economy 7
0 1.00am 5.00am
1 12.00am 6.00am
2 1.00am 6.00am
3 1.00am 7.00am
ECO 20:20
4 10.00pm 6.00am
ECONOMY 10
5 1.00am 6.00am 7.30pm 9.30pm
6 2.00am 7.00am 2.00pm 4.00pm 7.00pm 9.00pm 2.00am 7.00am 2.00pm 4.00pm 7.00pm 9.00pm
7 12.00am 5.00am 1.00pm 3.00pm 8.00pm 10.00pm 12.00am 5.00am 1.00pm 3.00pm 8.00pm 10.00pm
8 4.30am 7.30am 2.00pm 4.00pm 9.00pm 11.00pm 4.30am 7.30am 2.00pm 4.00pm 9.00pm 11.00pm
9 12.00am 7.00am 9.00pm 12.00am
13A, 230V, 50Hz, suitable for immersion
heaters up to 3kW.
IP30
Class 1
Two years.
BS EN 60730, 72-23-EEC, and 89-336-EEC
175 x 120 x 70mm.
Double pole rocker switch
WINTER
OFF ON OFF ON OFF ON OFF
2.00am 6.00am
1.00am 7.00am
2.00am 7.00am
2.00am 8.00am
11.00pm 7.00am
1.00am 6.00am 7.30pm 9.30pm
12.00am 7.00am 9.00pm 12.00am
SUMMER
ON OFF ON OFF
