Manual No: 577014-075
●
Revision: B
TLS-450PLUS Console

Troubleshooting Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TLS-450PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Veeder-Root TLS-450PLUS

Summary of Contents for Veeder-Root TLS-450PLUS

  • Page 1: Troubleshooting Guide

    Manual No: 577014-075 ● Revision: B TLS-450PLUS Console Troubleshooting Guide...
  • Page 2 Customer Service will work with production facility to have the replacement product shipped as soon as possible. If “lost” equipment is delivered at a later date and is not needed, Veeder-Root will allow a Return to Stock without a restocking fee.

  • Page 3: Table Of Contents

    Table of Contents 1 Introduction Related Manuals ......................1-1 Contractor Certification Requirements ................1-1 Safety Precautions ......................1-2 Safety Warnings ......................1-2 2 System Description System Parts Identification ....................2-1 About Screen .......................2-11 Console Power And Relay Wiring Inputs ..............2-11 Configuration DIP Switch Settings ................2-11 Basic Troubleshooting Procedures ................2-12 Intrinsic Safety Check ....................2-12 Visual Inspection of Console Interior ................2-13...
  • Page 4 Table of Contents 6 Console Troubleshooting Boot-Up LED Sequence ....................6-1 TLS-450PLUS Troubleshooting Guide ................6-2 7 Component Removal Safety Warnings ......................7-1 Precautions Against Static Electricity ................7-1 Before Turning Off Power ....................7-2 Removing The Ack Switch Panel/Display (Right) Door And CPU Board .......7-3 Removing The AC Input Filter And Power Supply Board ..........7-5...
  • Page 5 Figure 2-8. Comm Backplane Board ..............2-8 Figure 2-9. TLS-450PLUS Console - Selectable Comm Modules ......2-9 Figure 2-10. TLS-450PLUS Console - Fixed Comm Modules .........2-9 Figure 2-11. CPU Board ..................2-10 Figure 2-12. Configuration DIP Switch Settings .............2-11 Figure 7-1. USB Board - USB Ports ...............7-2...
  • Page 6 Figure 11-6. CSLD Moving Average Table Example ..........11-8 Tables Table 2-1. Selectable Comm Module Permissible Slots and Port Availability ..2-9 Table 2-2. TLS-450PLUS Wiring Inputs ...............2-11 Table 3-1. Power Supply/AC Input board fuses ............3-1 Table 3-2. I/O Module Fuses ...................3-1 Table 5-1.

  • Page 7: Introduction

    Related Manuals Troubleshooting of a TLS-450PLUS console requires knowledge of the system site prep and installation as well as setup and operation of all installed options. Refer to the Tech Docs CD-ROM (V-R P/N 331650-001) for all...

  • Page 8: Safety Precautions

    Introduction Safety Precautions • Wireless – ISD/PMC Wireless • A current Veeder-Root Technician Certification is a prerequisite for the VR Vapor Products course. Warranty Registrations may only be submitted by selected Distributors. Safety Precautions The following safety symbols may be used throughout this manual to alert you to important safety hazards and...

  • Page 9: System Description

    2 System Description System Parts Identification The following figures identify the components and printed circuit boards of the TLS-450PLUS console. T 2: DELIVERY NEEDED 1 Warning(s) 12/20/2012 06:01 PM 0 Alarms(s) Overview Tank Overview Print (0) TANK 1: reg Home...

  • Page 10: Figure 2-2. Printer Door Assembly

    System Description System Parts Identification Figure 2-2. Printer Door Assembly Legend For Figure 2-2 Item Description Item Description Paper roll release lever Connector for data input cable to USB1 on CPU board Printer assembly Paper cover Connector for power input cable to J1 on Power Supply board...

  • Page 11: Figure 2-3. Display Door Assembly

    System Description System Parts Identification Section A-A Figure 2-3. Display Door Assembly Legend For Figure 2-3 Item Description Item Description Touch screen display assembly Cable to Ack Switch Panel connector on CPU board (item 16 in Figure 2-11) Input Module Connection Labels Cable to LED Backlight connector on CPU board (item 11 in Figure 2-11) Cable to Data Display connector on CPU board (item 6...

  • Page 12: Figure 2-4. Console Board Locations (With Power Supply Protective Cover Removed)

    System Description System Parts Identification WARNING: TO MAINTAIN WARNING: TO MAINTAIN WARNING: TO MAINTAIN WARNING: TO MAINTAIN INTRINSIC SAFETY, ALL INTRINSIC SAFETY, ALL INTRINSIC SAFETY, ALL INTRINSIC SAFETY, ALL COVERS MUST BE IN COVERS MUST BE IN COVERS MUST BE IN COVERS MUST BE IN PLACE.

  • Page 13: Figure 2-5. Ac Input Board

    System Description System Parts Identification Figure 2-5. AC Input Board Legend For Figure 2-5 Item Description Item Description Console AC Input plugs into J2 on Relay output fuse, 2A 250V Slo-Blo Power Supply board Output relay control plugs into J3 on AC Input board plugs into Power Sup- Power Supply board ply board as shown...

  • Page 14: Figure 2-6. Power Supply Board

    System Description System Parts Identification Figure 2-6. Power Supply Board Legend For Figure 2-6 Item Description Item Description Low voltage relay control connector Printer power supply fuse, 3A Slo-Blo (Relay connector on AC input board connects here) AC Input power connector (Line AC Console power supply fuse, 3A Slo- input connector on AC input board connects here)

  • Page 15: Figure 2-7. I/O Backplane Board

    System Description System Parts Identification TO COMM I/O BACKPLANE TO EXPANSION SPARE SPARE EXT_ EXT_RESET RESET 332616-002 SCREW SNAP SCREW +24V +24V +24V +24V 332616-001 I/O BACKPLANE EXT_RESET +24V SLOT 3 SLOT 1 SLOT 2 SLOT 4 SNAP SNAP SNAP G G B B F F JJL012907 consoles\450\918-7.eps...

  • Page 16: Figure 2-8. Comm Backplane Board

    System Description System Parts Identification J2 J2 NO COMPONENTS OR TRACES ABOVE THIS LINE BD Group - Comm.Backplane board TLS-450 console 332881-001 Rev A VRBUS_RST VRBUS- SLOT 1 SLOT 2 SLOT 3 SLOT 5 VRBUS+ SLOT 4 +24V +24V 30 30 29 29 30 30 29 29...

  • Page 17: Figure 2-9. Tls-450Plus Console - Selectable Comm Modules

    1 2 3 Bottom of console Selectable Comm Fixed Comm Device slots Device slots Figure 2-9. TLS-450PLUS Console - Selectable Comm Modules Table 2-1. Selectable Comm Module Permissible Slots and Port Availability Slot 1 Slot 2 Slot 3 Port Port...

  • Page 18: Figure 2-11. Cpu Board

    System Description System Parts Identification Figure 2-11. CPU Board LEGEND Item Description Item Description Console beeper SD Card (in metal enclosure) Battery isolator strip - to be removed prior to LED Backlight cable connector (optional dis- startup play) USB Type A connectors (2) Features iButton Ethernet (RJ-45) connectors (3) Backup Battery...

  • Page 19: About Screen

    The About Screen displays the console's software version and information on installed features. From the Home screen touch Menu>Overview>About to view the About screen. Console Power And Relay Wiring Inputs Table 2-2 below details TLS-450PLUS power and relay wiring connections and requirements. Table 2-2. TLS-450PLUS Wiring Inputs Connector...

  • Page 20: Basic Troubleshooting Procedures

    Basic Troubleshooting Procedures Basic Troubleshooting Procedures To ensure proper and safe troubleshooting and repair procedures for the TLS-450PLUS consoles, the following steps should be taken in the order they appear, prior to servicing the system: 1. Review and thoroughly understand the “Safety Warnings” on page 1-2 of this manual.

  • Page 21: Visual Inspection Of Console Interior

    4. Verify that power conduit and sensor and probe conduits enter TLS console only through preformed, designated knock-outs. 5. Verify that probe and sensor wiring and conduit meet Veeder-Root requirements (ref. manual P/N 577014-073). 6. If the system fails the intrinsic safety check, disconnect and cap the AC wires in the monitor, and disconnect and cap all probe and sensor field wires in the probe and sensor junction boxes.

  • Page 22: Fuses

    3 Fuses The TLS-450PLUS console uses replaceable fuses on several boards and modules. Under no circumstances substitute a different rating or fuse type during service. Power Supply Fuses Table 3-1. Power Supply/AC Input board fuses Fuse Circuit Fuse Location Fuse Size/Type V-R Part No.

  • Page 23: Diagnostics

    From the Home Screen, touch Menu>Diagnostics to access the Diagnostics Main screen. To access specific diagnostic information for the TLS-450PLUS, touch the desired diagnostic button. An overview of each diagnostic component is discussed in the paragraphs below.

  • Page 24: Available Line Pressure Sensor Diagnostic Reports

    Diagnostics Mag Sensor AVAILABLE LINE PRESSURE SENSOR DIAGNOSTIC REPORTS • General (general diagnostic information) • Communication (communication diagnostic information) • Constants (constants diagnostic information) • Channel (channel data) Mag Sensor The Mag Sensor diagnostics contain reports on the activity and condition of Mag Sensors. AVAILABLE MAG SENSOR DIAGNOSTIC REPORTS •...

  • Page 25: Available Diagnostic Screens

    Diagnostics PLLD AVAILABLE DIAGNOSTIC SCREENS • Comm - This screen contains a report of data transmission and reception results for installed communication modules. • Device Assignments - This screens contains modules, their connected devices and the device's primary and secondary assignments. •...

  • Page 26: Relays And Inputs

    Diagnostics Relays and Inputs Relays and Inputs The Relays and Inputs diagnostics contain information/diagnostics about relays and inputs. AVAILABLE DIAGNOSTIC SCREENS • External Inputs- View diagnostic information on external Inputs. • Relays - Test all configured relays (except PLLD relays). Two types of relay tests are available: - Sequential Test - This test sets selected relays to INACTIVE for two seconds and then sets them to ACTIVE for two seconds.

  • Page 27: Available Tank Test Diagnostic Reports

    Diagnostics Tank Test AVAILABLE TANK TEST DIAGNOSTIC REPORTS • CSLD Monthly Report (CSLD state changes) • CSLD Rate Table Report (CSLD rate table) • CSLD Rate Test Report (CSLD rate test results) • CSLD Test Status Report (current CSLD test status) •...

  • Page 28: Warning And Alarm Messages

    5 Warning and Alarm Messages The TLS-450PLUS console constantly monitors the entire system for warning and alarm conditions including fuel leaks, inventory limit excesses, and equipment problems. When an alarm occurs, a message displays the device identifier followed by the alarm label.

  • Page 29: Displayed Alarm Messages

    Warning and Alarm Messages Displayed Alarm Messages Short Device Long Device Device Type Identifier Identifier Full Device Identifier Relay Relay Relay Siphon Set Siphon Siphon Set Tank Tank Tank Type A (2-Wire CL) Sensor Type A Type A Sensor Type B (3-Wire CL) Sensor Type B Type B Sensor Vacuum Sensor...

  • Page 30: Table 5-2. Tank Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-2. Tank Alarms Alarm Cause Action Insufficient data collection rate - More dispensing needs to occur. Warning will be posted on days that record fewer than 8 transactions. Noisy data - Verify Meter Map. Warning will be posted after a calibra- tion is generated, and the RMS Error of the data exceeds a maximum...
  • Page 31 Warning and Alarm Messages Displayed Alarm Messages Table 5-2. Tank Alarms Alarm Cause Action Fuel Quality Alarm Water/phase separation may be pres- Test fuel at bottom of tank to ensure ent in tank. water/phase separation is not present. Gross Leak Test Fail Alarm In-tank leak (3.0 gph [11.3 lph]) test Rerun in-tank leak test.

  • Page 32: Table 5-3. Liquid Sensor Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-2. Tank Alarms Alarm Cause Action Siphon Break Active Warning Siphon break valve has shut down Clears when tank test completes. manifold for tank test. Sudden Loss Alarm System detects loss of fuel during an Check for gross leak.

  • Page 33: Table 5-4. Vapor Sensor Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-4. Vapor Sensor Alarms Alarm Cause Action Fuel Alarm Fuel is present in the area being mon- Call for service following the proce- itored by the sensor. dures established for your site. Out Alarm The sensor setup was performed Call for service following the proce-...

  • Page 34: Table 5-7. Type A Sensor Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-6. Groundwater Sensor Alarms Alarm Cause Action Short Alarm A short has occurred in the sensor Call for service following the proce- wiring or in the sensor. dures established for your site. Water Out Alarm Water level is below the float switch Call for service following the proce-...

  • Page 35: Table 5-9. Relay Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-9. Relay Alarms Alarm Cause Action Out Alarm Console has lost communication with Call for service following the proce- the relay. dures established for your site. Setup Data Warning Device setup data problem. Recheck device setup parameters.

  • Page 36: Table 5-11. Mag Sensor Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-10. Pressure Line Leak Alarms Alarm Cause Action Shutdown Alarm System shut down line because of failed Identify offending alarm, and refer to PLLD line leak test, or an alarm assigned to dis- alarms for corrective action.

  • Page 37: Table 5-12. Line Pressure Sensor Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-12. Line Pressure Sensor Alarms Alarm Cause Action Communication Alarm Console has lost communication with the relay. Call for service following the proce- dures established for your site. Setup Data Warning Device setup data problem. Recheck device setup parameters.

  • Page 38: Table 5-17. Contact Alarms

    Warning and Alarm Messages Displayed Alarm Messages Table 5-17. Contact Alarms Alarm Cause Action Autodial Failed Alarm System failed to connect to a remote Verify the address book settings for the con- receiver after ‘n’ tries. tact are correct (i.e., modem device number, phone number to dial), verify the receiving device (fax or modem) is operational.

  • Page 39: Console Troubleshooting

    6 Console Troubleshooting Boot-Up LED Sequence A normal TLS-450PLUS boot-up sequence can be followed observing the front panel status LEDs as described in Table 6-1. Table 6-1. Front Panel LED Normal Boot-Up Sequence Boot-Up Sequence Visual Sequence System Task 1. Console powered On at the breaker.

  • Page 40: Tls-450Plus Troubleshooting Guide

    TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action Wrong paper type - not thermal Replace with thermal paper roll (Veeder-Root Part Blank printout from integral printer paper. No. 514100-328). Printer paper in backwards. Install paper properly. Swing down the printer cover (1) and push the paper feed release lever (2) down.
  • Page 41 Printer Error Alarm - Printer Traction Raise printer traction lever to up position. feed paper lever in down position. Printer out of paper. Load thermal paper (Veeder-Root Part No. 514100- 328). Loose printer cable. Check connections between printer and CPU board. Defective printer.
  • Page 42 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action Boot Sequence Boot device jumper(s) in wrong Verify jumper positions. Stalled position(s). For SD card: on J1203, off J1201 and J1202. For SATA drive: on J1201 and J1202, off J1203.
  • Page 43 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action Display Dark After Bad Display cable, loose Display 1. Open the printer door. Boot-Up cable. 2. Verify the Display ribbon cable (Item 3 in Figure 2- 3 on page 2-3) is securely seated in its CPU board connector and that the locking latch (1 pointer) is down against the cable.
  • Page 44 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action RS-485 Communica- Serial settings are incorrect for data Verify serial communication settings to make sure tion Not Working transfer such as Baud Rate, Parity settings are correct for data transfer.
  • Page 45 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action IFSF Communication Node ID Setting Incorrect Get the correct Node ID setting from the site’s LON Not Working - (cont’d.) administrator and verify that the correct Node ID has been entered: 1.
  • Page 46 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action IFSF Communication Bad cable connecting ATG to LON Verify the external input plug is pushed all the way Not Working - (cont’d.) network into the connector on the IFSF module. Verify if wires are loose or broken.
  • Page 47 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action No Connection To Cable is plugged into the wrong Verify Ethernet cables are plugged into correct Ethernet Port port. port(s) on the bottom of the console (ref. Slot 4 in Figure 2-10 on page 2-9 ).
  • Page 48 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action USB communication Cable(s) not properly plugged into Verify cables are plugged into moduled properly (ref. not working port on USB module. Slot 5 in Figure 2-10). Cable(s) not properly plugged into Open Printer door.
  • Page 49 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action Incorrect Time Dis- Battery Isolator strip not removed. Remove and discard the battery isolator strip (see played After Console Item 2 in Figure 2-11 on page 2-10).
  • Page 50 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action Sensor Connected To Sensor wires were connected while Re-boot console. TLS-450PLUS But No the console was ON. Sensor Address Under Devices Menu Sensor wiring installed incorrectly. 1. Open the Display door.
  • Page 51 Console Troubleshooting TLS-450PLUS Troubleshooting Guide Table 6-2. TLS-450PLUS Troubleshooting Symptom Cause Corrective Action "Could Not Validate Features iButton is not seated prop- Check that iButton (Item 12 in Figure 2-11 on IButton” Displays On erly in its holder. page 2-10) on the CPU board is installed correctly...
  • Page 52 Verify relay is enabled in the GUI. State enabled. Are relays setup on TLS-450PLUS? Connector is not pushed all the way Verify the relay plug is pushed all the way into the connector (Item 4 in Figure 2-5 on page 2-5). Verify each of the wires is correctly seated in the plug’s ter-...

  • Page 53: Component Removal

    7 Component Removal This sections contains instructions for removing/replacing the TLS-450PLUS console Ack Switch/Display door, CPU board, AC Input Filter, Power Supply board, Printer door, SD card, Features iButton, Backup Battery, and the SATA drive. Safety Warnings WARNING This console contains high voltages which can be lethal. It is also connected to low power devices that must be kept intrinsically safe.

  • Page 54: Before Turning Off Power

    2. From the Home Screen touch Menu > Software Upgrade > DB Backup to view the Database Backup Screen (see Figure 7-2). Touch the down arrow in the Backup Destination field to select the Backup thumb drive inserted in Step 1, then follow the on-screen instructions to backup TLS-450PLUS console data. System Status...

  • Page 55: Removing The Ack Switch Panel/Display (Right) Door And Cpu Board

    Component Removal Removing The Ack Switch Panel/Display (Right) Door And CPU Board Removing The Ack Switch Panel/Display (Right) Door And CPU Board To remove just the Acknowledge Switch Panel door (or optional Display door), complete Steps 1 - 6 in this section.

  • Page 56: Figure 7-4. Remove Ground Wire From Ack Switch/Display Door

    Removing The Ack Switch Panel/Display (Right) Door And CPU Board Figure 7-4. Remove Ground Wire From Ack Switch/Display Door 5. Remove the TLS-450PLUS Ack Switch Panel/Display door by removing the top and bottom hinge shoulder screws (see Figure 7-5). Figure 7-5. Remove Top And Bottom Optional Display Door Hinge Screws 6.

  • Page 57: Removing The Ac Input Filter And Power Supply Board

    Component Removal Removing The AC Input Filter And Power Supply Board Figure 7-6. Remove USB Module Cables From CPU Board 7. Remove the three Ethernet Module cables E2 (blue), E1 (yellow) and E0 (red) from the CPU board (see Figure 7-7). Figure 7-7.

  • Page 58: Figure 7-8. Remove Ac Channel Cover

    Component Removal Removing The AC Input Filter And Power Supply Board 956-8.eps Figure 7-8. Remove AC Channel Cover Legend For Figure 7-8 Item Description Item Description AC Channel cover. T15 screws (2). 4. Remove the three T15 screws in the AC Input Filter (item 1 in Figure 7-9). 5.

  • Page 59: Figure 7-9. Removing Ac Input Filter

    Component Removal Removing The AC Input Filter And Power Supply Board 956-5.eps Figure 7-9. Removing AC Input Filter Legend For Figure 7-9 Item Description Item Description T15 screws (the middle one secures the Power AC Input Filter handle Supply shield to the AC Input Filter bracket) Power Supply shield 7.

  • Page 60: Figure 7-10. Removing Power Supply Board

    Component Removal Removing The AC Input Filter And Power Supply Board 10.Lift the board out of the console by its edges since there is still undischarged high voltage in the item 3 capacitors. Figure 7-10. Removing Power Supply Board Legend For Figure 7-10 Item Description Item...

  • Page 61: Removing The Printer/Blank (Left) Door

    Component Removal Removing The Printer/Blank (Left) Door 15.Notice that there are two male connectors on the bottom of the AC Input Filter board that plug into two female connectors on the Power Supply board. With the handle (item 3 of Figure 7-9) of the AC Input Filter against the left side of the console housing, line up the two AC Input Filter bottom connectors over the two female connectors (items 4 and 5 in Figure 7-10) on the Power Supply board and push down on the AC Input Filter until the connectors are firmly seated.

  • Page 62: Removing The Backup Battery

    Figure 7-13). Figure 7-13. Removing Printer Door Ground Wire 6. Remove the TLS-450PLUS Printer door by removing the top and bottom hinge shoulder T15 screws (similar to the Ack Switch Panel/Display Door shoulder screws Figure 7-5). Removing The Backup Battery 1.

  • Page 63: Removing The Features Ibutton

    Component Removal Removing The Features iButton Figure 7-14. Locating Features iButton And Backup Battery Legend For Figure 7-14 Item Description Item Description Features iButton Backup Battery 4. Remove the battery by gently lifting the retaining clip over the battery as you slide it down out of its holder. Reinstall the battery with the ‘+’...

  • Page 64: Removing The Sd Card

    Component Removal Removing The SD Card 4. Holding the CPU board by its edges, place it on a clean surface. Locate the Features iButton at the top of the CPU board (see pointer 1 in Figure 7-14). 5. Remove the iButton by gently lifting the retaining clip over the iButton as you slide it out of its holder. 6.

  • Page 65: Removing The Sata Drive

    Component Removal Removing The SATA Drive Removing The SATA Drive 1. Perform all of the Steps in the section entitled “Before Turning Off Power” on page 7-2. 2. Open the console doors as described in Step 1 of the section entitled “Removing The Ack Switch Panel/ Display (Right) Door And CPU Board”...

  • Page 66: Console Diagnostics Using The Tlstech Diagnostic Tool

    TLS-450PLUS. Reconfigure the Laptop PC Prior To Using TLSTECH Prior to connecting to the TLS-450PLUS using the TLSTECH Diagnostic Tool, the IP address of the Laptop/PC has to be reconfigured. LAPTOP/PC SETUP FOR A WINDOWS 7 OPERATING SYSTEM...
  • Page 67 Console Diagnostics Using The TLSTECH Diagnostic Tool Reconfigure the Laptop PC Prior To Using TLSTECH 2. The Local Area Connection Status dialog box opens. Click on the Properties button.  ...
  • Page 68 Console Diagnostics Using The TLSTECH Diagnostic Tool Reconfigure the Laptop PC Prior To Using TLSTECH 3. In the Local Area Connection Properties dialog box ‘highlight Internet Protocol Version 4 (TCP/IPv6)’ and then click the Properties button.   4. In the ‘Internet Protocol Version 4 (TCP/IPv4) Properties’ dialog box, Check the Use the following IP address box and enter the Static IP address shown in the figure (this is the IP address for the Laptop/PC).

  • Page 69: Laptop/Pc Setup For A Windows Xp Operating System

    8. Your Laptop/PC is ready to TLSTECH to the TLS-450PLUS console. 9. When you have finished communicating with the TLS-450PLUS console, you will have to reconfigure the laptop/PC to its original TCP/IP settings. Repeat steps 1-4 above. When the ‘Internet Protocol Version 4 (TCP/IPv4) Properties’...
  • Page 70 3. When the ‘Internet Protocol (TCP/IP) Properties’ dialog box appears, select ‘Use the following IP address’ radio button and enter the Static IP address below (this is the default IP address for the TLS-450PLUS console). Once the IP address is entered, click in the Subnet mask field; the Subnet mask address will fill in automatically, if not enter 255.255.255.0.

  • Page 71: Using Putty And The Tlstech Diagnostic Tool

    3. Make the selections on the Putty Configuration dialog box as shown below and ignore the Category field selections. In the ‘Host Name for IP Address’ field, enter the IP address of the TLS-450PLUS console (169.254.21.12). Click the Open button to save settings and open the TLSTECH login screen.
  • Page 72 Console Diagnostics Using The TLSTECH Diagnostic Tool Using Putty And The TLSTECH Diagnostic Tool 4. When the login screen appears, login as tlstech: 5. Enter the password: tlstech...

  • Page 73: Tlstech Menu Examples

    Console Diagnostics Using The TLSTECH Diagnostic Tool TLSTECH Menu Examples 6. When the TLSTECH menu appears, enter the number of a desired choice then press Enter to view that result. To exit the program, press 0 then press Enter. TLSTECH Menu Examples The TLSTECH menu is shown below and examples of each menu item are shown below.

  • Page 74: Menu Selection 1

    MaintServer 1686 root httpd 21676 daemon \_ httpd 29299 daemon \_ httpd 26014 daemon \_ httpd MENU SELECTION 4 Display system statistics Linux 2.6.35.3-433-g0fae922+ (TLS-450PLUS) 08/08/13 _armv7l_ (1 CPU) 08/08/13 09:35:26 avg-cpu: %user %nice %system %iowait %steal %idle 13.75 0.00...

  • Page 75: Menu Selection 5

    Console Diagnostics Using The TLSTECH Diagnostic Tool TLSTECH Menu Examples MENU SELECTION 5 Displaying network settings Kernel Interface table eth0 Link encap:Ethernet HWaddr 00:50:83:f0:04:99 inet addr:10.2.1.71 Bcast:10.2.1.255 Mask:255.255.255.0 inet6 addr: fe80::250:83ff:fef0:499/64 Scope:Link UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1 RX packets:1833262 errors:0 dropped:0 overruns:0 frame:0 TX packets:440681 errors:0 dropped:0 overruns:0 carrier:0 collisions:0 txqueuelen:1000 RX bytes:142122262 (135.5 MiB) TX bytes:357490031 (340.9 MiB)

  • Page 76: Menu Selection 8

    Console Diagnostics Using The TLSTECH Diagnostic Tool TLSTECH Menu Examples Pinging gateway PING 10.20.95.1 (10.20.95.1): 56 data bytes 64 bytes from 10.20.95.1: icmp_seq=0 ttl=255 time=0.760 ms 64 bytes from 10.20.95.1: icmp_seq=1 ttl=255 time=1.114 ms 64 bytes from 10.20.95.1: icmp_seq=2 ttl=255 time=0.606 ms --- 10.20.95.1 ping statistics --- 3 packets transmitted, 3 packets received, 0% packet loss round-trip min/avg/max/stddev = 0.606/0.827/1.114/0.213 ms...

  • Page 77: Menu Selection 9

    Console Diagnostics Using The TLSTECH Diagnostic Tool TLSTECH Menu Examples Authoritative answers can be found from: mail.global.frontbridge.com internet address = 216.32.180.190 mail.global.frontbridge.com internet address = 216.32.181.178 mail.global.frontbridge.com internet address = 65.55.88.22 mail.global.frontbridge.com internet address = 207.46.163.30 mail.global.frontbridge.com internet address = 213.199.154.190 mail.global.frontbridge.com internet address = 213.199.154.254 mail.global.frontbridge.com...
  • Page 78 Console Diagnostics Using The TLSTECH Diagnostic Tool TLSTECH Menu Examples |-mmcblk0p1 1.9G / `-mmcblk0p2 1.9G Disk usage: Filesystem Type Size Used Avail Use% Mounted on rootfs rootfs 1.9G 1013M 742M /dev/root ext3 1.9G 1013M 742M tmpfs tmpfs 4.0K /dev tmpfs tmpfs 247M 228K...

  • Page 79: Probe Troubleshooting

    This section contains basic probe problem diagnosis and suggested corrected actions for troubleshooting Magnetostrictive Probes (Table 9-1). Refer to TLS-450PLUS Site Prep and Installation Manual (Veeder-Root No. 577014-073) and the appropriate probe installation manual for more information about probe, conduit, and wiring installation.
  • Page 80 Probe Troubleshooting Table 9-1. Mag Probe Troubleshooting Alarm Problem Probable Cause Corrective Procedure Fuel level reading equals Fuel float stuck in riser. Remove float from riser and install full tank volume even split-ring collar (P/N 576008-617) on though fuel level is below probe shaft below riser tube to pre- full volume.

  • Page 81: Field Troubleshooting Probe-Out Alarms

    1.00 KG/M (0.062 LBS/FT NOTE 1. Refer to TLS-450PLUS Site Prep and Installation Manual (Veeder-Root No. 577014-073). Field Troubleshooting Probe-Out Alarms You must verify all locations utilizing shielded cable are wired correctly. Turn off, tag, and lockout power to the console before opening display door assembly! Verify that the drain wire of the shielded cable is connected to the console end only.
  • Page 82 4. The Probe distance from the console must be less than 1000 feet. If the distance is greater than this probe operation is not guaranteed. 5. Ensure the probe wiring conforms to the requirements detailed in the TLS-450PLUS Site Prep and Installation Manual (Veeder-Root No. 577014-073).

  • Page 83: Minimum Detected Fluid Levels

    Probe Troubleshooting Minimum Detected Fluid Levels 13. Measure the resistance of the probe wiring from the probe end of the cable to its connections at the console. First disconnect the cable from the console and twist the two ends together. Then remove the connector from the probe canister.

  • Page 84: Mag Probe Channel Counts In Common Liquids

    Probe Troubleshooting Mag Probe Channel Counts in Common Liquids Table 9-2. Mag Probe Minimum Detected Fluid Levels 4” Ethanol- Blended Gasoline Floats 4” Floats 3” Floats 2” Floats Name Min. Min. Min. Min. Min. Min. Min. Min. Circuit Mag Probe Leak Plate Water...

  • Page 85: 10 Sensor Troubleshooting

    10 Sensor Troubleshooting This section contains suggested corrective actions for troubleshooting sensor problems. Turn off, tag, and lockout power to the console before opening display door assembly! Sensor Alarm Will Not Clear Liquid or fuel in containment area. Sensor Out Alarms Follow these steps in sequence to troubleshoot Sensor Out alarms.

  • Page 86: Cleaning Fuel Contaminated Discriminating Sensors

    Sensor Troubleshooting Cleaning Fuel Contaminated Discriminating Sensors 3. Damaged wiring insulation exposing bare conductors to moisture in the conduit. This condition may also appear as readings showing lower than normal or the same reading, regardless of the state of the sensor. 4.

  • Page 87: 11 Csld Troubleshooting

    11 CSLD Troubleshooting CSLD collects information during each idle time to form a highly accurate leak detection database. Since the database is being constantly updated, leak test results are always current. Periodic leak tests are performed using the best data from up to the previous 28 days, and test results are continuously updated as new data is gathered. Invalid data is discarded and only the best data is used to ensure accurate leak test results and fewer false alarms.
  • Page 88 CSLD Troubleshooting CSLD Block Diagrams CSLD Start TLS SAMPLE READY ? IDLE = Evaluate Activity() IDLE = TRUE Test In Progress Start Test Test In Progress End Test Test Duration Store TLS Sample >3 Hours Evaluate Test Test Acceptable Evaluate Add Test to Report Results Rate Table...
  • Page 89 CSLD Troubleshooting CSLD Block Diagrams Test Events Test Event Timing SCHEDULE TEST Start Tank goes idle and must remain so for 8 minutes. Idle is determined by: Tank idle 1) analysis of a group of probe samples 8 minutes? from the 30 second average table, and 2) checking the pump sense module (if available).

  • Page 90: Csld Diagnostic Aids

    CSLD Troubleshooting CSLD Diagnostic Aids CSLD Diagnostic Aids Due to the complexity of CSLD, most information required to troubleshoot the product is accessible only using RS-232 commands via direct or modem connection. If you do not have a computer or data terminal to collect this data you will not be able to resolve CSLD alarms.
  • Page 91 CSLD Troubleshooting CSLD Diagnostic Aids IA5100 MAR 14, 1996 8:12 AM CSLD DIAGNOSTICS: RATE TABLE T 1:SUPER TIME ST LRT AVTMP TPTMP BDTMP TMRT DSPNS VOL INTVL DEL ULLG EVAP 9602202227 0 -0.016 39.2 38.3 36.3 0.02 4281 174.5 0.000 9602210128 0.016 39.3...
  • Page 92 CSLD Troubleshooting CSLD Diagnostic Aids IA5200 MAR 14, 1996 8:12 AM CSLD DIAGNOSTICS: RATE TEST DATE LRATE INTVL ST AVLRTE C3 FDBK ACPT THPUT EVAP 9603140346 -0.031 33.7 0.002 3525 15 38.3 28.9 31.63 0.000 9603140342 0.000 32.2 0.004 3184 15 38.3 28.9 29.85 0.000 9603140151...
  • Page 93 CSLD Troubleshooting CSLD Diagnostic Aids I A 5 3 0 0 M A R 1 4 , 1 9 9 6 8 : 1 4 A M C S L D D I A G N O S T I C S : V O L U M E T A B L E T 1 : S U P E R L A S T H O U R = 2 2 9 6 6 4 Most recent...

  • Page 94: Tank Setup Check Before Troubleshooting

    CSLD Troubleshooting Tank Setup Check Before Troubleshooting IA5402 MAR 12, 1996 10:52 AM CSLD DIAGNOSTICS: MOVING AVERAGE TABLE T 2:SUPER TIME SMPLS TCVOL HEIGHT AVGTEMP TOPTEMP BDTEMP 960312103008 2118.16 29.547 45.52 44.01 39.31 960312103038 2118.16 29.547 45.52 44.01 39.31 SMPLS = Samples 960312103108 2118.14 29.547...

  • Page 95: Alarm: Csld Rate Incr Warn

    CSLD Troubleshooting CSLD Alarms ALARM: CSLD RATE INCR WARN A CSLD Rate Increase Warning indicates fluid is entering the tank during the leak test. This warning indicates a higher than acceptable positive increase in product calculated from the CSLD Rate Table. The threshold amounts are listed below.

  • Page 96: Alarm: No Csld Idle Time

    2. Very high activity. Tank capacity or throughput specifications are exceeding CSLD specifications. 3. Line leak detection is running the product pump during normally idle periods.Veeder-Root line leak equipment is designed to coordinate line testing and CSLD to prevent this disturbance however in some cases conflicts may arise.

  • Page 97: Alarm: Periodic Leak Test Fail

    CSLD Troubleshooting CSLD Alarms ALARM: PERIODIC LEAK TEST FAIL This message is posted when CSLD data indicates a high probability that a tank is leaking. The threshold for this determination is shown below, Single Tanks: PD - 95% = -0.17 gph PD - 99% = -0.16 gph Manifolded Tanks: PD - 95% = -0.16 gph...

  • Page 98: Static Leak Test

    CSLD Troubleshooting Static Leak Test 4. Defective probe. 5. Not enough idle time (see message above). 6. Tests are being rejected because the test results indicate a rate increase >+0.4 gph. Static Leak Test If after troubleshooting the Periodic Leak Test Fail Alarm an equipment problem has not been identified, perform a static leak test.

  • Page 99: Contacting Tech Support

    CSLD Troubleshooting Contacting Tech Support Contacting Tech Support If the CSLD problem cannot be resolved, retrieve the following data via the RS-232 port or SiteFax modem and contact Technical Support: 1. <Control-A> IA5100 CSLD RATE TABLE 2. <Control-A> IA5200 CSLD RATE TEST 3.

  • Page 100: Actual Csld Test Problems Analyzed

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed Actual CSLD Test Problems Analyzed CSLD PROBLEM 1 - TANK 1 CSLD FAIL Report I25101 confirmed the failure. Reports IA5201, and IA5100 were then collected for analysis. I25101 CSLD TEST RESULTS TANK PRODUCT RESULT SUPER PER: JUL 26, 1996 FAIL...
  • Page 101 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 9607081825 0 -0.356 72.7 75.1 89.4 0.07 6024 146.0 0 0.000 9607082126 0 -0.306 72.9 76.1 89.7 0.06 6023 145.5 12.0 0 0.000 9607090027 0 -0.296 73.1 76.7 89.8 0.05 6022 145.0 15.0 0 0.000 9607090329 0 -0.359 73.2...

  • Page 102: Analysis Of Rate Table (Ia51)

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed ANALYSIS OF RATE TABLE (IA51) Looking in the leak rate column (LRT) the test results start off looking reasonable, if anything they tend to be positive. Leak rates suddenly change on the 8th and are consistently negative. There is another transition on the 13th where the leak rates return to the pattern observed prior to the 8th - slightly positive.

  • Page 103: Analysis Of Rate Test (Ia52)

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed ANALYSIS OF RATE TEST (IA52) The average leak rate (AVLRTE) is -0.259. The average leak rate is uncompensated so excessive compensation is not an issue. This leak rate is not excessively high so blender/pump sense issues are probably not involved. The tank label is SUPER so most likely it is not manifolded.
  • Page 104 CSLD Troubleshooting Actual CSLD Test Problems Analyzed I510 AUG 22, 1996 11:58 AM CSLD DIAGNOSTICS: RATE TABLE Large and inconsistent negative leak rates. T1: REGULAR TIME ST AVTMP TPTMP BDTMP TMRT DISPNS INTVL ULLG EVAP 9607250359 1 -0.802 72.3 73.7 76.0 -0.09 5214...

  • Page 105: Csld Problem 3 - Increase Rate Warning For Manifolded Tanks 2 And 3

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed 9608180357 0 -0.853 72.1 74.6 76.9 -0.05 6329 46.5 50.3 0.000 9608180523 0 -1.071 72.0 74.6 76.9 -0.05 6316 72.0 51.7 0.000 9608190359 2 -1.182 72.0 74.1 76.8 0.00 9680 62.0 0.000 9608200135 1 -0.385 72.2 74.6 76.8...

  • Page 106: Csld Problem 4 - No Csld Idle Time

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed 9602150326 0.144 42.1 41.6 40.9 -0.00 7994 76.0 69.6 415 0.000 9602160140 0.354 42.0 41.6 41.2 0.00 6451 86.5 91.8 469 0.000 9602160333 0.281 42.0 41.6 41.2 0.00 6446 30.0 93.7 469 0.000 9602160506 0.260 42.0...
  • Page 107 CSLD Troubleshooting Actual CSLD Test Problems Analyzed Diagnostics IA5402 Excessive differences may indicate a JUN 24, 1996 2:30 PM defective probe. CSLD DIAGNOSTICS: MOVING AVERAGE TABLE T 2: MIDGRADE TIME SMPLS TLCVOL HEIGHT AVGTEMP TOPTEMP BDTEMP 960624140631 31 6521.67 53.299 78.76 81.10 86.64...

  • Page 108: Csld Problem 5 - Tank 1 Is Failing

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed Analysis The moving average table shows erratic probe readings. Fluid is rising and falling by several gallons. Solution Replace probe. CSLD PROBLEM 5 - TANK 1 IS FAILING Reports I251, I201, IA52, IA51, and I609 were collected for analysis. Diagnostics I25100 JUN 26, 1996 2:37...
  • Page 109 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 2 9606260806 -0.159 25.1 1 -0.140 8959 16 30.4 32.6 77.32 0.000 3 9606260928 -0.039 31.3 1 -0.026 9277 18 45.0 44.8 87.45 0.000 4 9606261351 0.020 102.1 0.031 5404 41 25.9 24.3 43.32 0.000 5 9606261122 -0.010 41.4...

  • Page 110: Csld Problem 6 - Csld Periodic Failure Tank 1

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed 9606200101 3 -0.183 70.4 74.1 79.3 -0.07 7715 48.5 12.6 0.000 9606200241 3 -0.187 70.3 74.2 79.5 -0.05 7711 53.5 14.3 0.000 9606200429 0 -0.175 70.3 74.3 79.6 -0.04 7708 70.5 16.0 0.000 Wrong values.
  • Page 111 CSLD Troubleshooting Actual CSLD Test Problems Analyzed I25100 JUN 17, 1998 8:32 AM Station Header 1 Station Header 2 Station Header 3 Tanks programmed as Station Header 4 manifolded would have a common result. CSLD TEST RESULTS TANK PRODUCT RESULT UNLEADED SOUTH PER: JUN 17, 1998 FAIL UNLEADED NORTH...
  • Page 112 CSLD Troubleshooting Actual CSLD Test Problems Analyzed IA5100 JUN 17, 1998 8:32 AM Inconsistent large leak rates. T1 is filling T2 while test is running. CSLD DIAGNOSTICS: RATE TABLE T 1:UNLEADED SOUTH TIME ST LRT AVTMP TPTMP BDTMP TMRT DSPNS VOL INTVL DEL ULLG THPT 9806060245...
  • Page 113 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 980617081337 5316.16 48.570 63.51 66.19 71.45 980617081407 5315.18 48.562 63.51 66.19 71.45 980617081437 5313.85 48.552 63.50 66.19 71.45 980617081507 5312.97 48.546 63.50 66.19 71.45 980617081537 5311.84 48.538 63.50 66.18 71.44 980617081607 5310.87 48.531 63.50 66.17 71.44...
  • Page 114 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 980617081507 5349.11 48.821 63.89 67.15 72.67 980617081537 5348.68 48.818 63.88 67.14 72.67 980617081607 5347.10 48.806 63.88 67.13 72.67 980617081637 5347.82 48.811 63.88 67.12 72.67 980617081707 5345.59 48.795 63.87 67.13 72.67 980617081737 5340.45 48.757 63.86 67.14 72.67...

  • Page 115: Csld Problem 7 - No Csld Results

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed CSLD PROBLEM 7 - NO CSLD RESULTS Diagnostics I20100 MAY 14, 1998 11:44 AM Station id 1 Station id 2 Station id 3 Station id 4 IN-TANK INVENTORY TANK PRODUCT VOLUME TLC VOLUME ULLAGE HEIGHT WATER...

  • Page 116: Csld Problem 8 - Csld Failure Tank 1

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed T 3:PREMIUM UNLEADED LAST HOUR = 248651 3737.9 3773.5 3797.8 3817.8 3883.3 3904.5 3904.7 Analysis The volume table IA53 gets cleared when a gap in time between probe samples is detected. The site operators were turning the console’s power Off every evening.
  • Page 117 CSLD Troubleshooting Actual CSLD Test Problems Analyzed PLUS 6362 56.81 68.1 3366 PREMIUM 7916 69.05 67.3 1812 IA5200 JUN 11, 1998 12:45 PM Comparing compensated LRATE to uncompensated AVLRATE shows excessive compensation. CSLD DIAGNOSTICS: RATE TEST DATE LRATE INTVL ST AVLRTE C3 FDBK ACPT THPUT DFMUL RJT 9806110308 -0.309...
  • Page 118 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 9805240303 0.057 55.1 14.7 71.9 -0.05 7426 45.0 9805240454 0 -0.138 54.9 14.7 71.8 -0.00 7366 21.5 9805240552 0 -0.084 54.8 14.7 71.8 -0.01 7337 40.0 10.1 9805250213 3 -0.048 51.2 14.7 72.0 -0.03 1599 5019 32.5...

  • Page 119: Csld Problem 9 - Tank 1 Fail

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed 1383.000 23473.699 23473.500 23473.699 23473.699 23473.500 23485.051 23484.699 23484.850 23485.150 23484.949 41917.949 17255.750 18685.750 19646.900 19714.150 19804.750 19917.900 41901.301 Analysis From the IA52 command compare LRATE (-0.309) with AVLRTE (0.040). This shows that there is excessive compensation.
  • Page 120 CSLD Troubleshooting Actual CSLD Test Problems Analyzed IA5101 MAY 18, 2000 8:25 CSLD DIAGNOSTICS: RATE TABLE T 1:UNLEADED TIME ST LRT AVTMP TPTMP BDTMP TMRT DSPNS VOL INTVL DEL ULLG EVAP 0004200431 0 -0.085 53.3 52.0 56.5 0.00 9682 50.0 48.5 0 0.000 0004202332...
  • Page 121 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 0005080126 0.020 66.4 -107.4 69.0 -0.13 7014 141.5 276 0.000 0005080427 0.129 66.0 -107.3 69.1 -0.11 7014 30.5 276 0.000 0005082328 0.097 64.5 -107.3 70.3 -0.16 2854 2747 129.5 27.3 467 0.000 0005090218 0.051 64.1 -107.3 70.3 -0.14 2518...

  • Page 122: Csld Problem 10 - Tank 8 Failing

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed CSLD PROBLEM 10 - TANK 8 FAILING Diagnostics I61200 7, 1999 10:10 AM TANK MANIFOLDED PARTNERS TANK PRODUCT LABEL MANIFOLDED TANKS DIESEL 1 2, 3, 4, 5 DIESEL 2 1, 3, 4, 5 DIESEL 3 1, 2, 4, 5 DIESEL 4...

  • Page 123: Csld Problem 11 - Periodic Test Fail Tank 2

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed I61101 7, 1999 10:13 AM LEAK TEST <------START TEST TIME------> TEST TEST TEST START TANK METHOD TYPE HOURS METHOD YEAR MONTH DAY OCCUR HH:MM ---- ----- ---- ----- ------ ---- ----- --- ----- ----- CSLD PER.

  • Page 124: Csld Problem 12 - Periodic Test Fail On Tank 1

    CSLD Troubleshooting Actual CSLD Test Problems Analyzed CSLD DIAGNOSTICS: RATE TABLE T 3:SUPREME TIME ST LRT AVTMP TPTMP BDTMP TMRT DSPNS VOL INTVL DEL ULLG THPT 9910190459 0 -0.166 85.9 88.1 88.8 0.02 1074 5434 52.5 10.2 9910200011 0 -0.131 85.7 88.0 88.9...
  • Page 125 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 981120072912 3434.87 36.405 61.85 60.89 57.33 981120072942 3434.70 36.404 61.85 60.89 57.33 981120073012 3434.65 36.404 61.85 60.89 57.32 981120073042 3434.54 36.403 61.85 60.88 57.32 981120073112 3434.45 36.403 61.85 60.88 57.32 981120073142 3434.39 36.403 61.85 60.87 57.31...
  • Page 126 CSLD Troubleshooting Actual CSLD Test Problems Analyzed 981120075512 3433.34 36.397 61.85 60.89 57.38 981120075542 3433.35 36.397 61.85 60.88 57.39 981120075612 3433.38 36.397 61.85 60.88 57.39 981120075642 3433.31 36.397 61.85 60.88 57.39 981120075712 3433.31 36.397 61.85 60.88 57.40 981120075742 3433.29 36.397 61.85 60.88 57.40...
  • Page 127 For technical support, sales or other assistance, please visit: www.veeder.com...

Table of Contents

Save PDF
