Depth below surface (waterline) offset: Set the distance from
the transducer to the surface - this should be set as a
positive value. For example, +0.5 m (+1.77 ft).
For depth below transducer, set the offset to 0.
Water temperature calibration
Temperature calibration is used to adjust the water temperature
value from the sonar transducer to match the data from another
temperature sensor. It may be required to correct for localized
influences to the measured temperature.
Calibration range: -9.9° - +9.9°. Default is 0°.
Ú Note:
Water temperature calibration only appears if the
transducer is temperature capable. Check transducer type
selection if this option should be available.
Transducer type
Transducer type is used for selecting the transducer model
connected to the sonar module. The transducer selected will
determine what frequencies the user can select during sonar
operation. In some transducers with built-in temperature sensors,
the temperature reading may be inaccurate or not available at all if
the wrong transducer is selected. Transducer temperature sensors
are one of two impedances - 5k or 10k. Where both options are
given for the same model transducer, refer to paperwork supplied
with transducer to determine impedance.

StructureScan

This feature is automatically enabled when a TotalScan transducer is
plugged in before the unit has been powered on.
Radar setup
Ú Note:
The 5" and 7" units do not support radar.
Use the Radar Installation dialog to setup the radar.
Ú Note:
The installation can vary depending on the radar. Follow
the installation and setup instructions supplied with the radar.
