Remove the retaining bolts from Hood Handle (A3), then attach it onto the Hood (A1)
using the retaining bolts.
14
Attach the hood assembly onto the barbecue body using the M5x10 Bolts (D9x6pcs).
A1
A3
Rear view of the barbecue
D9
11
