User Guide | Controller for appliance control, AK-CC 450
Survey of functions
Function
Normal display
Normally the temperature value from one of the two thermostat sensors S3 or S4 or a
mixture of the two measurements is displayed.
In o17 the ratio is determined.
Thermostat
Set point
Regulation is based on the set value plus a displacement, if applicable. The value is set via a
push on the centre button.
The set value can be locked or limited to a range with the settings in r02 and r 03.
The reference at any time can be seen in "u91 Cutout temp".
Differential
When the temperature is higher than the reference + the set differential, the compressor
relay will be cut in. It will cut out again when the temperature comes down to the set refer-
ence.
Setpoint limitation
The controller's setting range for the setpoint may be narrowed down, so that much too
high or much too low values are not set accidentally - with resulting damages.
To avoid a too high setting of the setpoint, the max. allowable reference value may be
lowered.
To avoid a too low setting of the setpoint, the min. allowable reference value may be
increased.
Correction of the display's temperature
If the temperature at the products and the temperature received by the controller are not
identical, an offset adjustment of the display temperature can be carried out.
Temperature unit
Set here if the controller is to show temperature values in °C or in °F.
Correction of signal from S4
Compensation possibility due to long sensor cable
Correction of signal from S3
Compensation possibility due to long sensor cable
Start / stop of refrigeration
With this setting refrigeration can be started, stopped or a manual override of the outputs
can be allowed. (For manual control the value is set at -1. Then the valve outlet and the
relay outlets can be force-controlled by the respective reading parameters (u23, u58, etc.).
Here the read value can be overwritten.)
Start / stop of refrigeration can also be accomplished with the external switch function
connected to a DI input.
Stopped refrigeration will give a "Standby alarm".
Night setback value
The thermostat's reference will be the setpoint plus this value when the controller changes
over to night operation. (Select a negative value if there is to be cold accumulation.)
Thermostat function
Here it is defined how the thermostat is to operate. Either as an ordinary ON/OFF thermo-
stat or as a modulating thermostat.
1: ON/OFF thermostat
2: pulse width modulation (PWM)
With "PWM" the refrigeration/brine valve will limit the flow of refrigerant so that the tem-
perature variation will be less than for the ON/OFF thermostat.
The differential (r01) must not be set lower than 2K for "PWM".
In a decentralised plant you must select the ON/OFF thermostat setting, so that with ap-
plications 3 and 9 the setting is forced to "1".
Selection of thermostat sensor
Here you define the sensor the thermostat is to use for its control function. S3, S4, or a
combination of them. With the setting 0%, only S3 is used (Sin). With 100%, only S4.
© Danfoss | ADAP-KOOL® | 2015.10
Ref.
Dif.
Para-
Parameter by operation via data com-
meter
munication
Display air (u56)
Thermostat control
Cutout °C
r01
Differential
r02
Max cutout °C
r03
Min cutout °C
r04
Disp. Adj. K
r05
Temp. unit
°C=0. / °F=1
(Only °C on AKM, whatever the setting)
r09
Adjust S4
r10
Adjust S3
r12
Main Switch
1: Start
0: Stop
-1: Manual control of outputs allowed
r13
Night offset
r14
Therm. mode
r15
Ther. S4 %
RS8EU702 | 15
