User Guide | Controller for appliance control, AK-CC 450
Define rail heat during defrost:
0: Off
1: On
2: Pulsing
Defrost stop temperature at application 9 and thermostat band 2
Max. defrost time at application 9 and thermostat band 2
If you wish to see the temperature at the defrost sensor, push the controller's lowermost
button. (May be changed to another function in o92.)
If you wish to start an extra defrost, push the controller's lowermost button for four sec-
onds.
You can stop an ongoing defrost in the same way

Parameters for refrigeration function

Period time for the pulse width period (PWM)
Expert setting - The value should only be changed by specially trained staff.
Max. opening degree at PWM
Min. opening degree at PWM
Wind up factor at PWM
Expert setting - The value should only be changed by specially trained staff.
Amplification factor at PWM
Expert setting - The value should only be changed by specially trained staff.
Integration time at PWM
Expert setting - The value should only be changed by specially trained staff.
Fan
Fan stop temperature
The function stops the fans in an error situation, so that they will not provide power to the
appliance. If the defrost sensor registers a higher temperature than the one set here, the
fans will be stopped. There will be re-start at 2 K below the setting.
The function is not active during a defrost or start-up after a defrost.
With setting +50°C the function is interrupted.
Pulse operation of fan
0: No pulse operation
1: Pulse operation when the thermostat does not call for refrigeration
2: Pulse operation when the thermostat does not call for refrigeration, but only during
night operation
Pulse operation period for fan
Here the overall pulse time is set. The sum of ON-to and OFF time.
ON time for fan
Here the % part of the period the fans are to be in operation is set.
The LED on the controller's front will indicate whether a defrost is going on.

Internal defrosting schedule/clock function

(Not used if an external defrosting schedule is used via data communication.)
Up to six individual times can be set for the defrost start throughout the day.
Defrost start, hour setting
Defrost start, minute setting (1 and 11 belong together, etc.)
When all t01 to t16 equal 0 the clock will not start defrosts.
Real-time clock::
Setting the clock is only necessary when there is no data communication.
In the event of a power failure of less than four hours, the clock function will be saved.
Clock: Hour setting
Clock: Minute setting
© Danfoss | ADAP-KOOL® | 2015.10
d27 Railh. at def.
d28 DefStop Temp2
d29 MaxDefTime2
Defrost temp.
Def Start
Here you can start a manual defrost
Hold After Def
Shows ON when the controller is
operating with coordinated defrost.
Disable def.
Defrost in progress can be stopped
Defrost State
Status on defrost
1= pump down / defrost
n63 Pwm Period
n64 Pwm Max. OD
n65 Pwm Min. OD
n66 PwmWindUpFac
n67 Pwm Kp fact.
n68 Pwm Tn sec
Fan control
F04 FanStopTemp.
F05 FanPulseMode
F06 Fan cycle
F07 Fan ON %
Fan Relay
Here you can read the fan relay status,
or force-control the relay in "Manual
control" mode.
t01-t06
t11-t16
t07
t08
