INSTALLATION & USER INSTRUCTIONS
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e : sales@focalpointfires.co.uk
Please note : Except where otherwise stated, all rights,
including copyright in the text, images and layout of this
booklet is owned by Focal Point Fires plc. You are not per-
mitted to copy or adapt any of the content without the
prior written permission of Focal Point Fires plc.
WALL MOUNTED ELECTRIC FIRE
MODELS COVERED BY THESE INSTRUCTIONS
L23SE MIDNIGHT ELECTRIC
L23SE CALLISTO ELECTRIC
L30SE VESUVIUS ELECTRIC
L30SE SANTORINI ELECTRIC
L23SE CALLISTO
L30SE SANTORINI
All instructions must be handed to the user for
1
GB IE
F500301
F500303
F500302
F500304
L23SE MIDNIGHT
L30SE VESUVIUS
safekeeping.
Revision A - 08/10
©
2010 Focal Point Fires plc.
