Excelsior
Slimline
Excelsior
Multiflue
INSTALLATION AND USER
INSTRUCTIONS
All instructions must be handed to user for safekeeping
Revision F - 05/10
Country(s) of destination - GB/IE
Focal Point Fires plc, Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e-mail: sales@focalpointfires.co.uk
Advertisement
Table of Contents
Related Manuals for FocalPoint Exselsior Slimline
Summary of Contents for FocalPoint Exselsior Slimline
- Page 1 Excelsior Slimline Excelsior Multiflue INSTALLATION AND USER INSTRUCTIONS All instructions must be handed to user for safekeeping Revision F - 05/10 Country(s) of destination - GB/IE Focal Point Fires plc, Christchurch, Dorset BH23 2BT Tel: 01202 499330 Fax: 01202 499326 www.focalpointfires.co.uk e-mail: sales@focalpointfires.co.uk...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS Preliminary Notes Before Installation This appliance is an Inset live fuel effect gas fire which provides radiant warmth utilising the latest type burner technology. The fire is designed to fit various types of fireplaces and natural draught flues as listed in the Installation Requirements. -
Page 3: Table Of Contents
Section Contents Page No. Page No. Section Contents Important Notes Cable Fixing Appliance Data Fitting the Burner Tray Installation Requirements Fuel Bed Layout (coal effect models) Site Requirements Fuel Bed Layout (pebble effect models) Debris Collection Space 10.0 Fitting the Fireframe Ventilation 11.0 Testing and Commissioning... -
Page 4: Appliance Data
APPLIANCE DATA Manual Control Version Manual Control Version Remote Control Version Gas Group G20 Natural Gas CAT I2H G31 Propane CAT I3P G20 Natural Gas CAT I2H Inlet Pressure 20 mbar (+/-2.0mbar) 37 mbar (+/-2.0mbar) 20 mbar (+/-2.0mbar) Max Energy Input (gross) 6.2 kW 6.2 kW 6.2 kW... -
Page 5: Site Requirements
SITE REQUIREMENTS The fireplace opening should be inspected and repairs made where necessary. Any chair brick or fireback may be left in situ, providing that the dimensional requirements for debris collection space and spigot clearances are met. See diagram below. The opening WIDTH and HEIGHT dimensions should be between 380mm and 450mm wide, and 540mm to 575mm high. -
Page 6: Debris Collection Space
DEBRIS COLLECTION SPACE The mounting depth of this appliance is 108mm (120mm - Multiflue) . In accordance with BS 5871 part 2, minimum debris collection volumes are required behind the installed appliance. These are shown in the table below and as dimension X on the fireplace diagram shown previously. CLAY/CEMENT LINES OR BLOCK FLUE WHICH IS NEW, UNUSED, OR PREVIOUSLY ONLY USED WITH A GAS FIRE. -
Page 7: Component Checklist
COMPONENT CHECKLIST QUANTITY DESCRIPTION Firebox and burner tray assembly Decorative frame Firefront Black Moulded ceramic fibre combustion matrix (coal effect version only) Beige Moulded ceramic fibre combustion matrix (Pebble effect, Natural gas versions only) Individual ceramic coals (coal effect version only) Individual ceramic pebbles (pebble effect , Natural gas versions only) Ceramic fibre side cheeks (pebble effect , Natural gas versions only) Ceramic brick panel... -
Page 8: Gas Supply Routing
PREPARING THE OPENING (continued) Cable fixing: For fixing the fire by the cable method, see relevant section. Fixing by screw: Mark and drill the fireframe or base, and relevant points in the opening or on the wall. Wall plugs will be required. NOTE: Plastic rawlplugs are not suitable for this application. -
Page 9: 8.5 Fitting The Burner Tray
FITTING THE BURNER TRAY Temporarily fit the burner tray and ensure a suitable gas route can be achieved. Place the burner tray into the firebox making sure that the rear lugs locate properly on to the ledge in the firebox. Fit the two securing screws through the tray legs to secure the assembly. Connect the gas supply and tighten the gas connections. -
Page 10: Fitting The Decorative Frame
FUEL BED LAYOUT (continued) The coals may be rotated slightly within their positions to give a good visual effect. Pay special attention to finally adjust the coals with the fire lit on the HIGH setting in order to ensure that no flames play onto the firebox sides. This will reduce the possibility of heat discolouration. The fire is designed to operate correctly with the coals supplied when assembled according to the instructions. -
Page 11: Testing And Commissioning
11.0 TESTING AND COMMISSIONING Turn on and test the gas supply up to the fire for any leaks, in accordance with current Approved Codes of Practice (ACOPs) 11.1 OPERATING THE APPLIANCE - Manual versions The pilot is visible through the left hand side of the matrix. Rotate the coals/pebbles for good viewing. Push in and turn the control knob to the SPARK position, and hold there for a few seconds. -
Page 12: Testing For Spillage
12.0 FLUE SPILLAGE MONITORING SYSTEM This fire is fitted with a flue spillage safety device (ODS). If the fire shuts down during use for no apparent reason then several things may be suspected. If a door or window has been opened creating a draught, then pilot disturbance is the problem, and removal of the draught should resolve this. -
Page 13: Servicing
14.0 SERVICING Isolate the fire from the gas supply. Ensure that the fire is fully cold before attempting service. A suggested procedure for servicing is detailed below. 1. Lay out the dust sheet and tools. 2. Carefully remove the ceramic components. 3. -
Page 14: Troubleshooting Guide
14.4 REMOVING THE FIREBOX Remove the burner tray as described previously. Protect the hearth from potential damage. Unroll the coiled tensioner cables from the rear of the firebox. Remove the securing nipples and tensioner adjusters. The firebox is now released from the opening and can be slid outward onto the hearth. Inspect the fireplace opening for debris and if excessive rectify the flue before proceeding further. - Page 15 U S E R I N S T R U C T I O N S Section Contents Page No. Important Notes Replacing the Batteries Firefront Clearances to Combustibles Ventilation Operating Instructions Flue Spillage Monitoring System Cleaning Coals and Ceramics Servicing 10.0 Shortlist of Spares...
-
Page 16: Clearances To Combustibles
FIREFRONT This fire is supplied with a particular style of firefront. Use of the firefront will ensure an adequate airflow under the fuelbed for the correct functioning of this appliance. Compliance with safety standards cannot be guaranteed if another style of front is used. CLEARANCES TO COMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. -
Page 17: Flue Spillage Monitoring System
OPERATING THE FIRE (remote control versions) continued If the pilot is extinguished during use of the fire, you MUST wait ten minutes before repeating the ignition procedure. To turn the main burner OFF whilst keeping the pilot flame lit, turn the ignition control knob to the pilot position then only the pilot will remain lit.
