INSTALLATION & USER INSTRUCTIONS
WALL MOUNTED HIGH EFFICIENCY GAS FIRE
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e : sales@focalpointfires.co.uk
Questions or problems with your appliance?
Don't take it back to the store
01202 588601
just give us a call on
lines open between 9am and 5pm, Monday to Friday
Please note : Except where otherwise stated, all rights,
including copyright in the text, images and layout of this
booklet is owned by Focal Point Fires plc. You are not per-
mitted to copy or adapt any of the content without the
prior written permission of Focal Point Fires plc.
MODELS COVERED BY THESE INSTRUCTIONS
L30 PIANO
L30 CASCARA
L30 VALERIA
AVAILABLE IN NG AND LPG
PIANO
VALERIA
we're here to help
1
The products covered by this booklet are protected under
patent GB2275331C.
All instructions must be handed to the user for
safekeeping.
Revision E - 04/15
GB IE
CASCARA
2015 Focal Point Fires plc.
'
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FocalPoint L30 PIANO
Summary of Contents for FocalPoint L30 PIANO
- Page 1 INSTALLATION & USER INSTRUCTIONS WALL MOUNTED HIGH EFFICIENCY GAS FIRE GB IE MODELS COVERED BY THESE INSTRUCTIONS L30 PIANO L30 CASCARA L30 VALERIA Focal Point Fires plc. Christchurch, Dorset BH23 2BT AVAILABLE IN NG AND LPG Tel: 01202 499330 Fax: 01202 499326 www.focalpointfires.co.uk...
-
Page 2: Table Of Contents
I N S T A L L A T I O N I N S T R U C T I O N S GB IE Section Contents Page No. Section Contents Page No. Important Notes Testing and Commissioning Appliance Data Operating the Appliance Installation Requirements Setting pressure... -
Page 3: Appliance Data
2.0 APPLIANCE DATA GB IE Operating/Inlet Max Energy Input (kW) Min Energy Input (kW) Pressure (±2.0 mbar) Destination Model Country G25 G30 G31 Gross Gross I 2H Natural gas models 2.35 1.35 GB - IE I 3P LPG models GB - IE 1.38 Specifications Natural Gas Models... -
Page 4: Ventilation
4.0 SITE REQUIREMENTS GB IE (CONTINUED) Clearances to combustible materials Combustible materials are defined as wood, fabrics, or other materials likely to combust if exposed to flame. Generally, any mate- rial, which is likely to discolour, melt or misshape when exposed to moderate heat, should be considered as a combustible mate- rial or surface. -
Page 5: Gas Supply Routes
6.0 GAS SUPPLY ROUTES GB IE There are six possible entry points for the gas supply pipework to enter the appliance firebox. as shown in figure 2. These entry points are ‘knock out’ type holes. Non-concealed gas con- nections may be made using the entry points in the bottom or sides of the firebox. -
Page 6: Testing And Commissioning
7.0 FIXING THE APPLIANCE GB IE (CONTINUED) Do not tighten fully. Before tightening the wall mounting screws fully, at this stage it is recommended to check the horizontal alignment of the appliance with a spirit level, as small adjustments can still be made if necessary. -
Page 7: Fitting The Decorative Frame
8.3 FITTING THE DECORATIVE FRAME ASSEMBLY GB IE Remove the frame panel from any pro- tective packaging. Ensure all/any pro- tective film is removed as the facia may be damaged if the fire is lit with the facia in position whilst still covered in film. -
Page 8: Servicing The Burner Unit
10.1 SERVICING THE BURNER UNIT AND GAS ASSEMBLY GB IE Firstly, remove the decorative facia assembly as described in section 8.4. Remove the inner glass panel, and disconnect the gas connection inside appliance.The gas connections to the gas valve can now be released. Undo the four screws retaining the burner support brackets to the base and rear of the firebox, and remove the control knob and spindle assembly by removal of the spindle retaining clip.The burner may now be removed. -
Page 9: Troubleshooting Guide
11.0 TROUBLESHOOTING GUIDE GB IE Fire sparks but pilot does not light No gas to fire, check isolators are open and gas supply is on. Pipework blockage, clean out. Air not fully purged, re purge supply or wait longer. Spark earthing to metalwork, reset gap correctly. Blocked pilot, clean out internally. -
Page 10: Important Notes
U S E R I N S T R U C T I O N S GB IE Section Content Page No Important Notes Clearances to Combustibles Fire guards Ventilation & Room Size Operating Instructions Combustion Monitoring System Cleaning Servicing List of Replacement Parts 10.0 Installation Details... -
Page 11: Clearances To Combustibles
2.0 CLEARANCES TO COMBUSTIBLES - GB IE (CONTINUED) Clearances to combustible materials (continued) Under no circumstances should any electrical equipment e.g. plasma/LCD screen TV sets etc. be positioned on the wall above the appliance.The appliance is designed to be wall mounted alone and not in conjunction with any type of combustible fire surround. No combustible shelves should be positioned on the wall above the appliance. -
Page 12: Combustion Monitoring System
5.0 OPERATING THE APPLIANCE GB IE The control knob is located on the lower right hand side of the outer case. It is marked as shown in figure 4. Push the control knob in fully and turn anti- The pilot is visible behind the left hand side of the burner. ‘OFF’... -
Page 13: Installation Details
10.0 INSTALLATION DETAILS GB IE Name & contact details of installer : Supplied by : Installer GAS SAFE registration No : Model : Fire serial No. : Date installed : 11.0 SERVICE HISTORY Date of service Serviced by (name): GAS SAFE No. : Contact details of Engineer 2015 Focal Point Fires plc. - Page 14 12.0 GUARANTEE - TERMS AND CONDITIONS GB IE Registration is not required. Provided that the following three terms and conditions are adhered to: 1. For any claim to be made within 1 year from date of purchase you will be required to provide and supply us with your original proof of purchase.
