Quick Setup
Step 1:
Step 2:
Step 3:
Individual features and settings are adjustable under the Advanced menu. Consult the User
Manual for more information on advanced features of Source Four LED fixtures.
Lustr + and Studio HD
Quick Setup
Smooth dimming, good consistency, direct
General
color control, simple operation.
Tungsten-like dimming, HSI color control with
Plus-7 fine tuning, fast color mixing and
Stage
consistency, console output snapshot to
record stand alone presets.
Maximum consistency in extreme
XT Arch
applications, reduced brightness.
Maximum brightness, quick response, RGB
High Impact
color control, reduced consistency.
Three-point control—White Point (CCT),
Studio Intensity and Tint, DMX, or standalone
operation.
Parameter
Profile
Strobe
Data Loss
Setting
Plus Seven
Fan Control
Output Setting
Dimming
Curve
Red Shift
White Point
Status
Indicators
Overtemp
Sou rc e Fo ur LED Pr of i le
On the Main Menu, scroll to Quick Setups and press [
Scroll to the desired setup and then press [
An asterisk (*) indicates which setup is active.
Press [ ] to return to the home screen.
The top line of the home screen displays the name of the active setup.
Features
General Stage
Direct HSI
Enabled Enabled
Instant Instant
N/A Enabled
DMX DMX
Regulated Regulated
Standard Incandescent
N/A Disabled
N/A 3200
On On
Dark Dark
].
General lighting, rentals.
Theatrical lighting.
High-temperature environments, installations
with limited access.
Video-based control, effects lighting, concerts.
Video and film lighting, white light-only
applications.
XT Arch
DMX Settings
HSI
Enabled
HLL-4ever
Disabled
DMX
LED Settings
Protected
Standard
Disabled
3200
Local Settings
On
Visible
Page 5 of 8
Features
].
Recommended For:
High Impact Studio
RGB Studio
Enabled Enabled
Instant N/A
Disabled Disabled
DMX DMX
Boost Regulated
Quick Linear
Disabled N/A
5600 N/A
On On
Dark Visible
