User Manual
ORDER DIRECTLY TODAY AT:
Source Four MultiPAR™ User Guide
Source Four MultiPAR guidelines
Please note the following precautions prior to use:
•
Do not mount the Source Four MultiPAR on or near combustible surfaces.
•
Do not operate the Source Four MultiPAR without lenses properly installed.
•
Always hang the Source Four MultiPAR with color frames held securely behind the
MultiPAR retaining channel.
•
Safety cables are provided with each MultiPAR. Be certain to secure the MultiPAR to
the batten by threading the safety cable through the end cap holes when hanging
the unit.
Power requirements
The Source 4 MultiPAR has several different standard, as well as custom configura-
tions of electrical circuitry. Make certain you are familiar with the wiring of the Multi-
PAR and that you have sufficient power (dimmer capacity) to operate the fixture.
C A U T I O N :
Make sure that the total wattage used by your MultiPAR
does not exceed the power available by dimmer.
www.BulbAmerica.com
or CALL TOLL FREE 888-505-2111
Source Four MultiPAR • 1
Advertisement
Table of Contents
Related Manuals for ETC Source Four MultiPAR
Summary of Contents for ETC Source Four MultiPAR
-
Page 1: Power Requirements
• Do not operate the Source Four MultiPAR without lenses properly installed. • Always hang the Source Four MultiPAR with color frames held securely behind the MultiPAR retaining channel. • Safety cables are provided with each MultiPAR. Be certain to secure the MultiPAR to the batten by threading the safety cable through the end cap holes when hanging the unit. -
Page 2: Installing The Hpl Lamp
115, 120, 230, and 240 volt HPL lamps are available. Operating lamps above their rated voltage reduces lamp life and can cause premature lamp failure. Improperly installed lamps will cause premature lamp and socket failures. 2 • Source Four MultiPAR... -
Page 3: Hpl Lamps
Use of other lamps may pose a safety risk, damage the fixture, and will void your warranty. Lens identification Lenses for the Source Four MultiPAR come in four versions. The type or beam spread can be identified by the lens texture. VNSP... -
Page 4: Changing Source Four Multipar Lenses
Removing a lens Disconnect power from the fixture before attempting to remove or install a lens. Source Four MultiPAR lenses become hot while in operation. Let the fixture cool before handling the lens. Place the fixture on a flat, stable work surface. -
Page 5: Gel Frames And Accessories
The spring steel pushes the gel frame into the MultiPAR. ETC identifies the side of the MultiPAR that holds the gel frame as the gel frame retaining channel. -
Page 6: Circuit Wiring Configurations For The Multipar-12
In the second terminal block from the left, insert the wires labeled 2,6,10. In the third terminal block from the left, insert the wires labeled 3,7,11. In the fourth terminal block from the left, insert the wires labeled 4,8,12. See for detail. Figure 7 6 • Source Four MultiPAR... -
Page 7: Spare Parts List
ORDER DIRECTLY TODAY AT: www.BulbAmerica.com or CALL TOLL FREE 888-505-2111 Spare parts list Source Four MultiPAR Lamp Burner Assembly Reference Quantity Part Number Description Number Required TP22 CLCLM assembly, W330-01 16-AWG Wire, Silver Contact, 3,5, or 7ft long TP22 CLCM assembly,... -
Page 8: Source Four Multipar Final Assembly
ORDER DIRECTLY TODAY AT: www.BulbAmerica.com or CALL TOLL FREE 888-505-2111 Spare parts list Source Four MultiPAR Final Assembly Reference Quantity Part Number Description Number Required 7061A3051 Hanger Bracket, MultiPar HW587 1/2” washer HW5138 1/2 -13 x 1” HH bolt Trunnion Bracket, Multi-...
