Figure 2: Covert IP camera Lens and bracket description
2
1
3
Lens and brackets: (purchased separately)
1. L-shape lens
2. L-shape lens cover
3. L-shape lens mounting bracket
4. Pinhole lens
5. Pinhole lens mounting bracket
Accessories
L-shape lens:
Cover
Adhesive tape (2 pcs, 1 mm and 4 mm)
Pinhole lens:
Mounting bracket
8
4
5
6
7
6. Cylinder lens
7. Cylinder lens mounting
bracket
8. L-shape 2mm lens
9. L-shape 2mm lens surface
mount cover
Mounting bracket
Screw A Ø4 x 25 mm (3 pcs)
Drywall anchor Ø7.5 x 24.5 mm (3
pcs)
Drywall anchor Ø7.5 x 24.5 mm (3
pcs)
Screw A Ø4 x 25 mm (3 pcs)
9
8
