Accessories
Mounting plate
Mounting rack
Screw A, Ø4 x 25 mm (3 pcs)
Table 1: LED Indicators
LED
POWER
STATUS
LINK
Installation Manual
Color and Status
Solid red
Unlit
Solid green
Unlit
Flashing amber
Unlit
12 VDC connector: DC jack
socket to terminal connectors
with positive and negative indicators.
Drywall anchor, Ø7.5 x 24.5 mm (3
pcs)
Screw B, Ø2 x 6 mm (4 pcs)
Indication
Normal operation
Power Off
Camera works properly
Camera does not work properly.
Network connection is functioning
properly
No network connection
7
