3.
Fix the mounting bracket on the rear panel of the camera block with the four
enclosed screws B.
4.
Hook the top catch of the camera mounting bracket on the prepared rack. Then
gently press the lower part of the camera block against the rack so that it snaps
into position on the rack.
Note: If there is a standard rail installed, you can directly snap the camera block with
mounting bracket on the prepared rail.
10
Installation Manual
