Parallel Communication Interface - Microcom 438TC Operator's Manual

Chapter 3
3.5

Parallel Communication Interface

The printer may be configured with a standard Uni-directional parallel port. The connector
on the printer side is a DB25 pin female type of connector.
3.6 Ethernet Communication Interface
Either type 192.168.200.3 in your Web Browser or run the Device Installer software. Please
note that you will need to add the 192.168.200.3 address to your network in order to
communicate to the printer via the Web Interface.
Please note that the printer's Ethernet port is configured with an IP address of
192.168.200.3, a NET mask of 255.255.255.0, and a local port of 9100.
3.6.1 Device Installer
After starting the Device Installer software, you will see a screen similar to the picture below.
Select the Search button to search for the XPORT device.
438TC Operator's Manual - 880050-0100
Getting Started
3-5
