3. Remove the packet of screws from the inner chassis and set them aside; they will
be used in upcoming steps. Note: the plastic shield over the circuit board is there
by design and should not be removed.
4. Install the lower hard drive (HDD2), as shown below. Slide the SATA connector on
the hard drive into the black SATA connector highlighted below-left. Make sure the
drive is firmly connected to the SATA port before continuing.
MERCURY ELITE PRO DUAL
2. Slide the inner chassis out the front of the
outer case, as shown at left. Start by pushing
on the back cover, then grip the front grill and
pull the chassis the rest of the way.
5
DEVICE SETUP
