Installation

Dimensions – Evolution EF5 Freestanding
22
(565 mm)
Installation Clearances & Specifications
Minimum clearances shown are in millimetres. All Enviro fires are tested to AS/NZS2918:2001.
Specifications were correct at time of printing but may alter and those detailed below should be used as
a guide only. Refer to the Installation and Operation Manual supplied with every Enviro Pellet Fire or if
in doubt, consult your Switch Retailer. Refer to Safety Test 09/1981 for all clearances to combustibles.

Clearances to Combustibles

Enviro Evolution EF5 Pellet Fire
Clearance to Combustibles
Internal Flue
A
External Flue
A
Note: The above clearance to combustibles on the flue are only applicable within the fire envelope. Clearance outside this e.g.at a ceiling / wall thimble reverts to 25mm as per ARS flue
test 05/1185.
2
1 / "
4
34 5 / "
16
(871 mm)
B
E
D
C
B
E
H
J
23 7 / "
16
(595 mm)
5 5 / "
8
(144 mm)
26 3 / "
8
(670 mm)
B
F
E
G
G
F
B
F
E
J
I
F
J
28"
(711 mm)
24 3 / "
8
(619 mm)
Freestanding
Clearances
Dimension
Location
(mm)
A 100
B 150
C* 50
D ~210
E N/A
F 75
G* 50
H 100
I* 50
J* 25
* from shielded flue
Note: AS/NZS 2918
requires a minimum
of 100mm clearance
for any side requiring
access.
Note: These are
minimum clearances to
combustibles. Actual
installation distances
may be greater.
November 2011
