Internal Standard Flue Kit - Enviro Evolution EF5 Installation Manual

50

Internal Standard Flue Kit (50)

150mm
(minimum)
Heat-resistant
oor protector
December 2006
4
Internal Standard Flue Kit
600mm from
roof
penetration
Seismic restraint
(to be tted)
210 mm
~
To order :
This flue kit may be used in new and replacement
This ue kit may be used in new and replacement
applications in rooms with stud height of 2.4m.
applications in rooms with stud height of 2.4m. The
The overall height of the flue is 3.6m. The visible
overall height of the ue is 3.6m. The visible u e is
flue is finished in black and the ceiling plate is
nished in black and the ceiling plate is white. T he
white. The support angles for securing the liner to
support angles for securing the liner to the ceilin g are
the ceiling are not shown. Kit is supplied in carton.
not shown. Kit is supplied in a carton.
Each 50 Internal Standard Flue Kit contains:-
a P t r N o D
1 Galvanised outer liner
ø100mm x 900mm long
2 Stainless steel inner liner
ø75mm x 900mm long
4a Black p/coat outer liner
ø100mm x 900mm long
5 Inner/outer ue liner spacer
6c Ceiling thimble ø107mm hole
7c Ceiling decor plate
ø107mm hole – white
8 Rain cap 75mm
9 Rain Cap 100mm
10b Elbow 45° – ø75mm stainless
– black (painted)
12H T-adaptor/cleanout – ø75mm
– black (painted)
23 Support angle 950mm long
– 50mm x 50mm sides
50mm minimum clearance if lined ue
Note: The Davin 50 Internal Standard Flue
Kit complies with AS/NZS 2918:2001 as per
Applied Research Test Report 05/1185, dated
15 September 2005.
All res must be installed by a quali ed
installer as per the manufacturer's
instructions and AS/NZS2918:2001.
Telephone 0800 765 431. Fax 64 3 341 8057
s e i r c t p o i n
Drawing representative only - not to scale.
