Osburn OB02047 Installation And Operation Manual

Gusto wood burning cookstove
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation and Operation Manual
GUSTO WOOD BURNING
COOKSTOVE
(OB02047 model)
US Environmental Protection Agency
phase II certified wood stove
compliant with 2020 cord wood
standard
MOBILE
HOME
Security test made according to
regulations ULC S627 and UL 1482
by an accredited laboratory.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD STOVE. FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
46389A

Advertisement

loading
Need help?

Need help?

Do you have a question about the OB02047 and is the answer not in the manual?

Questions and answers

Related Manuals for Osburn OB02047

Summary of Contents for Osburn OB02047

  • Page 1 Installation and Operation Manual GUSTO WOOD BURNING COOKSTOVE (OB02047 model) US Environmental Protection Agency phase II certified wood stove compliant with 2020 cord wood standard MOBILE HOME Security test made according to regulations ULC S627 and UL 1482 by an accredited laboratory.
  • Page 3 It is also highly recommended to register the warranty online at https://www.osburn-mfg.com/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit. Installation and operation manual - Gusto woodburning cookstove...
  • Page 4 TABLE OF CONTENTS CERTIFICATION PLATE ........................ PART A - OPERATION AND MAINTENANCE ................1. Safety Information ......................... 7 2. General information ....................... 9 Performances ........................ 9 Specifications ......................10 Cookstove Dimensions ....................11 EPA Loading Procedure ....................13 3. Cookstove operation ......................17 Components use ......................17 Gas path ........................21 Blower Operation ......................22...
  • Page 5 6.12 Air Tubes And Baffle Installation ..................46 6.13 Handles installation ......................47 6.14 Mobile Home Installation ....................48 6.15 Level the product as needed ..................48 6.16 Exhaust System ......................50 PART B - INSTALLATION ......................7. General Information ......................52 Security ........................52 Regulations Governing the Installation of the Cookstove ..........53 Cookstove Positioning ....................53 Location of the Certification Label .................53 8.
  • Page 6 CERTIFICATION PLATE Page 6 Installation and operation manual - Gusto woodburning cookstove...
  • Page 7 PART A - OPERATION AND MAINTENANCE 1. Safety Information • Operate only with doors fully closed. If door is left partly open, gas and flame may be drawn out of the opening, creating risks from both fire and smoke. • The cookstove is not designed to be used when the door is open. Open the door only to startup or to reload the stove.
  • Page 8 • DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. • DO NOT BURN GARBAGE OR FLAMMABLE LIQUIDS SUCH AS GASOLINE, NAPHTHA, FUEL OIL, ENGINE OIL, KEROSENE, CHARCOAL LIGHTER FUEL, SIMILAR LIQUIDS, OR AEROSOLS TO START, REVIVE OR NEAR THE FIRE. KEEP ALL SUCH LIQUIDS WELL AWAY FROM THE HEATER WHILE IT IS IN USE.
  • Page 9 2. General information Performances Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. Model Gusto woodburning cookstove (OB02047) Type of combustion Non-catalytic Fuel Type Dry Cordwood Recommended heating area (sq. ft.
  • Page 10 Specifications Maximum log length 20" (508 mm) east-west orientation Recommanded log length 16" (406 mm) Flue outlet diameter 6 in (150 mm) Recommended connector pipe diameter 6 in (150 mm) Type of chimney ULC-S629, UL 103 HT (2100 °F) Necessary flue draft 0,05"...
  • Page 11 706mm 13 7/8" 353mm 27 3/4" OPTION 706mm 13 7/8" 353mm 9 7/8" Cookstove Dimensions 251mm OPTION 7 1/2" 9 7/8" 189mm 251mm 27 3/4" 706mm 13 7/8" 7 1/2" 353mm 189mm OPTION 9 7/8" 251mm 7 1/2" 6" 189mm 153mm 6"...
  • Page 12 2.3.1 Combustion Chamber Dimensions 3/8" 7 3/4" 198mm 18" 458mm 9" 228mm 11 7/8" 303mm 20" 508mm 16 1/2" 21" 419mm 533mm Figure 4: Door opening 3/16" 3/8" 11 7/8" 303mm 21" 16 1/2" 533mm 419mm Figure 5: Front view : Combustion chamber Figure 6: Side view : Combustion chamber Page 12 Installation and operation manual - Gusto woodburning cookstove...
  • Page 13 EPA Loading Procedure The best loading method for efficient and clean combustion with this fireplace is the EPA loading method. The images below show the space in the firebox where the logs are to be placed. It is important to always respect this space and not to put logs in the grid area marked with an X. The marked area is defined by the space between the glass and primary air channel.
  • Page 14 in the middle, in an East-West orientation (see Figure 11). Let the door open at 90 degree for 1 minutes. Close the door, start the blower at maximum speed, and let burn until the weight is down to target. Front Figure 10: Position of the bottom Figure 11: Position of the two top Figure 12: Example high burn load...
  • Page 15 Front Figure 13: Position of the bottom Figure 14: Position of the two top Figure 15: Example low burn load (side pieces (Low burn) pieces (Low burn) view) Let the door ajar at 90° until the flames roll on top of the fuel (between 2:00 and 3:30) and then close the door with the primary air control open.
  • Page 16 Front Figure 16: Position of the bottom Figure 17: Position of the two top Figure 18: Example medium burn load pieces (Medium burn) pieces (Medium burn) (side view) Let the door ajar at 90° until the flames roll on top of the fuel (between 2:30 and 4:00) and then close the door with the primary air control open.
  • Page 17 3. Cookstove operation Components use Cooking with a wood-burning cookstove is an art that requires several attempts to get to know and control the appliance. Many factors can influence how the cookstove will heat the oven and the cooking surface. Among them, the type of fuel used and its quality, the size of the logs and when to load before cooking.
  • Page 18 3.1.1 Oven Figure 20: Oven door closed Figure 21: Oven door open The cooker has a stainless steel oven to cook or bake food. The panoramic glass of the oven door allows you to watch your meal without having to open the door. During cooking, keep the oven door closed to maintain a constant temperature.
  • Page 19 3.1.2 Combustion chamber Figure 22: Combustion Chamber door closed Figure 23: Combustion chamber door open Installation and operation manual - Gusto woodburning cookstove Page 19...
  • Page 20 3.1.3 Cast iron cooking surface Figure 24: Cast iron cooking surface It is not recommended to cook food directly on the cast iron top, as the paint used is not food grade. The cast iron cooking surface on the top of the range is designed to provide intense heat to allow food to be cooked.
  • Page 21 Gas path Figure 25: Gas path The gas path is in fact the circuit followed by the hot gases emitted by burning wood. This circuit is used to heat the stainless steel oven and the cast iron cooking surface. The primary air supply provided by the pilot feeds the wood combustion. Wood burning in the combustion chamber gives off particles and hot gases heading upwards.
  • Page 22 Blower Operation It is possible to install a fan on this cookstove. See the Parts List section at the end of this manual for the original part number. The blower is installed on the back of the cookstove to increase the airflow through the heat exchanger and improve hot air circulation in the room.
  • Page 23 4. Combustibles Good firewood has been cut to the correct length for the stove, split to a range of sizes and stacked in the open until its moisture content is down to 15% to 20%. DO NOT BURN: • COAL; •...
  • Page 24 Log Length Logs should be cut at least 1" (25 mm) shorter than the firebox so they fit in easily. Pieces that are even slightly too long makes loading the stove very difficult. The most common standard length of firewood is 16" (400 mm). Piece Size Firewood dries more quickly when it is split.
  • Page 25 Here are some facts to consider in estimating drying time: − Firewood bought from a dealer is rarely dry enough to burn, so it is advisable to buy the wood in spring and dry it yourself; − Drying happens faster in dry weather than in a damp climate; −...
  • Page 26 First Use Two things happen when burning the first few fires; the paint cures and the internal components are conditioned. As the paint cures, some of the chemicals vaporize. The vapors are not poisonous, but they smell bad. Fresh paint fumes can also trigger false alarms in smoke detectors. When lighting the heater for the first few times, it may be wise to open doors and windows to ventilate the house.
  • Page 27 Place three or four small, split, dry logs in the firebox. Arrange the kindling wood on the logs in two layers at right angles and place a dozen finely split kindling on the second row. It is possible to use ragged paper but it may not hold in place since it tends to roll while it is burning.
  • Page 28 Rekindling a Fire Generally, when you need to cook, it is time to reload. Remove excess ash from the front of the firebox and bring the ashes forward. Place a new load of wood on, and at the back of the embers.
  • Page 29 On the other hand, too much air can make the fire uncontrollable, creating very high temperatures in the unit as well as in the chimney and seriously damaging them. A reddish glow on the unit and on the chimney components indicates overheating. Excessive temperatures can cause a chimney fire.
  • Page 30 6. Maintenance This cookstove will give many years of reliable service if used and maintained properly. Some of the internal components of the firebox, such as vermiculite and baffle will wear over time under intense heat. Defective parts should always be replaced with original parts. Firing each load hot to begin a cycle will not cause premature deterioration of the cookstove.
  • Page 31 Grills and cast iron cooking surface Clean the grills with a brush and mild soap. To clean the cast iron cooking surface, wipe it with a soft and damp cloth. Do not clean the surface when it is hot. If rust or scratches appear, follow the instructions in section 6.4 Cleaning and painting to repair the surface.
  • Page 32 Glasses The cookstove has two glasses to maintain. The combustion chamber glass has a gasket while the furnace does not. 6.6.1 Cleaning Under normal conditions, the door glass should stay relatively clear. If the firewood is dry enough and the operating instructions in this guide are followed, a whitish, dusty deposit will form on the inner surface of the glass after a week or so of use.
  • Page 33 6.6.2 Replacement The glass used is a ceramic glass, 5/32" (4 mm) thick, tested to reach temperatures up to 1400º  F. The dimensions of the glass are 17 5/8" x 9 9/16". If the glass breaks, it must be replaced by a ceramic glass from SCHOTT with the same specification. Contact your dealer to obtain a genuine replacement part.
  • Page 34 6.6.3 Replacement The glass used is a ceramic glass, 5/32" (4 mm) thick, tested to reach temperatures up to 1400º F. The dimensions of the glass are 17.5" x 5.375". If the glass breaks, it must be replaced by a ceramic glass from SCHOTT with the same specification. Contact your dealer to obtain a genuine replacement part.
  • Page 35 6.6.4 Gasket The glass gasket is flat, adhesive-backed, woven fibreglass. The gasket must be centred on the edge of the glass. Follow the steps of the previous section to remove the glass. Remove the old gasket and clean the glass thoroughly. Peel back a section of the paper covering the adhesive and place the gasket on a table with the adhesive side Stick the end of the gasket to the middle of one edge,...
  • Page 36 6.6.7 Door sealing In order for the stove to bur n at its best efficiency, the door must provide a perfect seal with the firebox. The tightness o f the door seal can be verified by closing and latching the door on a strip of paper. The test must be performed all a round the door.
  • Page 37 6.6.9 Door Alignment To align, open the door and loosen the pressures screws located on the lower and upper hinges of the door using a 3/32” Allen key to free the adjustable hinge rods. Figure 31: Release eccentric hinges Figure 32: Adjust eccentric hinges Using a flat screwdriver, turn the adjustable hinge rods in the direction shown to adjust the doors.
  • Page 38 6.6.10 Gasket It is important to replace the gasket with another having the same diameter and density to maintain a good seal. Remove the door and place it face-down on something soft like a cushion of rags or a piece of carpet. Remove the old gasket from the door.
  • Page 39 Decorative Panels To remove the decorative panel (C), remove the wooden handle (A), located on the side, by unscrewing the screw (B). Unscrew the screws (D), at the back of the decorative panels. Turn the back of the decorative panel (C) towards the outside and push upwards to remove it from the panel support (E).
  • Page 40 Fresh Air Intake Kit Installation Remove the ash drawer (A) and the base front (B) by unscrewing the screws (C). Remove the plate at the back of the base by cutting the micro-joint with pliers. MICRO-JOINT Pass the kit (D) through the base of the product and pass the nozzle through the hole previously cut in the back of the base.
  • Page 41 Lift the kit forward and secure it with the screws (E) at the front and rear of the product. Replace the ash drawer and the base front. Installation and operation manual - Gusto woodburning cookstove Page 41...
  • Page 42 The installation of a fresh air intake kit (D) requires an insulated fresh air intake pipe (F) HVAC type (must meet ULC S110 or UL 181 class 0 or class 1), sold separately. It is mandatory to install the fresh air intake in a mobile home. Refer to air intake kit installation instructions for more details.
  • Page 43 Log retainers installation Installation and operation manual - Gusto woodburning cookstove Page 43...
  • Page 44 6.10 Center molding installation *See center molding installation manual 46390. Page 44 Installation and operation manual - Gusto woodburning cookstove...
  • Page 45 6.11 Optional Blower and Thermodisc Installation A blower and a thermodisc can be installed on the Gusto. Thermodisc allows the blower to operate only when the cookstove is hot enough. See the instructions provided with the thermodisc for more details. Remove the backplate by cutting the knockouts with pliers.
  • Page 46 6.12 Air Tubes And Baffle Installation Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Align the notch in the left end of the tube with the key of the left air channel hole.
  • Page 47 Note that secondary air tubes (B) can be replaced without removing the baffle board (A) and that all tubes are not necessarely identical (look at the part number on the tube). 6.13 Handles installation Insert, in order, the natural wood handle (A), the washers (B) and the nuts (C) into the holes on 7/16"...
  • Page 48 6.14 Mobile Home Installation For a stove on a base, screw the base in place with the proper hardware. *The proper hardware to screw the legs in place is not included. 6.15 Level the product as needed To level the product, first remove the stained wood handle (A), located on the right side, by unscrewing the screws (B).
  • Page 49 Installation and operation manual - Gusto woodburning cookstove Page 49...
  • Page 50 6.16 Exhaust System Wood smoke can condense inside the chimney, forming a inflammable deposit called creosote. If creosote builds up in the system, it can ignite when a hot fire is burned in the stove. A very hot fire can progress to the top of the chimney. Severe chimney fires can damage even the best chimneys.
  • Page 51 N.B. It is possible to remove the chimney after sweeping. The residues will thus all have fallen on top of the oven. You can also remove the chimney before sweeping and make sure to put a container as airtight as possible at the end of the chimney (where it has been unscrewed), to collect the residues that will fall during the sweeping.
  • Page 52 PART B - INSTALLATION 7. General Information Security • Read this manual completely before installing the cookstove. It is important to fully respect the installation instructions. If the cookstove is not correctly installed, it could result in a fire, bodily injuries or even death.
  • Page 53 Regulations Governing the Installation of the Cookstove In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment is to be followed in the absence of local code requirements. In the USA, the ANSI NFPA 211 Standard for Chimneys, Fireplaces, Vents and Solid Fuel-Burning Appliances is to be followed in the absence of local code requirements.
  • Page 54 8. Clearances to Combustible Material The clearances given in this section have been established following test results in accordance with the procedures described in the standards ULC S627 (Canada) and UL 1482 (USA). When this cookstove is installed respecting the indicated minimum clearances or more, the flammable surfaces won’t overheat during normal or even abnormal usage.
  • Page 55 72" 48" 183cm FLUSH 48" 36" 122 cm 92 cm Figure 40: Clearances - Top Figure 41: Clearances - Side Figure 42: Clearances - Corner Installation and operation manual - Gusto woodburning cookstove Page 55...
  • Page 56 APPLIANCE CLEARANCES (INSTALLATION APPLIANCE CLEARANCES (INSTALLATION WITH SINGLE WALL PIPE CONNECTOR) WITH DOUBLE WALL PIPE CONNECTOR) Canada Canada 15" (381 mm) 15" (381 mm) 6" (152 mm) 6" (152 mm) 15" (381 mm) 15" (381 mm) 15" (381 mm) 15" (381 mm) 7.5"...
  • Page 57 Floor Protection This stove is designed to prevent the floor from overheating. However, it must be placed on a non-flammable surface to protect the floor from hot embers that may fall during loading. The floor protection must be a continuous, non combustible material, such as steel with a minimum thickness of 0.015"...
  • Page 58 Clearances Reduction to the Walls and the Ceiling It is often desired to use as little space as possible when installing cookstove. To do this, it is possible to reduce the clearances safely and install the cookstove closer to the walls by permanently installing a heat shield between the cookstove and the flammable material.
  • Page 59 Table 1 : Clearances Reduction Percentages Table CLEARANCES MAY BE REDUCED BY THESE PERCENTAGES TYPE OF SHIELD SIDES AND REAR TOP (CEILING) CAN /USA CAN /USA MIN. MIN. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at least 25 mm (1 in)* 12 in 18 in by non-combustible spacers...
  • Page 60 Clearances for Shield Installation Minimum clearance between the top of 833 mm the appliance and the (32 13/16") unprotected ceiling Shield extension above 500 mm appliance (20") USA 25 mm (1") Minimum space behind the Can. 21 mm shield (7/8") USA 25 mm (1") Clearance at the bottom of Can.
  • Page 61 8.3.1 Mobile Home It is strictly forbidden to install a unit with a single wall pipe in a mobile home. APPLIANCE CLEARANCES WITH DOUBLE DISTANCES FROM PIPE CONNECTOR WALL PIPE CONNECTOR WITH DOUBLE WALL PIPE CONNECTOR Canada Canada 6" (152 mm) 6"...
  • Page 62 8.3.2 Mobile Home With Heat Shield (AC02765, AC02766) APPLIANCE CLEARANCES WITH DOUBLE DISTANCES FROM PIPE CONNECTOR WALL PIPE CONNECTOR WITH DOUBLE WALL PIPE CONNECTOR Canada Canada 3" (76 mm) 3" (76 mm) 6.25" (159 mm) 6.25" (159 mm) 3" (76 mm) 3"...
  • Page 63 9.2.1 Factory-Built Metal Chimneys These sometimes referred ‘high temp’ chimneys because they have the specific characteristics to withstand temperatures that can be created by wood burning stoves. Factory- built chimneys are tested as a system with all the necessary components for installation. The instructions provided with the chimney by its manufacturer are the only reliable source of installation guidelines.
  • Page 64 9.2.3 Masonry Chimneys The stove may also be connected to a masonry chimney, provided the chimney complies with the construction rules found in the building code enforced locally. The chimney must have either a clay liner or a suitably listed stainless steel liner. If the masonry chimney has a square or rectangular liner that is larger in cross-sectional area than a round 6"...
  • Page 65 Venting systems that rise straight up from the stove flue collar provide the best performance. Chimneys that rise inside the warm space of the house tend to provide a small amount of draft even when there is no fire burning. This means that when a fire is lit, the smoke goes up the chimney and strong draft build quickly as the chimney flue warms up.
  • Page 66 Installing the Chimney Connector The chimney connector is the single or double wall pipe installed between the stove flue collar and the chimney breech. Single wall pipe components are available from most hardware and bu ilding supply stores. These components are not usually tested to a particular standard and certified as compliant.
  • Page 67 • The assembly should be as short and direct as possible between the stove and chimney. The use of two 45 degree elbows is often preferable to a single 90 degree elbow because less turbulence is created in the exhaust flow and they result in less horizontal run. •...
  • Page 68 10.2 Installation of Double wall Chimney Connector Important! The connector (A) PL36899 is required, only on a Ventis double wall pipe installation. To install a double wall connector on the appliance, the universal connector supplied with the stove must be installed as shown on the picture bellow.
  • Page 69 Combustion Air For the cookstove draft to work correctly, the room must have an outside or fresh air inlet, with a minimum of 5" diameter, from the house exterior to the room, that is at least sufficient to replenish the volume of air that comes out of the chimney flue. In well insulated houses an air inlet must be fitted through the outer wall that is not exposed to the prevailing winds, depending on the surrounding conditions of the house.
  • Page 70 11.2 Conventional House The safest and most reliable supply of combustion air for a wood stove is from the room in which it is installed. Room air is already preheated so it will not chill the fire, and its availability is not affected by wind pressures on the house.
  • Page 71 Troubleshooting PROBLEM POSSIBLE CAUSES SOLUTION • Draft too low • Check that all the pipes are clean. • Bad air intake adjustment • Modify the chimney: increase the height Oven window • Too much combustible in the or check surrondings. or combustion cookstove.
  • Page 72 Parts List DETAIL D DETAIL E DETAIL F DETAIL A DETAIL B DETAIL C Page 72 Installation and operation manual - Gusto woodburning cookstove...
  • Page 73 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your unit, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
  • Page 74 Item Description AC01211 5"Ø FRESH AIR INTAKE KIT FOR WOOD STOVE ON LEGS PL75864 DECORATIVE PANEL BOTTOM RIGHT PL75862 DECORATIVE PANEL UPPER RIGHT PL75863 DECORATIVE PANEL UPPER LEFT PL75865 DECORATIVE PANEL BOTTOM LEFT 30154 BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A SE75854 FRONT BASE 30094...
  • Page 75 Item Description PL74534 INSULATING PROTECTIVE 21635 17" X 20 5/16" X 1/2" INSULATION AC06950 1'' X 1/8'' X 9' SELF-ADHESIVE GASKET SE75883 OVEN KIT SE75709 OVEN INTERIOR 31224 COOKSTOVE OVEN GRILL PL75709 ASH DRAWER SE46389 GUSTO INSTRUCTION MANUAL KIT AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 31407 SCREW 4 1/4"-20 X 5/8"...
  • Page 76 Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your OSBURN dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
  • Page 77 NOTES : Installation and operation manual - Gusto woodburning cookstove Page 77...
  • Page 78 NOTES : Page 78 Installation and operation manual - Gusto woodburning cookstove...
  • Page 79 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 1-877-356-6663 of information contained in any document obtained from https://www.osburn-mfg.com/en/ unauthorized sources. tech@sbi-international.com...
