Osburn 1600 Owner's Manual

Us environmental protection agency phase ii certified wood insert

Advertisement

250, rue de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3
This  manual  is  available  for  free  download  on  the  manufacturer's  web  site.  It  is  a  copyrighted
document. Re‐sale is strictly prohibited. The manufacturer may update this manual from time to
time  and  cannot  be  responsible  for  problems,  injuries,  or  damages  arising  out  of  the  use  of
information contained in any manual obtained from unauthorized sources.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
OWNER'S MANUAL
1600 MODEL INSERT
Manufactured by : STOVE BUILDER INTERNATIONAL INC.
Tel.: 418 878-3040
Fax: 418 878-3001
www.osburn-mfg.com
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED WOOD
INSERT
OREGON DEPARTEMENT
ENVIRONMENTAL QUALITY
Verified and tested following
ULC S628, UL 907, UL 1482 Standards by:
45084A
14-10-2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Osburn 1600

  • Page 1 OWNER’S MANUAL 1600 MODEL INSERT US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOOD INSERT OREGON DEPARTEMENT ENVIRONMENTAL QUALITY Verified and tested following ULC S628, UL 907, UL 1482 Standards by: Manufactured by : STOVE BUILDER INTERNATIONAL INC. 250, rue de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3 Tel.: 418 878-3040...
  • Page 3: Table Of Contents

    BAFFLE INSTALLATION ......................23   SECONDARY AIR TUBE REPLACEMENT ................24   OSBURN LIMITED LIFETIME WARRANTY ..............25   REGISTER YOU WARRANTY ONLINE To receive full warranty coverage, you will need to show evidence of the date you purchased your insert.
  • Page 4 INTRODUCTION SBI INC., one of the most important wood stove and fireplace manufacturers in Canada, congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood insert. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.
  • Page 5: Technical Specifications

    TECHNICAL SPECIFICATIONS Combustible: Wood Recommended surface: Up to 1800 square feet 42,600 BTU/h Heating Capacity* : E.P.A : Seasoned cordwood: 65,000 BTU/h Optimum efficiency: Average emissions, EPA: 4.4 g/h Metallic Black Color : 6’’ (152 mm) Flue Pipe Diameter : 2100°F (1150 °C) Type de cheminée : Maximum:...
  • Page 6: Installation

    INSTALLATION SAFETY NOTICE  I F THIS INSERT IS NOT PROPERLY INSTALLED A HOUSE FIRE MAY RESULT O REDUCE THE RISK OF FIRE FOLLOW THE INSTALLATION INSTRUCTIONS AILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE BODILY INJURY OR EVEN DEATH ...
  • Page 7: Door Overlay Installation

    DOOR OVERLAY INSTALLATION In order to complete the assembly of your Osburn 1600 wood insert, you need to install the door overlay. See figure 1 below for installation instructions : 1- Position the overlay on the door frame and fix it in place from behind using the 4 screws.
  • Page 8: Door Adjustment

    DOOR ADJUSTMENT In order for your insert to operate properly, the door should be adjusted periodically to provide an air tight fit. To adjust:  Remove the lock pin (spring pin) by pulling and turning it using pliers ("wise grip") ...
  • Page 9 MASONRY & ZERO CLEARANCE REQUIREMENTS The masonry fireplace must meet the minimum code requirements, or NFPA 21,1 or the equivalent for a safe installation. Contact your local Building Inspector for requirements in your area. An inspection of the fireplace should include the following: 1.
  • Page 10 4. CHIMNEY CAPS: Mesh type chimney caps must have provision for regular cleaning, or the mesh should be removed to eliminate the potential of plugging. 5. LINER: The chimney must have an acceptable masonry liner suitable for solid fuel, otherwise a continuous stainless steel liner must be installed. 6.
  • Page 11: Minimum Masonry Opening, Clearances To Combustibles, And Floor Protector

    MINIMUM MASONRY OPENING, CLEARANCES TO COMBUSTIBLES, AND FLOOR PROTECTOR...
  • Page 12 MAXIMUM MAXIMUM MINIMUM MASONRY STANDARD LARGE OPENING FACEPLATE FACEPLATE 21.75" (553 mm) 29" (737 mm) 32" (813 mm) 26" (660 mm) 44" (1118 mm) 50" (1270 mm) 14.5" (368 mm) CLEARANCES 16’’ (406 mm) 10’’ (254 mm) 16’’ (406 mm) 22’’...
  • Page 13: Venting Requirements

    VENTING REQUIREMENTS The flue is a critical component to a satisfactory installation. Your insert will attain its best performance if installed with a flue that generates its own draft. The minimum venting requirement will be the installation of a flue connector from the insert into the first tile of the chimney (see Figure 2.3).
  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS Inspect the fireplace according to the safety information and fireplace requirements and have it cleaned and/or upgraded as necessary. If the installation of the unit renders the existing damper control inaccessible, it will be necessary to either secure the damper wide open or remove it entirely. An inaccessible damper which may fall shut later could cause smoke to enter the room.
  • Page 15 POSITIONING THE UNIT: The more extended the insert, the greater the heat transfer to the room. When installed as an extended insert, the front edge of the air jacket will be installed flush with the fireplace facing. Otherwise the unit can be moved back as much as 3.5"...
  • Page 16 If lag-bolts and anchors are to be used to secure the insert, the hole locations should be marked with the unit in place. Remove the unit and locate the anchors. Remove the faceplate panels from their box and assemble according to these faceplate instructions: Remove the slide from within the air jacket.
  • Page 17 INSTALLATION ON FACEPLATE: Attach the mitred corners of trim together using the corner brackets. Slide the assembled trim over the edge of the faceplate. See Figures 8 and 9. Attach the left and right sides to the top with corner brackets supplied. Slip the trim over the faceplate and snap the eight faceplate trim clips in place (see Figure 8).
  • Page 18 Push the air control (A) in, all the way. Slide the adjustable faceplate sleeve back into its original location until the faceplate fits tightly against the fireplace facing. See Figure 10. One 7/16" (11mm) open end wrench should be used to turn the nut (B), located above the cooktop in the center, up so that it securely fastens the adjustable faceplate sleeve to the top air jacket.
  • Page 19: Operation

    OPERATION Your heating unit was designed to burn wood only; no other materials should be burnt. Wastes and other flammable materials should not be burnt in your wood insert. Any type of wood may be used in your insert, but specific varieties have better energy yields than others.
  • Page 20: Testing Your Wood

    Smaller pieces of wood will dry faster. All logs exceeding 6" in diameter should be split. The wood should not be stored directly on the ground. Air should circulate through the cord. A 24" to 48" air space should be left between each row of logs, which should be placed in the sunniest location possible.
  • Page 21: Heating

    If you move it completely to the left, it is fully close. Your OSBURN insert burnt between .979 kg\h and 4.4 kg\h. of wood during EPA testing. Real operating conditions may give very different results than those obtained in the lab according to the species of wood used, its moisture content, the size and density of the pieces, the length of the chimney, altitude and outside temperature.
  • Page 22: Creosote Formation And Need For Removal

    CREOSOTE FORMATION AND NEED FOR REMOVAL When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool chimney flue of a slow-burning fire. As a result, creosote residue accumulates on the flue lining.
  • Page 23: Maintenance

    Do not abuse the glass door by striking or slamming shut. Do not use the insert if the glass is broken.  If the glass on your insert breaks, replace only with glazing supplied from the OSBURN dealer.
  • Page 24: Baffle Installation

    BAFFLE INSTALLATION firebrick and ceramic wool baffles must be properly in place for correct burning operation. Have any damaged firebricks replaced. Check the firebricks annually for damage and replace if they are broken or damaged. See figure 11 for the firebrick layout. VERMICULITE BAFFLE TUBE Figure 11 - Baffle installation...
  • Page 25: Secondary Air Tube Replacement

    Note that any tube can be replaced without disturbing the baffle. The air tubes are identified for placement as follows: Model Type of tube Osburn 1600 Insert Front ► 22 holes of 1/4"...
  • Page 26: Osburn Limited Lifetime Warranty

    Paint (peeling), gaskets, insulation, firebrick, and ceramic fibre blankets. 1 year *Pictures required Shall your unit or a components be defective, contact immediately your OSBURN dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: ...
