3
BATTERY PACKS
Battery pack replacement
Before replacing the battery pack, push [POWER] for 1 sec. to turn
the power OFF.
• Slide the battery release forward, then pull the battery pack up-
ward with the transceiver facing away from you.
D D BATTERY PACKS
Battery
pack
BP-208
BP-209
BP-210
BP-222
1
*
Operating periods are calculated under the following conditions;
Tx : Rx : standby =5 : 5 : 90,
2
*
Operating period depends on the alkaline cells used.
9
Voltage Capacity
Battery case for AA
(R6)×6 alkaline
7.2 V 1100 mAh
7.2 V 1650 mAh
7.2 V
600 mAh
Charging period
BC-144
BC-146
or
BC-121
N/A
N/A
12 hrs.
1.5 hrs.
18.5 hrs.
2.0 hrs.
6.5 hrs.
1.0 hr.
power save function: auto setting is activated
Battery life*
1
—*
2
7.5 hrs.
11 hrs
4 hrs
