Miller REGENCY 250 Owner's Manual page 8

100 ft (30 m) Or Less
Welding 10 To 60%
Amperes Duty Cycle
100 4
150 3
200 3
250 2
300 1
*Weld cable size (AWG) is based on either a 4 volts or less drop or a current density of at least 300 circular mils per ampere.
1 2
1 in
(26 mm)
Tools Needed:
Table 3-1. Weld Cable Size*
Total Cable (Copper) Length In Weld Circuit Not Exceeding
150 ft
(45 m)
60 Thru 100%
Duty Cycle
4 4
3 2
2 1
1 1/0
1/0 2/0
5 6
7/32 in
Figure 3-5. Male Camlok Connector Assembly
200 ft 250 ft 300 ft
(60 m) (70 m) (90 m)
10 Thru 100% Duty Cycle
3 2
1 1/0
1/0 2/0
2/0 3/0
3/0 4/0
4
3
350 ft 400 ft
(105 m) (120 m)
1 1/0 1/0
2/0 3/0 3/0
3/0 4/0 4/0
4/0 2-2/0 2-2/0
2-2/0 2-3/0 2-3/0
1 Weld Output Cable
Strip insulation as shown.
2 Copper Strip (Two Included)
3 Connector Body
Wrap strip around bare weld cable
(use two on small diameter cable),
and insert into connector body.
4 Setscrew
Tighten setscrew against copper
strip.
5 Handle
6 Pin
Slide handle over connector body
so holes align; secure by tapping
pin into place.
If job requires cable larger than 3/0
AWG, use 2 ft. (610 mm) or shorter
piece of 3/0 AWG cable for Camlok
connector installation. Connect
other end of short cable to larger
weld cable.
