Selecting And Preparing Weld Output Cables - Miller REGENCY 250 Owner's Manual

NOTE
A
C
B
Front
Figure 3-3. Overall Dimensions And Base Mounting Hole Layout

3-3. Selecting And Preparing Weld Output Cables

Tools Needed:
OM-293 Page 4
Overall dimensions (A, B, and C) include lifting eye, handles, hardware, etc.
F
L
D
E
5
10 ft (3 m)
10 ft (3 m)
1
Figure 3-4. Selecting And Preparing Weld Output Cables
J
H
G
3
2
For Example,
Total Cable
Length In Weld
Circuit = 20 ft (6 m)
4
Inches Millimeters
A 23-1/4
B 16
C 22-3/4
D 13
E 12-1/4
F 3/4
G 16-1/16
H 14-29/32
J 5-13/32
K 13/32
L 7/16 Dia.
6 Holes
K
1 Weld Output Cable
Determine total cable length in weld
circuit and maximum welding am-
peres. Use Table 3-1 to select prop-
er cable size.
Use shortest cables possible.
Do not use damaged cables.
2 Terminal Lug
Use lugs of proper amperage ca-
pacity and hole size for connecting
to work clamp and wire feeder.
3 Wire Feeder
Install according to manufacturer's
instructions.
4 Work Clamp
Install onto work cable.
5 Male Camlok Connector
Install onto weld cable as shown in
Figure 3-5.
591
406
578
330
311
19
408
379
137
10
11 Dia.
6 Holes
ST-155 897-A
Ref. S-0336
