2 Connecting to the system
Description
Tboiler
Teg / photo
Tburner
Thw
Troom
Tch
Tout
12V
5V
GND
Description
1 (CH)
2 (HW)
3 (Ign)
4 (Mo)
5 (Mc)
6 (Blo)
7 (Ftan)
8 (Fbur)
STB
N
N1
PE
page 12
PL20110629
INPUTS
Boiler temperature sensor
Exhaust gas temperature sensor or photocell
The temperature sensor burner
The temperature sensor hot water
Room temperature sensor / regulator (CTP)
The temperature sensor central heating
Outdoor temperature sensor (CTZ)
+12V output to supply optional equipment
+5V output to supply optional equipment
Mass electric to connect sensors
OUTPUTS
Central heating circulating pump
Circulating pump for hot water
Burner igniter
Opening the central heating mixer
Closing the central heating mixer
Burner blower
Feeder tank, or if burning wood, it's blower
Burner feeder
Protection STB
Neutral standing
Neutral separable such as by STB
Protective
