Assembly and Operating Instructions for
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
Outback® Oven Grill
RB-H5060
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children and pets away.
CAUTION: Do not use spirit or petrol for lighting or re-lighting! Use only
firelighters complying to EN1860-3!
Do not move the appliance during use.
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
Retain these instructions for future reference.
For Flare-up control please refer to the 'OPERATION' section of this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RB-H5060 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Outback RB-H5060

  • Page 1 Assembly and Operating Instructions for Outback® Oven Grill RB-H5060 Photographs are not to scale. Specifications subject to change without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.
  • Page 2: Parts List

    Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. CODE PART Outback® Oven Grill Hood Hood Handle Hood Heat Indicator and Nuts Assembly HOOD...
  • Page 3: Parts Diagram

    Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice. ST4.0x12 Screw "O" Shaped Spring Washer M4 Cap Nut M4x8 Bolt M6x12 Bolt M6 Cap Nut M6x15 Bolt (White) M6 Nut M6x15 Bolt (Black) Axle R-Spring Clips M4x32 Bolt Hood R-Spring Clips M6x33 Bolt M6x58 Bolt M6x83 Bolt...
  • Page 5 Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Remove any internal components or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 6 Place the Oven Bottom Panel (C11) into the assembled cabinet, as shown. Using ST4.0x12 screws (D1x3pcs) fixed onto the Oven upper door. Attach the Oven Right Planel Assembly (C9) and Side Shelf (C1) to the assembled cabinet using M6x83 Bolts (D9x4pcs),M6x58 Bolts (D8x2pcs) and M6 Cap Nuts (D14x6pcs),as shown.
  • Page 7 Attach the Oven Door Support (C6) to the Oven Door (C5) using Oven Door Support Fixing Pieces (C7x2pcs) , M4x8 Bolts (D2x4pcs) and M4 Cap Nuts (D13x4pcs). Attach the Oven door assembly to the assembled cabinet using M4x32 Bolts (D6x9pcs) and M4 Cap Nuts (D13x9pcs) , as shown.
  • Page 8 Align the Wheels (C17) and Legs, and fixed them with Axles (D10x2pcs) and R clips (D16x2pcs). Place the wheel Hubcaps (C18) onto the outsides of the wheels. Remove the nut and washer pre-set on the Heat Indicator, attach the Heat Indicator (C3) on the Oven upper door, as shown.
  • Page 9 Attach the Body Hinges (C15) to the assembled cabinet using M6x33 Bolts (D7x4pcs), “O”Shaped Spring Washers (D12x4pcs) and M6 Cap Nuts (D14x4pcs). Carefully place the Barbecue body (B1) into the oven, then place the Cooking grill (B2) onto the Barbecue body, as shown.
  • Page 10 Remove the nut and washer pre-set on the Heat Indicator, attach the Heat Indicator (A3) on the Hood, as shown. Upside Left Right Remove the nut and washer pre-set on the Vents, attach the Vents (A4) on the Hood, as shown. Attention! Please make sure that all is Vents clockwise rotation.
  • Page 11 Remove the nut and washer pre-set on the Hood Hinge , attach the Hood Hinge (A5) and Hood Hinge Support (A6) on the Hood, as shown. D3 D12 Attach the Hood Handle (A2) to the Hood using M6x12 Bolts(D3x4pcs), “O”Shaped Spring Washers (D12x4pcs) and M6 Cap Nuts (D14x4pcs), as shown.
  • Page 12 LEFT RIGHT Carefully place the Hood assembly onto the barbecue body. Align the Hood hinge and Body hinge, and fixed them with Hinge Pins (D11) and R Clips(D17). Open the oven door, Place Oven Cooking Grill (B3) into the oven as shown.
  • Page 13 Attach the Charcoal Harrow Handel (C14) onto the Charcoal Harrow (C13) using M6x15 Bolts (D5x2pcs) and M6 Nuts (D15x2pcs). Place the Tool Hooks (C16) onto the Side shelf.
  • Page 14 *Cooking grill extract the instructions* The Charcoal harrow into the gap at the Cooking grill, with the Charcoal harrow to Cooking grill above hook hooked, then lift Cooking grill, as shown!
  • Page 15: Installation

    Important Information Ensure the ash tray is in place before use. Do not move the cooking grill and charcoal Please read these instructions carefully grill until after the appliance has completely before assembly and use of your barbecue. cooled down. Never remove the ash tray whilst the Retain these...
  • Page 16 Preparation Before Cooking Grill Cooking To prevent foods from sticking to the cooking The food on the grill is cooked by the heat surface, please use a long handled brush to produced from the hot charcoal below. The apply a light coat of cooking or vegetable oil natural food juices produced during cooking fall before each barbecuing session.
  • Page 17: Care And Maintenance

    be used for large gatherings, additional care will Never douse the barbecue with water when be required to ensure excessive build up of fat its surfaces are hot. does not occur and cause a fat fire. The time between cleaning may need to be reduced if In order to extend the life and maintain the very fatty foods or cheap meat products are condition...
  • Page 18 Fixings NOTE: All screws and bolts, etc. should be checked and tightened on a regular basis. Storage Ensure the barbecue is properly cooled before covering or storing. Store your barbecue in a cool dry place. When using the barbecue after extended periods storage follow...
  • Page 19 OUTBACK® WARRANTY OUTBACK® barbecues are warranted to the original purchaser against defects in materials and workmanship. OUTBACK® will supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
