CARE AND CLEANING
Removing and Replacing the Oven Door
IMPORTANT
Special door care instructions - The door is heavy. For
safe, temporary storage, lay the door flat with the inside
of the door facing down.
Most oven doors contain glass that can break. Do not
close the oven door until all the oven racks are positioned
correctly in the cavity. Do not hit the glass with bakeware
or any other objects. Scratching, hitting, jarring, or
stressing the glass may weaken its structure, causing an
increased risk of breakage at a later time.
To remove the oven door:
1. Open oven door completely, horizontal with floor
(Figure
11).
2. Pull the door hinge locks on both left and right door
hinges down from the oven frame completely toward
the oven door
(Figure
blade screwdriver may be required.
3. Close the door to approximately 10 degrees from the
door frame
(Figure
13).
4. Firmly grasp both sides of oven door along the door
sides. Do not use the oven door handle
5. Lift the oven door hinge arms over the roller pins
located on each side of the oven frame
To replace oven door:
1. Firmly grasp both sides of oven door along the door
sides. Do not use the oven door handle
2. Holding the oven door at the same angle as the removal
position, seat the hook of the hinge arm over the roller
pins located on each side of the oven door frame
(Figure 13
and
Figure
must be fully seated onto the roller pins.
3. Fully open the oven door, horizontal with floor
(Figure
11).
4. Push the door hinge locks up toward and into the oven
frame on both left and right oven door hinges to the
locked position
(Figure
5. Close the oven door.
16
12). A tool such as a small flat-
(Figure
(Figure
(Figure
14). The hook of the hinge arms
12).
Figure 11: Door hinge location
Figure 12: Door hinge locks
13).
13).
13).
Figure 13: Holding door for removal/replacement
Figure 14: Replacement and location of hinge arm and
roller pin

Oven door

hinge
locations
about
10°
oven
door
hinge
roller
pin
hinge
arm
