Changing Oven Light; Removing/Replacing Lift-Off Oven Door - Frigidaire 318205303 Important Safety Instructions Manual

Wall oven


Table of Contents
oFF oven door
The door is heavy. For safe, temporary storage, lay the
door flat with the inside of the door facing down.
To Remove Oven Door:
1. Open oven door completely (horizontal with floor -
See Figure 1).
2. Pull the door hinge locks on both left and right
door hinges down from the oven frame completely
towards the oven door (See Figure 2). A tool such as
a small flat-blade screwdriver may be required.
3. Firmly grasp both sides of oven door along the door
sides (Do not use the oven door handle - See Figure 3).
4. Close the door to the broil stop position (the oven
door will stop into this position just before fully
5. With the oven door in the broil stop position, lift the
oven door hinge arms over the roller pins located on
each side of the oven frame (See Figure 4).
To Replace Oven Door:
1. Firmly grasp both sides of oven door along the door
sides (Do not use the oven door handle - See Figure 3).
2. Holding the oven door at the same angle as the
removal position, seat the hook of the hinge arm over
the roller pins located on each side of the oven door
frame (See Figure 4). The hook of the hinge arms
must be fully seated onto the roller pins.
3. Fully open the oven door (horizontal with floor - See
Figure 1).
4. Push the door hinge locks up towards and into the
oven frame on both left and right oven door hinges
(See Figure 2) to the locked position.
5. Close the oven door.
Door Hinge locations
with oven door fully open
Figure 1
Oven door
special door care instructions - Most oven doors
contain glass that can break.
Read the following recommendations:
1. Do not close the oven door until all the oven racks
2. Do not hit the glass with pots, pans, or any other
3. Scratching, hitting, jarring or stressing the glass may

cHanging oven ligHt

Be sure the oven is unplugged and all parts are COOL
before replacing the oven light bulb. Do not turn
the oven light on during a self-cleaning cycle. High
temperature will reduce lamp life.
On some models an interior oven light will turn on
automatically when the oven is opened. The oven light
may be turned on when the door is closed by using the
oven light switch located on the Electronic Oven control.
The oven light bulb is covered with a glass shield held
in place by a wire holder. THIS GLASS SHIELD MUST
to replace the light Bulb:
Be sure oven is cool
1. Turn the power off at the main source.
2. Wear a leather-faced glove for protection against
3. Replace bulb with a 40 Watt appliance bulb only.
4. For self-cleaning oven, press wire holder to one side to
Figure 2
and be sure to replace glass shield.
care & cleaning
Figure 3
are fully in place.
weaken its structure causing an increased risk of
breakage at a later time.
possible broken glass.
release glass shield, change bulb
Figure 4
