Product Overview

Controls

Figure 18
1. Forward traction pedal
2. Reverse traction pedal
Traction Pedals
Press the traction forward pedal
Press traction reverse pedal
to assist in stopping when moving forward. Also, allow the
pedal to move or move it to the neutral position to stop the
machine.
Mow/Transport Slide
Using your heel, move the mow/transport slide
to the left to transport and to the right to mow. The cutting
units will only operate in the mow position and not lower
in the transport position.
Important: The mow speed is set at the factory to 9.7
km/h (6 mph). It can be increased or decreased by
adjusting the speed stop screw
Figure 19
1. Speed stop screw
3. Mow/transport slide
4. Tilt-steering lever
(Figure 18) to move forward.
(Figure 18) to move backward or
(Figure
(Figure 19).
Tilt-Steering Lever
Pull the tilt-steering lever
wheel to the desired position. Then push the lever forward
to secure the position.
Ignition Switch
The ignition switch
preheat the engine, has 3 positions: Off, On/Preheat, and
Start. Rotate the key to the On/Preheat position until the
glow-plug indicator light goes out (approximately 7 seconds);
then rotate the key to the Start position to engage the starter
motor. Release the key when the engine starts. The key will
move automatically to the On/Run position. To shut the
engine off, rotate the key to the Off position. Remove the key
from the switch to prevent accidental starting.
1. Parking brake
2. Ignition switch
3. Enable/Disable switch
18)
4. Diagnostic light
5. Lower mow/raise control
lever
6. Hour meter
Throttle
Move the throttle
speed and rearward to decrease the engine speed.
Enable/Disable Switch
Use the enable/disable switch
with the lower mow/raise control lever to operate the
cutterheads. The cutting units cannot be lowered when
the mow/transport lever is in the transport position.
Hour Meter
The hour meter
machine operation. The hour meter starts to function
whenever the key switch is On.
18
(Figure 18) back to tilt the steering
(Figure 20), used to start, stop, and
Figure 20
7. Oil-pressure light
8. Temperature light
9. Light switch
10. Glow-plug indicator light
11. Throttle
12. Alternator light
(Figure 20) forward to increase the engine
(Figure 20) in conjunction
(Figure 20) indicates the total hours of
