CCTV
Model:
Colour Vandal Resistant
20m IR Dome Camera
Before you begin
Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor or outdoor use. Please bear in mind the following points when
choosing a mounting position.
The camera must be positioned so that it will not point directly into the sun (sunrise and
sunset) or any bright light, as this may cause damage to the camera.
Avoid viewing areas where half the area is in bright sunlight and the other half is dark,
such as in the shadow of a building. All types of cameras have difficulty in 'seeing' with
such a large lux level variation.
Do not cut the camera cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the camera by
incorrect voltage or wiring is not covered by the warranty.
Model:
XIR538/592
Colour Vandal Resistant Varifocal
Dome Cameras with 20m Nightvision
XIR538
XIR592
Model:
Colour Vandal Resistant
20m IR Dome Camera
CCTV
