XPD721WIR
Model:
700 TVL Vandal Resistant Day/Night Dome
Before you begin
• Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor or outdoor use. Please bear in mind the following
points when choosing a mounting position.
• The camera must be positioned so that it will not point directly into the sun (sunrise
and sunset) or any bright light, as this may cause damage to the camera.
• Do not cut the camera cables, this will void the warranty.
• Make sure you use only the recommended power supply. Damage caused to the
camera by incorrect voltage or wiring is not covered by the warranty.
Model:
XPD721WIR
700 TVL Vandal Resistant Day/Night Dome
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for XVision XPD721WIR
Summary of Contents for XVision XPD721WIR
-
Page 1: Before You Begin
XPD721WIR Model: 700 TVL Vandal Resistant Day/Night Dome Before you begin • Please unpack the box carefully and identify that all the parts are present. The camera is suitable for indoor or outdoor use. Please bear in mind the following points when choosing a mounting position. -
Page 2: Safety Precautions
Thank you for purchasing this Xvision camera. Before operating this product, please read this instruction manual carefully. 1. Safety Precautions z Use with a 12V DC regulated power supply. z To prevent fire or electrical shock, industry standard wiring should be used for the 12V DC input terminal. -
Page 3: Product Description
2. Product Description The XPD721WIR dome camera is designed for high risk applications and is able to withstand a blow from a 120 pound sledgehammer. It offers very high resolution images of 600 TVL in Colour mode and 700 TVL in B/W mode, with a low lux sensitivity of 0.0003 lux. - Page 4 4. Contents XPD721WIR Camera Screws & Wall Plugs Opening Tool Allen Key Template Wall Plugs & Screws Use of Accessories: 1. OPENING TOOL: Needed for opening up the pipe holes during cabling. 2. ALLEN KEY: For body cover and camera base assembly.
-
Page 5: Product Assembly
5. Product Assembly Dome base Body cover Camera body IR LEDs Dome cover (transparent) Cable hole Mounting Holes Handling the camera: 1. Never attempt to disassemble or modify the camera. 2. If an abnormality should occur, immediately turn off the power and consult your dealer. Cover Removal and Attachment 1. -
Page 6: Installation
6. Installation FIX THE DOME BASE 1. Attach the provided template to where you want to install the camera and drill the holes in the place where the camera is to be installed, then run the power and video cables through the hole. 2. - Page 7 ADJUST THE CAMERA LENS Camera body moves in three ways. It can be paned, tilted and rotated. 4. Adjust the direction so that the lens is pointing at the target. 5. Use the lever to adjust the view angle and focus. Pan 360°...
-
Page 8: Camera Osd Control
7. Camera OSD Control Various camera settings can be adjusted using the OSD buttons located in the dome. Press the Set button to enter the OSD Menu. Down Left Set (Menu) Down Video Test Left Connector OSD Button Control Actions Press this Control For this Action UP, DOWN... -
Page 9: Osd Menu Structure
8. OSD Menu Structure SETUP MENU LENS EXPOSURE SHUTTER SENS-UP D-WDR RETURN WHITE BALANCE AWC SET OUTDOOR INDOOR MANUAL DAY/NIGHT AUTO COLOR 3DNR SPECIAL CAMTITLE D-EFFECT MOTION PRIVACY SNYC LANGUAGE ADJUST SHARPNESS MONITOR OSD COLOR RESET FACTORY RETURN EXIT... -
Page 10: Setup Menu Functions
9. SETUP Menu Functions 1. LENS <Option : DC> This should be left on the default DC setting. 2. EXPOSURE <Option : SHUTTER / AGC / SENS-UP / BLC / D-WDR / RETURN> • SHUTTER: Adjusts shutter settings <AUTO / FLK / MANUAL> - AUTO - Adjusts shutter settings to control the brightness level on screen. - Page 11 9. SETUP Menu Functions continued - HSBLC (Highlight Suppress BLC for Numberplate Recognition) - Select this feature to select masking of bright areas in the image, such as when viewing number plates when car headlights are on. Enter the HSBLC submenu to select an area in the scene which requires masking.
- Page 12 9. SETUP Menu Functions continued 3. WHITE BALANCE (WHITE BALANCE MENU) <Option : AWB / ATW / AWC-SET / OUTDOOR / INDOOR / MANUAL > • AWB: Automatic White Balance (default setting). This feature automatically adjusts the colour temperature of the camera image to match the type of light available, so that white and other colours appear as natural as possible.
- Page 13 9. SETUP Menu Functions continued 6. SPECIAL MENU 6.1 CAM TITLE <Option : ON / OFF> Use the feature to display a title on the monitor. CAM TITLE 0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z / = &...
- Page 14 9. SETUP Menu Functions continued 6.3 MOTION <Option : ON / OFF> This function will transmit an alert signal when it detects motion on screen. MOTION AREA SELECT AREA 1 AREA DISPLAY LEFT/RIGHT WIDTH TOP/BOTTOM HEIGHT SENSITIVITY MOTION VIEW RETURN •...
- Page 15 9. SETUP Menu Functions continued • ON: Activate Privacy. Select the areas to be masked by using the Joystick control. AREA SELECT: Select privacy area number. (AREA 1-8). The area selected will flash on and off visually. - AREA DISPLAY: Turns selected privacy area ON or OFF. Pressing joystick when ON will change the display to set the position and the size of the area.
-
Page 16: Specifications
Dimensions (WxHxD): 150 x 130 x 150mm TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 3 Year warranty.The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
