XVision XP1080B User Manual

Hd ir waterproof fixed ip camera ?with integrated bracket?
Hide thumbs
Table of Contents

Advertisement

Quick Links

XP1080B
HD IR Waterproof Fixed IP Camera （With Integrated Bracket）
User's Manual
Version 3.3.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP1080B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XP1080B

Summary of Contents for XVision XP1080B

  • Page 1 XP1080B HD IR Waterproof Fixed IP Camera （With Integrated Bracket） User’s Manual Version 3.3.1...
  • Page 2 Welcome Thank you for purchasing our IP camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!

  • Page 3: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. This series product can not support these two modes at the same time.
  • Page 4 Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.

  • Page 5: Table Of Contents

    Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Specifications ........................ 2 1.3.1 Performance ......................2 1.3.2 Factory Default Setup ................... 4 Structure ............................ 11 Multiple-function Combination Cable ..............11 Framework and Dimension ..................12 Bidirectional talk......................13 2.3.1 Device-end to PC-end ..................
  • Page 6 Login and Logout ......................21 FAQ ............................24 Appendix Toxic or Hazardous Materials or Elements ............... 25...

  • Page 7: General Introduction

    1 General Introduction 1.1 Overview This series IP camera integrates the traditional camera and network video technology. It adopts audio and video data collection, transmission together. It can connect to the network directly without any auxiliary device. This series IPC uses standard H.264 video compression technology and G.711a audio compression technology, which maximally guarantee the audio and video quality.

  • Page 8: Specifications

     Day/Night mode auto switch.  Built-in IR light. Support IR night vision.  Support picture parameter setup such as electronic shutter and gain setup.  Backlight compensation: screen auto split to realize backlight compensation to adjust the bright.  Support video watermark function to avoid vicious video modification.
  • Page 9 NTSC: NTSC: NTSC: Main stream Main stream Main stream： （ 3M@15fp （ 1080P@30fps, （ 1.3M@30fps, s ,1080P@3 SXGA@30fps, 720P@30fps, 0fps, 1.3M@30fps, 720P@30fps, 704*480@30fps） SXGA@30fp 704*480@30fps）， Extra stream Extra stream （ 704*480@30fps,352*240 1.3M@30fps （ 704*480@30fps,352*240 @30fps） @30fps） 720P@30fp 704*480@3 0fps）， Extra stream （704*480@ 30fps,352*2 40@30fps）...

  • Page 10: Factory Default Setup

    Remote Monitor, PTZ control, system setup, file download, log information, Operation maintenance , upgrade and etc. Video Output 1-channel analogue video output，BNC port. Restore Default Reset button Setup Support AC24V/DC12V power. (Cannot support these two modes at the Power same time.) Power 8W MAX (10W MAX when ICR switch) Consumption...
  • Page 11 Default Setup Setup Item HFW330 HFW320 HFW310 HFW310 HFW3202 ded Bit Bit Rate 8192 I Frame Enable Watermark Watermark DigitalCCTV character Enable Enable Bit stream General type Encode H.264 mode PAL:CIF(352*288) Resolution NTSC:CIF(352*240) PAL:25 Frame Rate （FPS） Stream NTSC:30 Bit Rate Type Recommen 192-1024Kb/S...
  • Page 12 Default Setup Setup Item HFW330 HFW320 HFW310 HFW310 HFW3202 Host Name Ethernet Wire(Default) Card Mode Static Device MAC address when it is shipped out of the factory Address IP Version IPV4 IP Address 192.168.1.108 Subnet 255.255.255.0 Mask TCP/IP Default 192.168.1.1 Gateway Preferred 8.8.8.8...
  • Page 13 Default Setup Setup Item HFW330 HFW320 HFW310 HFW310 HFW3202 SMTP none Server Port Anonymity Disable User Name anonymity Password Sender none Authenticati SMTP(Email) (Encryption mode) Title IPC Message (Subject) Attachment Mail seconds Receiver Email Test Disable，interval=60 minutes Enable UPnP Disable UPnP SNMP v1 Disable...
  • Page 14 Default Setup Setup Item HFW330 HFW320 HFW310 HFW310 HFW3202 Sensitivity Record Enable Channel Record 10 seconds Delay Relay out Enable Alarm Delay 10 seconds Send Email Disable Snapshot Disable Enable Disable Record Enable Channel Record 10 seconds Delay Video Masking Relay out Enable Record...
  • Page 15 Default Setup Setup Item HFW330 HFW320 HFW310 HFW310 HFW3202 Delay Send Email Disable Enable Disable Relay out Enable Card Relay Error 10 seconds Delay Send email Disable Enable Disable Record Enable Record 10 seconds Delay Disconnectio Relay out Enable Relay 10 seconds Delay Enable...
  • Page 16 Default Setup Setup Item HFW330 HFW320 HFW310 HFW310 HFW3202 Date Format Y-M-D Time Format Time Zone GMT+08:00 System Sync Time Disable Date DST Type Week time Start Time 00:00:00 of the first Sunday of the month End Time 00:00:00 of the second Monday of the month Disable NTP Server clock.isc.org...

  • Page 17: Structure

    2 Structure 2.1 Multiple-function Combination Cable You can refer to the following figure for multiple-function combination cable information. See Figure Figure 2-1 Please refer to the following sheet for detailed information. Port Name Function Connection Note DC 12V/AC Power input Power port.

  • Page 18: Framework And Dimension

    Port Name Name Note ALARM_COM Alarm output public port. Alarm output port. It is to output the alarm signal to the alarm device. ALARM_NO NO: normal open alarm output port. It works with the ALARM_COM port. I/O Port Alarm input port 1. It is to receive the on-off signal ALARM_IN1 from the external alarm source.

  • Page 19: Bidirectional Talk

    2.3 Bidirectional talk 2.3.1 Device-end to PC-end Device Connection Please connect the speaker or the MIC to the audio input port of the device. Then connect the earphone to the audio output port of the PC. Login the Web and then click the Audio button to enable the bidirectional talk function. You can see the button becomes orange after you enabled the audio talk function.
  • Page 20 Figure 2-4 Please refer to the following figure for alarm input information. See Figure 2-5. Alarm input: When the input signal is idle or grounded, the device can collect the different statuses of the alarm input port. When the input signal is connected to the 5V or is idle, the device collects the logic “1”.

  • Page 21: Installation

    3 Installation 3.1 Device Installation Please follow the steps listed below to install the device. Please refer to Figure 3-1 for reference.  Please draw the installation holes in the installation surface and then mark three expansion bolts holes in the surface. Insert three bolts in the hole and secure firmly. ...

  • Page 22: Lens Adjustment

    Figure 3-2 3.3 Lens Adjustment Turn counter clockwise to remove the lens cover, now you can see the iris front and rear control rod. The front control rod is to focus and the rear control rod is to zoom. See Figure 3-3. Please turn clockwise to fix the lens cover back firmly.

  • Page 23: Bracket Adjustment

    3.4 Bracket Adjustment You can use a M4 inner hex screw to control the bracket. Please use the inner hex wrench from the installation accessories bag to unfasten the screw. See Figure 3-4.The horizontal angle of the rear cover can rotate 360°, the tilt angle can rotate 90° and the chassis can rotate 360°. Please use the inner hex wrench to secure the screw firmly after you complete the setup.

  • Page 24: Quick Configuration Tool

    4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2 Operation Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 4-1.
  • Page 25 Figure 4-2 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 4-3. Figure 4-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
  • Page 26 Figure 4-4 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.

  • Page 27: Web Operation

    5 Web Operation This series IPC product support the Web access and management via PC. Web includes several modules: monitor channel preview, system configuration, alarm and etc. 5.1 Network Connection Please follow the steps listed below for network connection.  Make sure the IPC has connected to the network properly.
  • Page 28 Figure 5-2 If it is your first time to login in, system pops up warning information to ask you whether install control webrec.cab or not after you logged in for one minute. Please click OK button, system can automatically install the control. When system is upgrading, it can overwrite the previous Web too. If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download.
  • Page 29 Figure 5-4 Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.
  • Page 30 6 FAQ I cannot boot up Please click RESET button for at least five seconds to restore the device. factory default setup. card write Do not set the SD card as the storage media to storage the times schedule record file. It may damage the SD card duration. I cannot use the When disk information is shown as hibernation or capacity is 0, disk as the storage...

  • Page 31: Appendix Toxic Or Hazardous Materials Or Elements

    Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component ○ ○ ○ ○ ○ ○ Case ○ ○ ○ ○ ○ ○ Wire and Cable Packing ○...
