- Page 1 USE AND MAINTENANCE MANUAL SIMPLA 500E ED. 05-2010 ORIGINAL INSTRUCTIONS Doc. 10024476 Ver.
- Page 2 The descriptions contained in this document are not binding. The company therefore reserves the right to make any modifications at any time to elements, details, or accessory supply, as considered necessary for reasons of improvement or manufacturing/commercial requirements. The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.
-
Page 3: Table Of Contents
CONTENTS ON CONSIGNMENT OF THE MACHINE ........................4 INTRODUCTORY COMMENT .............................4 TECHNICAL DESCRIPTION ............................4 SYMBOLS USED ON THE MACHINE ........................5 SYMBOLS USED IN THE MANUAL ...........................7 GENERAL SAFETY REGULATIONS..........................8 MACHINE PREPARATION............................9 1. HANDLING THE PACKED MACHINE ............................ 9 2. HOW TO UNPACK THE MACHINE............................9 3. -
Page 4: On Consignment Of The Machine
On consignment of the machine When the machine is delivered to the customer, an immediate check must be performed to ensure all the material mentioned in the shipping documents has been received, and also to check the machine has not been damaged during transportation. -
Page 5: Symbols Used On The Machine
SYMBOLS USED ON THE MACHINE Tap symbol Indicates the tap lever Indicates the switch of the solenoid valve Symbol denoting base rise/fall Indicates the base rise/fall lever Brush symbol Indicates the brush motor switch Symbol denoting suction motor Indicates the suction motor switch Symbol denoting squeegee rise/fall Indicates the squeegee lever Symbol denoting brake... - Page 6 SYMBOLS USED ON THE MACHINE Indicates the handlebar height adjustment lever Indicates the master switch Hooking symbol Indicates the hooking points and the load direction Open book symbol Used to tell the operator to read the manual before using the machine...
-
Page 7: Symbols Used In The Manual
SYMBOLS USED IN THE MANUAL Warning symbol Read carefully the sections marked with this symbol, for the safety of the operator and the machine Indicates danger of gas exhalation and leakage of corrosive liquids Indicates the danger of fire Do not go near with free flames... -
Page 8: General Safety Regulations
When disposing of consumption materials, observe the laws and regulations in force When your COMAC machine has reached the end of its long working life, dispose of the materials it contains (especially oils, batteries and electronic components) in an appropriate manner, and bearing in mind that the... -
Page 9: Machine Preparation
MACHINE PREPARATION 1. HANDLING THE PACKED MACHINE The machine is contained in specific packaging with a pallet for the handling with fork trucks. It is not possible to place more than two packages on top of each other. The total mass of the packed machine is 105 kg per Simpla 45-50 The overall dimensions of the package are: A: 1150 mm B: 610 mm C: 1250 mm 2. -
Page 10: Assembling The Squeegee
MACHINE PREPARATION ASSEMBLING THE SQUEEGEE For packaging reasons, the squeegee is supplied disassembled from the machine, and must be assembled as shown in the figure, inserting the small column of the squeegee into the coupling mechanism until the lever is triggered. Insert the squeegee tube in the appropriate sleeve, ensuring that the tube lies to the right of the lifting cable. -
Page 11: Solution Tank
MACHINE PREPARATION SOLUTION TANK Remove the filler cap and check that the solution filter, on the bottom left, is fitted properly. DETERGENT SOLUTION Fill the solution tank with clean water at a temperature no greater than 50°C and add liquid detergent in the proper concentration, following the instructions of the manufacturer. -
Page 12: Work
WORK PREPARING TO WORK 1. Carry out the operations to prepare the machine 2. Connect the plug to the power supply. 3. Press the solenoid valve switch (4) 4. Press the suction switch (5) 5. Press the brush switch (6) 6. -
Page 13: Overflow Device
WORK OVERFLOW DEVICE The machine is fitted with a float which intervenes when the recovery tank is full, causing the suction tube to close. In this case, it is necessary to empty the recovery tank, removing the drainage tube cap. ATTENTION! this operation must be carried out using gloves to protect against contact with dangerous solutions FORWARD MOVEMENTS... -
Page 14: At The End Of The Work
AT THE END OF THE WORK At the end of the work, and before carrying out any type of maintenance: 1. Turn off the tap by means of the lever (1) 2. Raise the base by means of the lever (2) 3. -
Page 15: Daily Maintenance
DAILY MAINTENANCE CLEANING THE RECOVERY TANK 1. Pull out the pipe on the front of the recovery tank 2. Remove the drainage cap and empty the tank ATTENTION! this operation must be carried out using gloves to protect against contact with dangerous solutions 3. -
Page 16: Solution Filter Cleaning
DAILY MAINTENANCE SOLUTION FILTER CLEANING 1. Loosen the solution tank cap 2. Remove the filter by pulling the cover upward, clean it thoroughly 3. Reassemble everything by pushing until the cover of the filter casing snaps closed CLEANING THE SQUEEGEE Check the squeegee is always clean, for better drying results. -
Page 17: Replacing The Squeegee Rubbers
DAILY MAINTENANCE REPLACING THE SQUEEGEE RUBBERS Check the state of wear and tear of the squeegee rubbers and, if necessary, replace them. To replace it you must: 1. unthread the squeegee tube from the sleeve 2. push the release lever and unthread the small right-hand column 3. -
Page 18: Weekly Maintenance
WEEKLY MAINTENANCE CLEANING THE SQUEEGEE TUBE Every week, or whenever suction seems to be unsatisfactory, check the squeegee tube is not obstructed. To clean it, proceed as follows: 1. Unthread the tube from the sleeve on the squeegee 2. Remove the other end from the recovery tank 3. -
Page 19: Troubleshooting
TROUBLESHOOTING INSUFFICIENT WATER ON THE BRUSH 1. Check that the tap (1) is turned on 2. Check there is water in the solution tank. 3. Check the solenoid valve switch is on THE MACHINE DOES NOT CLEAN WELL 1. Check the state of wear and tear of the brush and, if necessary, replace it (the brush must be replaced when the bristles are about 15 mm long). -
Page 20: Disposal
DISPOSAL ATTENTION! The product must be disposed of in the appropriate differentiated waste collection at the end of its useful life. -
Page 21: Choosing And Using The Brushes
This type of dragging device is recommended above all for machines with more than one brush, where the centring of the abrasive discs is difficult TABLE FOR CHOOSING THE BRUSHES 404653 404654 SIMPLA 500E 405631 405632 ABRASIVE Pad locking... -
Page 22: Ec Declaration Of Conformity
COMAC (SHANGHAI) MACHINES Ltd. Through the trustee appointed under the European Community: COMAC S.p.A. declares under its sole responsibility that the products SIMPLA 500E SCRUBBING MACHINE comply with the requirements of the following Directives: 2006/42/EC: Machinery Directive 2006/95/EC: Low Voltage Directive...
