Daewoo DLT-26C2 Service Manual page 94

Service part list
LOC PART CODE PART NAME
D45 DMMBD1204B DIODE CHIP
D46 DMMBD1204B DIODE CHIP
D48 DFM405—-C DIODE CHIP
D49 DFM405—-C DIODE CHIP
D50 DBAV99ML-B DIODE CHIP
D51 DM2FM3—-C DIODE CHIP SCHOTTKY
D52 DM2FM3—-C DIODE CHIP SCHOTTKY
D53 DZ02W8R2VA DIODE CHIP ZENER
D54 DZ02W8R2VA DIODE CHIP ZENER
D55 DZ02W8R2VA DIODE CHIP ZENER
D56 DZ02W8R2VA DIODE CHIP ZENER
D70 DZ02W5R6VA DIODE CHIP ZENER
D71 DZ02W5R6VA DIODE CHIP ZENER
JP5 4859201360 CONN HDMI
L1 HLC100K03B L CHIP COIL
L10 HFF300C00A F CHIP FERRITE BEAD
L11 HFF300C00A F CHIP FERRITE BEAD
L12 HFF300C00A F CHIP FERRITE BEAD
L13 HFFH1M501B F CHIP FERRITE BEAD
L14 HFF300C00A F CHIP FERRITE BEAD
L15 HFF300C00A F CHIP FERRITE BEAD
L16 HFF300C00A F CHIP FERRITE BEAD
L17 HFF300C00A F CHIP FERRITE BEAD
L18 HFFH1M501B F CHIP FERRITE BEAD
L19 HFF300C00A F CHIP FERRITE BEAD
L2 HFF300C00A F CHIP FERRITE BEAD
L20 HFF300C00A F CHIP FERRITE BEAD
L23 HFFH1M501B F CHIP FERRITE BEAD
L24 HFFH1M501B F CHIP FERRITE BEAD
L25 HFF300C00A F CHIP FERRITE BEAD
L26 HLC470KECE L CHIP COIL
L27 HLC470KECE L CHIP COIL
L29 HLC100K03B L CHIP COIL
L3 HFF300C00A F CHIP FERRITE BEAD
L30 HLC100K03B L CHIP COIL
L31 HLC470KECE L CHIP COIL
L32 HLC100J00A L CHIP COIL
L33 HLC100J00A L CHIP COIL
L34 HLC470KECE L CHIP COIL
L35 HFFH1M501B F CHIP FERRITE BEAD
L36 HFF600C01A F CHIP FERRITE BEAD
L37 HFF600C01A F CHIP FERRITE BEAD
L38 HFF600C01A F CHIP FERRITE BEAD
L39 HFF600C01A F CHIP FERRITE BEAD
L4 HFF300C00A F CHIP FERRITE BEAD
L40 HFF600C01A F CHIP FERRITE BEAD
L41 HFF600C01A F CHIP FERRITE BEAD
L42 HFF600C01A F CHIP FERRITE BEAD
L43 HFF600C01A F CHIP FERRITE BEAD
L44 HFF600C01A F CHIP FERRITE BEAD
L45 HLC479K05C L CHIP COIL
L46 HFF600C01A F CHIP FERRITE BEAD
L47 HFF600C01A F CHIP FERRITE BEAD
L49 HFF600C01A F CHIP FERRITE BEAD
L5 HFF300C00A F CHIP FERRITE BEAD
L50 HFF600C01A F CHIP FERRITE BEAD
L58 HFF600C01A F CHIP FERRITE BEAD
L59 HFF600C01A F CHIP FERRITE BEAD
L6 HFF300C00A F CHIP FERRITE BEAD
L60 HFF600C01A F CHIP FERRITE BEAD
L61 HFF600C01A F CHIP FERRITE BEAD
L62 HFF600C01A F CHIP FERRITE BEAD
L63 HFF600C01A F CHIP FERRITE BEAD
L64 HFFMMZ400A F CHIP FERRITE BEAD
L65 HFFMMZ400A F CHIP FERRITE BEAD
L66 HFFMMZ400A F CHIP FERRITE BEAD
L67 HFFMMZ400A F CHIP FERRITE BEAD
L68 HFFMMZ400A F CHIP FERRITE BEAD
L69 HFFMMZ400A F CHIP FERRITE BEAD
L7 HFF300C00A F CHIP FERRITE BEAD
DESCRIPTION
MMBD1204
MMBD1204
FM405
FM405
BAV99ML
M2FM3 M2F TYPE
M2FM3 M2F TYPE
Z02W8.2V
Z02W8.2V
Z02W8.2V
Z02W8.2V
Z02W5.6V
Z02W5.6V
51V019S-36WT-A1R
10UH K NLCV25T-PF
30 OHM PBY 2012
30 OHM PBY 2012
30 OHM PBY 2012
HH-1M3216-501J
30 OHM PBY 2012
30 OHM PBY 2012
30 OHM PBY 2012
30 OHM PBY 2012
HH-1M3216-501J
30 OHM PBY 2012
30 OHM PBY 2012
30 OHM PBY 2012
HH-1M3216-501J
HH-1M3216-501J
30 OHM PBY 2012
47UH K 1280
47UH K 1280
10UH K NLCV25T-PF
30 OHM PBY 2012
10UH K NLCV25T-PF
47UH K 1280
10UH NLC322522
10UH NLC322522
47UH K 1280
HH-1M3216-501J
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
30 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
4.7UH K NLC322522T
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
30 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
30 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
60 OHM PBY 2012
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
30 OHM PBY 2012
-94-
LOC PART CODE PART NAME
L70 HFFMMZ400A F CHIP FERRITE BEAD
L71 HFFMMZ400A F CHIP FERRITE BEAD
L72 HFFMMZ400A F CHIP FERRITE BEAD
L73 HFFMMZ400A F CHIP FERRITE BEAD
L74 HFFMMZ400A F CHIP FERRITE BEAD
L75 HFFMMZ400A F CHIP FERRITE BEAD
L76 HFF600C01A F CHIP FERRITE BEAD
L8 HFF300C00A F CHIP FERRITE BEAD
L9 HFF300C00A F CHIP FERRITE BEAD
P13 4859295120 CONN WAFER
P14 4859295220 CONN WAFER
P3 4859293820 CONN WAFER
Q1 T2SA1037KB TR CHIP
Q10 T2SC2412KB TR CHIP
Q11 T2SC2412KB TR CHIP
Q12 T2SC2412KB TR CHIP
Q13 T2SC2412KB TR CHIP
Q14 T2SC2412KB TR CHIP
Q15 T2SC2412KB TR CHIP
Q16 T2SC2412KB TR CHIP
Q17 T2SC2412KB TR CHIP
Q18 T2SA1037KB TR CHIP
Q19 T2SC2412KB TR CHIP
Q2 T2SC2412KB TR CHIP
Q20 T2SA1037KB TR CHIP
Q21 T2SC2412KB TR CHIP
Q26 T2SA1037KB TR CHIP
Q27 T2SA1037KB TR CHIP
Q3 T2SC2412KB TR CHIP
Q4 T2SC2412KB TR CHIP
Q5 T2SC2412KB TR CHIP
Q6 T2SC2412KB TR CHIP
Q7 T2SC2412KB TR CHIP
Q8 T2SC2412KB TR CHIP
R10 HRFT750JBA R CHIP
R100 HRFT184JBA R CHIP
R101 HRFT223JBA R CHIP
R104 HRFT103JBA R CHIP
R107 HRFT103JBA R CHIP
R108 HRFT681JBA R CHIP
R112 HRFT682JBA R CHIP
R114 HRFT103JBA R CHIP
R115 HRFT153JBA R CHIP
R116 HRFT751JBA R CHIP
R119 HRFT222JBA R CHIP
R12 HRFT103JBA R CHIP
R120 HRFT201JBA R CHIP
R123 HRFT221JBA R CHIP
R124 HRFT470JBA R CHIP
R126 HRFT103JBA R CHIP
R128 HRFT101JBA R CHIP
R129 HRFT102JBA R CHIP
R130 HRFT101JBA R CHIP
R133 HRFT000JBA R CHIP
R136 HRFT101JBA R CHIP
R137 HRFT101JBA R CHIP
R138 HRFT101JBA R CHIP
R139 HRFT101JBA R CHIP
R140 HRFT151JBA R CHIP
R142 HRFT102JBA R CHIP
R143 HRFT102JBA R CHIP
R144 HRFT105JBA R CHIP
R146 HRFT101JBA R CHIP
R147 HRFT470JBA R CHIP
R148 HRFT470JBA R CHIP
R149 HRFT470JBA R CHIP
R15 HRFT302JBA R CHIP
R150 HRFT470JBA R CHIP
R151 HRFT470JBA R CHIP
R152 HRFT103JBA R CHIP
DESCRIPTION
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
40 OHM MMZ 2012S
60 OHM PBY 2012
30 OHM PBY 2012
30 OHM PBY 2012
12505WS-05A00
12505WS-06A00
GT121-31P-TD-A 31P ST
2SA1037AKT146-R
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SA1037AKT146-R
2SC2412K-T146-BR
2SC2412K-T146-BR
2SA1037AKT146-R
2SC2412K-T146-BR
2SA1037AKT146-R
2SA1037AKT146-R
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
2SC2412K-T146-BR
1/10 75 OHM J 1608
1/10 180K OHM J 1608
1/10 22K OHM J 1608
1/10 10K OHM J 1608
1/10 10K OHM J 1608
1/10 680 OHM J 1608
1/10 6.8K OHM J 1608
1/10 10K OHM J 1608
1/10 15K OHM J 1608
1/10 750 OHM J 1608
1/10 2.2K OHM J 1608
1/10 10K OHM J 1608
1/10 200 OHM J 1608
1/10 220 OHM J 1608
1/10 47 OHM J 1608
1/10 10K OHM J 1608
1/10 100 OHM J 1608
1/10 1K OHM J 1608
1/10 100 OHM J 1608
1/10 0 OHM J 1608
1/10 100 OHM J 1608
1/10 100 OHM J 1608
1/10 100 OHM J 1608
1/10 100 OHM J 1608
1/10 150 OHM J 1608
1/10 1K OHM J 1608
1/10 1K OHM J 1608
1/10 1M OHM J 1608
1/10 100 OHM J 1608
1/10 47 OHM J 1608
1/10 47 OHM J 1608
1/10 47 OHM J 1608
1/10 3K OHM J 1608
1/10 47 OHM J 1608
1/10 47 OHM J 1608
1/10 10K OHM J 1608
