Daewoo DLT-26C2 Service Manual page 89

Service part list
DLT-37C3
LOC PART CODE PART NAME
ZZ100 48B5655J12 TRANSMITTER REMOCON
ZZ110 PTACPWG262 ACCESSORY AS
60 4850Q00910 BATTERY
M212 4852177601 COVER BOTTOM
M681 4856819300 CLAMP WIRE
M821 4858219401 BAG INSTRUCTION
M861 4.86E+08 MANUAL INSTRUCTION
P801A 48599PM005 CORD POWER AS
ZZ120 PTBCSHG262 COVER BACK AS
M211 4852177501 COVER BACK
M211C 4855944700 DECO TERM B
M388 4853829200 FRAME WALL KIT
M388A 7172401452 SCREW TAPPTITE
ZZ130 PTPKCPG262 PACKING AS
M801 4858071600 BOX CARTON
M811 485819CT00 PAD
M822 4858215001 BAG P.E
ZZ140 PTCACAG262 CABINET AS
J10A 4859006761 CABLE LVDS
M191 4851958700 SHIELD CASE AS
M201A 7173301052 SCREW TAPPTITE
M211A 7172401452 SCREW TAPPTITE
M211B 7172401652 SCREW TAPPTITE
M211C 7172401452 SCREW TAPPTITE
M321 4853297000 BRKT STAND
M321A 7172401452 SCREW TAPPTITE
M322 4853296700 BRKT STAND BOX
M322A 7172401452 SCREW TAPPTITE
M381A 7178300852 SCREW TAPPTITE
M382 4853829800 FRAME SURPORT
M382A 7003400651 SCREW MACHINE
M383 4853829400 FRAME SIDE T
M383A 7172401452 SCREW TAPPTITE
M383B 7172401452 SCREW TAPPTITE
M384 4853829600 FRAME SIDE B
M384A 7172401452 SCREW TAPPTITE
M384B 7172401452 SCREW TAPPTITE
M384C 4856815900 CLAMP WIRE
M385 4853830000 FRAME SIDE L/R
M385A 7172401452 SCREW TAPPTITE
M491B 7172401452 SCREW TAPPTITE
M541 4855421200 SPEC PLATE
M681 4956800200 CLAMP WIRE
M721A 7178300852 SCREW TAPPTITE
M723 4857255905 SHIELD JACK
M723A 7178300852 SCREW TAPPTITE
P803B 4850712S11 CONNECTOR
P803C 4850712S09 CONNECTOR
V901 485LD00370 LCD PANEL
V902 4850M14510 MODULE POWER
ZZ200 PTFMSJG262 MASK FRONT AS
M201 4852094001 MASK FRONT
M201A 4857743800 CUSION PANEL
M561 4855625700 MARK BRAND
M591 4855945400 DECO PLATE
ZZ210 PTSPPWG262 SPEAKER AS
SP01 48A8317000 SPEAKER SYSTEM
SP01A 4856017800 SCREW SPKR FIX
SP02 48A8317000 SPEAKER SYSTEM
SP02A 4856017800 SCREW SPKR FIX
SP03A 7173301052 SCREW TAPPTITE
SP04A 7173301052 SCREW TAPPTITE
ZZ250 PTSNSWG229 STAND AS
M387 4853831201 FRAME STAND
M387A 7115401552 SCREW TAPPING
M520 4851957501 COVER ASSY
ZZ290 PTMPMSG262 PCB MAIN MANUAL AS
100 2193110012 SOLDER WIRE
200 2193110024 SOLDER WIRE
300 2291050623 FLUX SOLDER LF
DESCRIPTION
R-55J12(AAA)
DLT-37C3LMBD
R03/NN
HIPS BK
NYLON 66
L.D.P.E T0.05X280X470
ENGLISH
UK LP-61L+LS-60=2.0M(CORE)
DLT-37C3LMBD
HIPS BK
PC 0.25T
SECC T=2.0
TT2 TRS 4X14 MFZN BK 3CR
DLT-37C3LMBD
DW-3
EPS
PE FOAM t0.5x1200x1150
DLT-37C3LMBD
LPL:FMW1214A-31A+FH10001-3
7256400+5944605
TT2 BIN 3X10 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X16 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
SECC T1.6
TT2 TRS 4X14 MFZN BK 3CR
SECC T1.0
TT2 TRS 4X14 MFZN BK 3CR
TT2 WAS 3X8 MFZN BK 3CR
SECC T1.2
BIN 4X6 MFZN 3CR
SECC T1.2 (LPL)
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
SECC T1.6 (LPL)
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
EGI T0.4+TUBE+PIE 3.2
SECC T1.2 (LPL)
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
P.E 149X59
WS-A-2-19
TT2 WAS 3X8 MFZN BK 3CR
AL 1100 T=1.0 (A-6 : SL-50
TT2 WAS 3X8 MFZN BK 3CR
20022HS-12S+20022HS-12S+UL
20022HS-12S+20022HS-12S+UL
LC370WX1-SL01
FEL-37H
DLT-37C3LMBD
HIPS BK
PVC 400 X 10 T=1.0
SILVER DIA-CUTTING(DOUBLE
PC T2.0
DLT-37C3LMBD
SS-57165F01CR
SWRM+SECC 3CR
SS-57165F01CR
SWRM+SECC 3CR
TT2 BIN 3X10 MFZN BK 3CR
TT2 BIN 3X10 MFZN BK 3CR
DLV-37C3LMBS
ABS BK
FLT 4X15 MFZN BK 3CR
STAND SUB ASSY (NORMAL SPR
DLT-37C3LMBD
SAC3000 •'3.0MM (LFA3C0-W3
SAC3005 •'1.6MM (LFA3-107-
SV-PBF-304P(0.823)
-89-
LOC PART CODE PART NAME
400 2291050312 FLUX SOLVENT
C0N1 4859200440 CONN PCMCIA
JP1 4859112950 JACK SCART
JP10 4859105340 JACK S-VHS
JP11 4859117450 JACK PIN
JP2 4859112950 JACK SCART
JP3 4859117550 JACK PIN
JP4 4959102340 JACK PHONE
JP6 4959200160 CONN D-SUB
JP7 97P6316100 JACK HEAD PHONE
JP8 4859201170 CONN OPTICAL SENSOR
JP9 4859201460 CONN D-SUB 9P
M321 4853294100 BRKT POWER SW
M321A 7172401452 SCREW TAPPTITE
M371 4853748800 RETA PCB
M372 4956800200 CLAMP WIRE
M381 4855218900 PLATE LOWER
M381B 7178301051 SCREW TAPPTITE
M381C 7178301051 SCREW TAPPTITE
M381D 7008300851 SCREW MACHINE
M381E 4856815900 CLAMP WIRE
M381F 4956800200 CLAMP WIRE
P13A 4850705S34 CONNECTOR
P14A 4850706S49 CONNECTOR
P4 4859284420 CONN WAFER
P5 4959240520 CONN WAFER
P6 4859285020 CONN WAFER
P6A 4850709S21 CONNECTOR
P7 4859284920 CONN WAFER
P8A 4850704S86 CONNECTOR
P9 4859295520 CONN WAFER
TU1 4859731230 TUNER DIGITAL
U10 125L8005PC IC FLASH MEMORY
U11 1M24C32BN6 IC EEPROM
U3 1M24C04BN6 IC EEPROM
U31 14C64WBN6- IC EEPROM
X2 5XJ14R31AE CRYSTAL QUARTZ
Z1 5PK9650M— FILTER SAW
Z2 5PK3953M— FILTER SAW
ZZ200 PTMPJ2G262 PCB MAIN CHIP B AS
C10 HCBK104KBA C CHIP CERA
C100 HCBK104KBA C CHIP CERA
C105 HCBK104KBA C CHIP CERA
C12 HCQK220JBA C CHIP CERA
C13 HCQK220JBA C CHIP CERA
C132 HCBK104KBA C CHIP CERA
C136 HCBK104KBA C CHIP CERA
C14 HCQK220JBA C CHIP CERA
C145 HCBD105KBA C CHIP CERA
C15 HCBK472KBA C CHIP CERA
C16 HCBK472KBA C CHIP CERA
C164 HCBK104KBA C CHIP CERA
C166 HCBK223KBA C CHIP CERA
C168 HCBK223KBA C CHIP CERA
C17 HCBK102KBA C CHIP CERA
C171 HCBK104KBA C CHIP CERA
C172 HCBK104KBA C CHIP CERA
C176 HCBK104KBA C CHIP CERA
C177 HCBD105KBA C CHIP CERA
C182 HCBK104KBA C CHIP CERA
C183 HCBK104KBA C CHIP CERA
C184 HCBK104KBA C CHIP CERA
C185 HCBK104KBA C CHIP CERA
C186 HCBK104KBA C CHIP CERA
C187 HCBK104KBA C CHIP CERA
C188 HCBK104KBA C CHIP CERA
C189 HCBK222KBA C CHIP CERA
C19 HCBK102KBA C CHIP CERA
C190 HCBK153KBA C CHIP CERA
C191 HCBK221KBA C CHIP CERA
DESCRIPTION
S-3000
PC68PRA5513XZ
DSSM-0378 STR
DSW-10 (STRAIGHT)
DPSS-0173S(3P ST SHIELD)
DSSM-0378 STR
DPSE-0375S
SPJ-358H(3.5 STRAIGHT)
SHF-015-B111-22/BR2-J0.6
DHSE-9959
OJ107A-T050-SHS
SHRA0209011
SECC 1T
TT2 TRS 4X14 MFZN BK 3CR
NYLON 66
WS-A-2-19
"SECC, T=1.2"
TT2 WAS 3X10 MFZN 3CR
TT2 WAS 3X10 MFZN 3CR
WAS 3X8 MFZN 3CR
EGI T0.4+TUBE+PIE 3.2
WS-A-2-19
20017HR-05+12505HS-05+USW=
20017HR-06+12505HS-06+USW=
SMW250-03
SMW250-02
SMW250-09
SMH250-09+SMH250-09+ULW=30
SMW250-08
YH025-04+YH025-04+ULW=300
4602-02MV2-60-1 PLUG 2P ST
TD1318AF/IHP-3(DV-IF-H-P)
MX25L8005PC-15G 8M 8-DIP
M24C32WRN6
M24C04WRN6
M24C64-WBN6
HC-49/S 14.31818MHZ 30PPM
K9650M
K3953M
DLT-37C3LMBD
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V CH 22PF J 1608
50V CH 22PF J 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V CH 22PF J 1608
10V X7R 1MF K 1608
50V X7R 4700PF K 1608
50V X7R 4700PF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.022MF K 1608
50V X7R 0.022MF K 1608
50V X7R 1000PF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
10V X7R 1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 2200PF K 1608
50V X7R 1000PF K 1608
50V X7R 0.015MF K 1608
50V X7R 220PF K 1608
