Daewoo DLT-26C2 Service Manual page 71

Service part list
DLT-32C3
LOC PART CODE PART NAME
ZZ100 48B5655J12 TRANSMITTER REMOCON
ZZ110 PTACPWG233 ACCESSORY AS
60 4850Q00910 BATTERY
M212 4852176101 COVER BOTTOM
M681 4856819300 CLAMP WIRE
M821 4858219401 BAG INSTRUCTION
M861 485862100 MANUAL INSTRUCTION
P801A 48599PM005 CORD POWER AS
ZZ120 PTBCSHG300 COVER BACK AS
M211 4852177001 COVER BACK
M211A 4857818702 CLOTH BLACK
M384 4853829200 FRAME WALL KIT
M384A 7172401452 SCREW TAPPTITE
ZZ130 PTPKCPG300 PACKING AS
M681 4856812400 BAND PP AUTO
M801 4858071300 BOX CARTON
M811 485819CR00 PAD
M822 4858215701 BAG P.E
ZZ140 PTCACAG300 CABINET AS
J10A 4859006761 CABLE LVDS
M191 4851958700 SHIELD CASE AS
M201B 7173301052 SCREW TAPPTITE
M201C 7173301052 SCREW TAPPTITE
M201E 7003400651 SCREW MACHINE
M201F 4856815910 CLAMP WIRE
M211A 7172401452 SCREW TAPPTITE
M211B 7172401652 SCREW TAPPTITE
M211C 7172401452 SCREW TAPPTITE
M321 4853296800 BRKT STAND
M321A 7172401452 SCREW TAPPTITE
M322 4853296900 BRKT STAND BOX
M322A 7172401452 SCREW TAPPTITE
M322B 7172401452 SCREW TAPPTITE
M382 4853829102 FRAME BAR
M382B 7172401452 SCREW TAPPTITE
M491B 7172401452 SCREW TAPPTITE
M541 4855421200 SPEC PLATE
M591 4855944702 DECO TERM B
M721A 7178300852 SCREW TAPPTITE
M723 4857255905 SHIELD JACK
M723A 7178300852 SCREW TAPPTITE
M723B 7178300852 SCREW TAPPTITE
P803B 4850712S11 CONNECTOR
P803C 4850712S09 CONNECTOR
V901 485LD00321 LCD PANEL
V902 4850M14410 MODULE POWER
ZZ200 PTFMSJG300 MASK FRONT AS
M201 4852093701 MASK FRONT
M561 48556260SD MARK BRAND
M591 4855945000 DECO PLATE
ZZ210 PTSPPWG233 SPEAKER AS
P4A 4850703S82 CONNECTOR
P5A 4850702N34 CONNECTOR
SP01 4858318510 SPEAKER
SP02 4858318510 SPEAKER
ZZ250 PTSNSWG300 STAND AS
M213 4852177301 COVER STAND BASE
M383 4853831001 FRAME STAND
M383A 7172401452 SCREW TAPPTITE
M521 4855219100 PLATE BASE STAND
M521A 7115401051 SCREW TAPPING
M521C 4852937500 RUBBER BOTTOM
ZZ270 PTUNSWG300 PCB UNION AS
100 2193110012 SOLDER WIRE
200 2193110024 SOLDER WIRE
300 2291050623 FLUX SOLDER LF
400 2291050312 FLUX SOLVENT
IC291 1TS0P34838 IC PREAMP
LED2 DSPR39MVW- LED
M232 4852333201 PANEL CTRL
DESCRIPTION
R-55J12(AAA)
DLT-32C6LMBD
R03/NN
ABS BK
NYLON 66
L.D.P.E T0.05X280X470
ENGLISH
UK LP-61L+LS-60=2.0M(CORE)
DLT-32C3LMBD
HIPS BK
FELT T0.7 L=350 W=15
SECC T=2.0
TT2 TRS 4X14 MFZN BK 3CR
DLT-32C3LMBD
T1.1XW17MMXL770M
DW-3
EPS
PE FOAM t0.5x1050x950
DLT-32C3LMBD
LPL:FMW1214A-31A+FH10001-3
7256400+5944605
TT2 BIN 3X10 MFZN BK 3CR
TT2 BIN 3X10 MFZN BK 3CR
BIN 4X6 MFZN 3CR
EGI T0.4+TUBE+PIE 4.2
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X16 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
SECC T1.6
TT2 TRS 4X14 MFZN BK 3CR
SECC T1.0
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
SECC T=1.2(A-2 FINAL:LPL P
TT2 TRS 4X14 MFZN BK 3CR
TT2 TRS 4X14 MFZN BK 3CR
P.E 149X59
PVC T0.25 (SL-500T)
TT2 WAS 3X8 MFZN BK 3CR
AL 1100 T=1.0 (A-6 : SL-50
TT2 WAS 3X8 MFZN BK 3CR
TT2 WAS 3X8 MFZN BK 3CR
20022HS-12S+20022HS-12S+UL
20022HS-12S+20022HS-12S+UL
LC320W01-SL01
FEL-3226H
DLT-32C3LMBD
HIPS BK
SILVER DIA-CUTTING(DOUBLE
PC T2.0
DLT-32C6LMBD
SMH250-03+YRT205+YRT110+US
SMH250-02+YRT205+YRT110+US
SP-45165F01C
SP-45165F01C
DLT-32C3LMBD
HIPS BK
ABS BK
TT2 TRS 4X14 MFZN BK 3CR
SECC T2.0
FLT 4X10 MFZN 3CR
CR60 BK PHI 18.0 X T 3.0
DLT-32C3LMBD
SAC3000 •'3.0MM (LFA3C0-W3
SAC3005 •'1.6MM (LFA3-107-
SV-PBF-304P(0.823)
S-3000
TSOP34838SJ
SPR-39MVW (DUAL)
HIPS BK
-71-
LOC PART CODE PART NAME
M491 4854964311 BUTTON CH
M491A 7178301051 SCREW TAPPTITE
P911A 4859299720 CONN WAFER
P912B 4859299820 CONN WAFER
ZZ200 PTUNJ0G300 PCB UNION RHU AS
ZZ200 PTUNJBG300 PCB UNION M-10 AS
ZZ200 PTUNJRG300 PCB UNION RADIAL AS
SW201 5S50101Z90 SW TACT
SW202 5S50101Z90 SW TACT
SW203 5S50101Z90 SW TACT
SW204 5S50101Z90 SW TACT
SW205 5S50101Z90 SW TACT
SW206 5S50101Z90 SW TACT
SW207 5S50101Z90 SW TACT
ZZ200 PTUNJAG300 PCB UNION AXIAL AS
A001 4859815360 PCB UNION
C997 CCZJ1H104Z C CERA
R901 85801050GY WIRE COPPER
R902 RD-AZ152J- R CARBON FILM
R903 RD-AZ432J- R CARBON FILM
R904 85801050GY WIRE COPPER
R905 RD-AZ152J- R CARBON FILM
R906 RD-AZ432J- R CARBON FILM
R907 RD-AZ113J- R CARBON FILM
ZZ290 PTMPMSG233 PCB MAIN MANUAL AS
100 2193110012 SOLDER WIRE
200 2193110024 SOLDER WIRE
300 2291050623 FLUX SOLDER LF
400 2291050312 FLUX SOLVENT
C0N1 4859200440 CONN PCMCIA
JP1 4859112950 JACK SCART
JP10 4859105340 JACK S-VHS
JP11 4859117450 JACK PIN
JP2 4859112950 JACK SCART
JP3 4859117550 JACK PIN
JP4 4959102340 JACK PHONE
JP6 4959200160 CONN D-SUB
JP7 97P6316100 JACK HEAD PHONE
JP8 4859201170 CONN OPTICAL SENSOR
JP9 4859201460 CONN D-SUB 9P
M321 4853294100 BRKT POWER SW
M321A 7172401452 SCREW TAPPTITE
M371 4853748800 RETA PCB
M372 4956800200 CLAMP WIRE
M381 4853829001 FRAME MAIN PCB
M381B 7178301052 SCREW TAPPTITE
M381C 7008300851 SCREW MACHINE
M381D 4856815900 CLAMP WIRE
P13A 4850705S34 CONNECTOR
P14A 4850706S49 CONNECTOR
P4 4859284420 CONN WAFER
P5 4959240520 CONN WAFER
P6 4859285020 CONN WAFER
P6A 4850709S21 CONNECTOR
P7 4859284920 CONN WAFER
P8A 4850704S86 CONNECTOR
P9 4859295520 CONN WAFER
TU1 4859731230 TUNER DIGITAL
U10 125L8005PC IC FLASH MEMORY
U11 1M24C32BN6 IC EEPROM
U3 1M24C04BN6 IC EEPROM
U31 14C64WBN6- IC EEPROM
X2 5XJ14R31AE CRYSTAL QUARTZ
Z1 5PK9650M— FILTER SAW
Z2 5PK3953M— FILTER SAW
ZZ200 PTMPJ2G233 PCB MAIN CHIP B AS
C10 HCBK104KBA C CHIP CERA
C100 HCBK104KBA C CHIP CERA
C105 HCBK104KBA C CHIP CERA
C12 HCQK220JBA C CHIP CERA
DESCRIPTION
ABS GY
TT2 WAS 3X10 MFZN 3CR
20017WR-05A
20017WR-06A
DLT-32C3LMBD
DLT-32C3LMBD
DLT-32C3LMBD
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
DLT-32C3LMBD
246X197 D1B
50V F 0.1MF Z AXL(1608)
1/0.5 TIN COATING
1/6 1.5K OHM J
1/6 4.3K OHM J
1/0.5 TIN COATING
1/6 1.5K OHM J
1/6 4.3K OHM J
1/6 11K OHM J
DLT-32C6LMBD
SAC3000 •'3.0MM (LFA3C0-W3
SAC3005 •'1.6MM (LFA3-107-
SV-PBF-304P(0.823)
S-3000
PC68PRA5513XZ
DSSM-0378 STR
DSW-10 (STRAIGHT)
DPSS-0173S(3P ST SHIELD)
DSSM-0378 STR
DPSE-0375S
SPJ-358H(3.5 STRAIGHT)
SHF-015-B111-22/BR2-J0.6
DHSE-9959
OJ107A-T050-SHS
SHRA0209011
SECC 1T
TT2 TRS 4X14 MFZN BK 3CR
NYLON 66
WS-A-2-19
SECC T=1.2 (A-2 : 32C1/32C
TT2 WAS 3X10 MFZN BK 3CR
WAS 3X8 MFZN 3CR
EGI T0.4+TUBE+PIE 3.2
20017HR-05+12505HS-05+USW=
20017HR-06+12505HS-06+USW=
SMW250-03
SMW250-02
SMW250-09
SMH250-09+SMH250-09+ULW=30
SMW250-08
YH025-04+YH025-04+ULW=300
4602-02MV2-60-1 PLUG 2P ST
TD1318AF/IHP-3(DV-IF-H-P)
MX25L8005PC-15G 8M 8-DIP
M24C32WRN6
M24C04WRN6
M24C64-WBN6
HC-49/S 14.31818MHZ 30PPM
K9650M
K3953M
DLT-32C6LMBD
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V X7R 0.1MF K 1608
50V CH 22PF J 1608
