Page 1 LCD TELEVISION INSTRUCTION MANUAL DLT-26C2 DLT-26C3 DLT-32C1 DLT-32C2 DLT-32C3 DLT-37C3...
Page 2 Caution RISK OF ELECTRIC SHOCK CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning ﬂash with arrowhead symbol, within an equilateral triangle, is in- tended to alert the user to the presence of uninsulated “dangerous voltage”...
Page 3: Important Safeguards
Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. Read, Retain and Follow All Instructions Read all safety and operating instructions before operating the TV. Retain them safely for future reference. Follow all operations and instructions accordingly.
Page 4: Replacement Parts
Important Safeguards 13. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
Page 5 This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user’s own safety, and the proper operation of the product. WARNING In case of an accident, please unplug the unit from the outlet immediately. To reduce the risk of electric shock, do not remove cover or back.
Page 6 This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user’s own safety, and the proper operation of the product. CAUTION Please keep the user’s manual in a safe place for future reference. Do not put volatile substance-such as benzene, naphtha- near the product since it may cause a change in the product’s colour.
Page 7: Table Of Contents
Table of Contents Installation and Maintenance Antenna Connection ....... 10 Video Connection .
Page 8: Supplied Accessories
Accessories Make sure that the following accessories are provided with the product. AC CORD AC cord Microﬁber Sheet (Only 32C1) (When you install wall mounting you setup cover bottom like upper picture). Note : • You should follow the hanger instruction manual to install a TV set on the wall. Supplied Instruction manual Cable Holder...
Page 9 The method of wire arrangement (32C1, 26/32/37C3) 1. Assemble the cable holder enclosed on the back of TV (picture 1). (ASSEMBLY METHOD: After you push the ”A” (prominence part of cable holder) in the hole, rotate the cable holder clockwise as an angle of 90°.
Page 10: Antenna Connection
Connection 1. Connect the feeder cable of the antenna to the combining adapter. WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong antenna con- 2. Connect the combining adapter to the antenna input at the left side of the TV set. WHEN USING THE COMBINING ADAPTER : You may obtain the combining adapter at your closest Service Center.
Page 11 Such community TV Antenna installation may be found in most of co-op apartments. When a coaxial cable is used : Plug the coaxial cable to the antenna socket, and ﬁx it ﬁrmly by turning it to the right. Antenna socket on the wall When a feeder cable is used : Plug the coaxial cable to the antenna socket, and ﬁx it ﬁrmly by turning it to the right.
Page 12: Outdoor Antenna Connection
Connection Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses. Single Antenna Connection VHF Antenna UHF Antenna Separate Antenna Connection. VHF Antenna In case of coaxial cable In case of feeder cable UHF Antenna Antenna Outdoor Antenna Connection Back of the tv set Antenna socket at the left side...
Page 13: Video Connection
Video Connection Connecting with an External Source You may connect an S-Video input to enjoy clearer and brighter picture images. You can make the connection with the AV3 input. Note : If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is recom- mended for better picture quality.
Page 14: Camcorder & Video Game Connection
Camcorder & Video Game Connection Watching the Camcorder Recording or Video Game on TV 1. Prepare the S-video and RCA connector. 2. These connectors connect to S-video or AV 3 as shown in the picture below. 3. Turn on the TV set and camcorder/video game. 4.
Page 15: Dvd Player/Stb(Set Top Box) Connection
When connecting with a component cable and Euro SCART cable Note : • When you connect with the component video, please check the colour of the cable between the DVD and TV set. When connecting with a S-VHS cable and RCA cable Note : If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is recom- mended for better picture quality.
Page 16 DVD player / STB (Set Top Box) connection When connecting with a HDMI cable Back of the tv set Set Top Box When connecting with a component cable Back of the tv set Set Top Box Note : • When you connect with the component video, please check the colour of the cable between the Set Top Box and TV set.
Page 17: Pc Connection
When connecting with PC(D-Sub) cable. 1. Adjust PC resolution to available resolution in LCD TV. 2. Connect between PC and TV set using the D-Sub and Audio cable like below the picture. 3. Turn on the PC and TV set. 4.
Page 18 PC Connection PC CONNECTION NOTES: 1) The resolution of the TV set is the best at 1360 x 768 (WXGA). 2) If there is a [Vertical Frequency] setting menu in the [Screen] Menu of the PC, adjust the frequency to 60Hz. 3) If the PC resolution is too high, it may be hard to read letters.
Page 19: Cable Tv Broadcasting Connection
External Input Connection Source Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. You may make the connection to any of the Component input and SCART input AV1, AV2. Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver.
Page 20: Connect With The Dolby Digital Amp
Connect with the Dolby Digital AMP. If you connect the optical output to a Dolby digital AMP, you can listen to better sound. Optical output Dolby Digital AMP Woofer Center Surround L Surround R...
Page 21: Name Of Each Part
Front Panel (DLT-26C2/DLT-32C2) Buttons on the TV set have the same functions as those of the remote controller. Control Key Buttons. ① Buttons : Each time you press this button, the TV will cycle through: TV / AV1 / AV2 / AV3 / S-Video / Component / PC /HDMI / DVB-T ②...
Page 22 Each Part Front Panel (DLT-26C3/DLT-32C1/DLT-32C3/DLT-37C3) Buttons on the TV set have the same functions as those of the remote controller. Control Key Buttons. ① Button : Each time you press this button, the TV will cycle through: TV / AV1 / AV2 / AV3 / S-Video / Component / PC /HDMI / DVB-T ②...
Page 23 Name of Each Part Side and Rear Panel Left Side of the TV set Rear Panel...
Page 24: Parts Of The Remote Controller
Parts of the Remote Controller POWER MUTE DVB/Analog MULTIMEDIA PQRS WXYZ PICTURE MENU OK/SELECT GUIDE SUB TITLE CANCEL/EXIT STILL RECALL ASPECT EDIT SLEEP S.EFFECT MGDI (MUTE) : Press this button, and the sound goes off. Press again, and the sound returns. (POWER) : TV on/off button in Stand-By mode.
Page 25 POWER MUTE DVB/Analog MULTIMEDIA PQRS WXYZ PICTURE MENU OK/SELECT GUIDE SUB TITLE CANCEL/EXIT STILL RECALL ASPECT EDIT SLEEP S.EFFECT MGDI Parts of the Remote Controller 18. STILL : Press this button to freeze the picture Note : It works only AV 1, AV 2, AV 3, S-VIDEO, Analog TV, DVB-T 19.
Page 26: Method To Use Basic Menu
Method To Use Basic Menu - The basic menu appears on the screen if you press the menu button of the remote control. - There are 5 items Picture, Sound, Screen, Utilities, and Setup in the basic menu. - Each item has sub-items under it. If the desired item is selected, the relevant sub-items are displayed upward. 1.
Page 27: To Watch Tv
On/Off, Number, Mute, RECALL[ ], Buttons with same name in the main body performs the same function. Press the “ON/OFF” button of the front or right side of the set or the “POWER” button of Remote controller. • You can also turn on the TV using “ PR ” or digit key in the ST- BY mode.
Page 28 To Watch TV 1. Press the “ (ON/OFF)” button of the front or right side of the set or the “POWER” button of Remote controller. • The Stand-by LED lamp turns on in red colour. • Press “ PR ” buttons of the main body or “POWER” button of the remote control.
Page 29: Setting Up Tv Stations
- All stations that can be received are stored by this method. It is recommended that you use Auto tuning during instal- lation of this set. 1. Press the “Menu” button to select the Setup menu. • Move the selection bar to the Setup menu with “ UP/DOWN ” buttons.
Page 30: Manual Tuning
Setting Up TV The Manual tuning menu shows you information as follows: - System information: GB, France, E/Euro, W/Euro. - Program number, Station name and Real channel number, frequency. 1. Locate the selection bar on the Manual tuning at the Setup menu.
Page 31 4. Searching for channel. • Move the selection bar to the Program with “ UP/DOWN ” but- tons. • Select a programme number you want to tune ﬁnely with the “ LEFT/RIGHT ” buttons. • Move the selection bar to the System and select a system which you want.
Page 32 Setting Up TV The Edit menu shows you information as follows: - Program position assignment: Program number, Real channel number, Station name and Skip. 1. Skipping the Programs. • Move to EDIT in the Setup menu and press the “RIGHT ” but- ton.
Page 33: Selection Of Av And Multimedia Input Signal
When watching video, Camcorder, DVD, Cable TV with AV - See page 12 for connection method of TV and “Video” . - When pressing ” ” button on the TV set, screen changes as follows: Analog => AV1 => AV2 => AV3 => S-Video => Component => PC => HDMI => DVB-T => Analog 1.
Page 34 Selection of AV and Multimedia Input Signal When connecting PC, STB, DVD with Multimedia 1. Press the “MULTIMEDIA” button on the remote controller. • Screen changes as follows whenever pressing the “MULTIMEDIA” button. Component => PC => HDMI => Component COMPONENT PR 19 HDMI &...
Page 35: Screen Adjustment
When setting up various screen modes - The user may select various screens designed for a good picture without adjusting the brightness, contrast or colour individually. 1. Pressing the “PICTURE” button. • Screen changes as follows whenever pressing the “PICTURE” button. Normal =>...
Page 36 Screen Adjustment When adjusting the screen to taste - You can enjoy various screens by adjusting Brightness, Contrast, Colour, Sharpness, etc to the user’s taste. 1. Select Picture by pressing the “Menu” button. • The menu screen appears as follows. 2.
Page 37 Adjustment of Screen Size in TV and AV mode - Randomly change the size of the screen. - The AUTO screen operates when power is turned on ﬁrstly. 1. Pressing the “ASPECT” button on the remote controller. • The screen changes as below whenever pressing the “Aspect” button. Auto =>...
Page 38 Screen Adjustment Adjustment of Screen in PC mode 1. Select the PC from the Screen menu. • Press the “RIGHT ” button and the PC mode appears. • Press the ” UP/DOWN ” buttons to adjust the horizontal position of displayed image. 2.
Page 39 5. Auto Adjust. • Move to Auto Adjust in the PC menu. • Press the “ LEFT/RIGHT ” buttons to detect optimal resolution automatically. Note : • You can adjust the PC menu only in the PC mode. • During the Auto Adjust, you must not alter a screen on the monitor. •...
Page 40: Sound Adjustment
Sound Adjustment When selecting various sound modes 1. Sound mode selects what you want. STILL RECALL ASPECT • Press the “S. EFFECT” button, then the sound status changes as followed : Flat => 3D Panorama => Super Bass => Speech => Flat EDIT SLEEP S.EFFECT...
Page 41 - The user can enjoy various the sounds by adjusting Sound Effect, AVC, Balance and Equalizer. 1. Select Auto Volume Control. • Move to AVC in the Sound menu. • Select either AVC ON or OFF using the “ LEFT/RIGHT ” but- tons.
Page 42 Sound Adjustment 1. Mono Sound Selection. • In Stereo reception if the stereo is weak, you can switch to MONO by pressing the “ (MTS)” button. Then the colour of “MONO” character will be change to Black. In Mono reception the depth of sound is improved.
Page 43: Utilities
1. Setup of Child Lock. • Move to Child Lock in the Utilities menu. • Select Child Lock to “On/Off” using the “ LEFT/RIGHT ” button. Note : • This prevents the use of the TV set without the remote control. •...
Page 44: Adjustment Of Time
1. Setting the Clock. • Move to Timer in the Utilities menu. • To go to the Time, press the “RIGHT ” button. • Place the cursor to Hour / Minute with “ LEFT/RIGHT ” buttons. • Set the Hour / Minute with the “ UP/DOWN ” buttons. •...
Page 45: Teletext
Teletext Teletext SWITCHING TELETEXT ON/OFF Press the TELETEXT button ( The index page or the page viewed last will appear. Repeatedly press the TELETEXT button the mode in the following order: TV => TELETEXT => Double Window => TV Note : Teletext works only in TV/AV mode. COLOUR BUTTONS IN TOP/FLOF TELETEXT A red, green, yellow and blue ﬁeld is shown at the bottom of the screen.
Page 46: Channel Banner
Channel Banner - The channel banner displays information about a channel number, name, broadcasting time, audio service and more. You can see this banner by pressing “OK/SELECT” button or “ UP/DOWN ” buttons on the Remote Control. BBC ONE ② ①...
Page 47 2. View the Channel Information. • You can view information of all channels currently listed services. • Press “ UP/DOWN ” buttons to preview the program informa- tion of the listed channels. • Press “ LEFT/RIGHT ” buttons to display the now/next program information of the watching channel.
Page 48: Setting Up Dvb-T System
Setting up DVB-T System 1. Press the “MENU” button to select the DVB-T Setup. • Move the selection bar to the DVB-T Setup menu with “ UP/ DOWN ” buttons and press the “RIGHT ” button. 2. Select the “Auto Setup” . •...
Page 49 The System menu shows you information as follows: - Banner Display time, Subtitle Language, Audio Language. - Common Interface, Signal Strength, Software Update. 1. Setting Banner Display Time. • Move to System in the DVB-T Setup. • To go to the Banner Display Time, press the “RIGHT ” button.
Page 50 Setting up DVB-T System 4. Common Interface. • Place the selection bar on Common Interface and press the “RIGHT ” button. • The Common Interface menu provides the Informa- tion of CI card inserted into the CI slot, at the left side of the TV.
Page 51 Note : • The whole downloading process may take about 10~15 minutes according to signal status. • If you want to start the installation press the “OK/SELECT” button to start. WARNING : • During the installation process don’t power off TV. Note : •...
Page 52: Electronic Program Guide(Epg)
Electronic Program Guide (EPG) - The DTV Electronic Program Guide(EPG) displays program informa- tion about each channel, up to seven days ahead. - You can edit your own proﬁles, and record programs. - By pressing the “GUIDE” button to access EPG directly, you can see all channels broadcasting now.
Page 53: Electronic Program Guide (Epg)
3. Category / Theme Select. • Press the “BLUE” multi function button to display the Category list. • Press the “YELLOW” multi function button to change the Category/Theme list. • Press “ LEFT/RIGHT ” buttons to select the Catego- ry/Theme. •...
Page 54: Common Interface Module Menu
Common Interface Module Menu - The Common Interface menu allows you to access a pay-per-view (PPV) service on your TV set. This feature operates once you have obtained a CI module and a viewing card. If you want to know the pay-per-view (PPV) service in your region, please contact your nearest PPV provider for detail.
Page 55 3. Module Information. • You can see information of CI Module. - Serial number, SAP number, Manufacturer, SW version, FW version. 4. Smart Card Information. • This Feature displays the serial number and a term of validity of the module. 5.
Page 56: Digital Teletext (Mheg5)
Digital Teletext - Many broadcasters provide a Digital Teletext service in form of a dedicated Teletext channel. When you switch to a Digital Teletext service, the image you see can contain graphics and text, laid out and controlled in a manner decided by the broadcaster.
Page 57: User Proﬁle
Exit Proﬁle Exit Program Guide Today 12 : 54 Oct 27 2005 User Proﬁle Proﬁle conﬁguration Proﬁles All Servicess DAEWOO ﬁve 15 abc1 16 OVC 17 UKTV GOLD 23 bid tv 24 prince-drop tv 25 TCM 26 UK TV Style Save Exit Proﬁle...
Page 58: Troubleshooting
Troubleshooting Please check the following items before asking for repair service. Symptom Neither picture nor sound Picture is OK but no sound Sound is OK, but no colour. The picture has image. Picture has “snow noise” . Stripes on picture. Bad stereo or Dual sound.
Page 59 Some Problems will only occur when viewing DVB channels. Due to the different techniques involved in digital reception, DVB signal quality can be poor even if you appear to have a strong signal when viewing analogue programmes. The DVB system requires a good quality signal to provide the best picture. When viewing analogue pictures, interference such as signal reﬂection from nearby buildings or mountains causes ‘ghosting’...
Page 60 Troubleshooting Symptom “OUT OF RANGE” appears on the screen “NO SIGNAL” appears on the screen. Image is not clear. Image is not centered. • AFTER SALES SERVICE Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present.
Page 61: Standard Of Product
Model Features LCD Panel Screen Size Aspect Ratio Resolution Pixel Pitch Contrast Ratio TV System Receiving System Stereo System Power Consumption Max. Power Source Dimension (W x H x D) Set Dimension Model Features LCD Panel Screen Size Aspect Ratio Resolution Pixel Pitch Contrast Ratio...
