Service part list
LOC PART CODE PART NAME
R733 HRFT000JBA R CHIP
R734 HRFT000JBA R CHIP
R74 HRFT101JBA R CHIP
R75 HRFT220JBA R CHIP
R76 HRFT472JBA R CHIP
R77 HRFT472JBA R CHIP
R78 HRFT473JBA R CHIP
R79 HRFT103JBA R CHIP
R8 HRFT750JBA R CHIP
R80 HRFT103JBA R CHIP
R81 HRFT101JBA R CHIP
R83 HRFT101JBA R CHIP
R84 HRFT101JBA R CHIP
R85 HRFT101JBA R CHIP
R86 HRFT750JBA R CHIP
R87 HRFT750JBA R CHIP
R89 HRFT101JBA R CHIP
R9 HRFT750JBA R CHIP
R90 HRFT750JBA R CHIP
R91 HRFT101JBA R CHIP
R92 HRFT103JBA R CHIP
R93 HRFT333JBA R CHIP
R94 HRFT153JBA R CHIP
R95 HRFT220JBA R CHIP
R96 HRFT470JBA R CHIP
R97 HRFT183JBA R CHIP
R99 HRFT101JBA R CHIP
RP1 HRTS8E101J R CHIP ARRAY
RP10 HRTS8E330J R CHIP ARRAY
RP11 HRTS8E330J R CHIP ARRAY
RP12 HRTS8E330J R CHIP ARRAY
RP13 HRTS8E330J R CHIP ARRAY
RP14 HRTS8E330J R CHIP ARRAY
RP16 HRTS8E330J R CHIP ARRAY
RP17 HRTS8E330J R CHIP ARRAY
RP18 HRTS8E330J R CHIP ARRAY
RP19 HRTS8E330J R CHIP ARRAY
RP2 HRTS8E101J R CHIP ARRAY
RP20 HRTS8E330J R CHIP ARRAY
RP3 HRTS8E101J R CHIP ARRAY
RP4 HRTS8E101J R CHIP ARRAY
RP7 HRTS8E330J R CHIP ARRAY
RP8 HRTS8E330J R CHIP ARRAY
RP9 HRTS8E330J R CHIP ARRAY
U1 1WM8521HCD IC CHIP STREO DAC
U12 1TDA8931TQ IC CHIP AUDIO AMP
U13 1TDA1308TC IC CHIP HEDPHONE DRI
U14 1TDA8931TQ IC CHIP AUDIO AMP
U16 1CD74HC53D IC CHIP LOGIC
U18 1APW1172-D IC CHIP DC-DC CONVER
U19 1G9171863C IC CHIP REGULATOR
U2 1CD74HC52D IC CHIP LOGIC
U20 1LM317BD2E IC CHIP REGULATOR
U21 1G9117T63C IC CHIP REGULATOR
U22 1G9173363C IC CHIP REGULATOR
U23 1LM317BD2E IC CHIP REGULATOR
U24 1G9173363C IC CHIP REGULATOR
U25 1APW1172-D IC CHIP DC-DC CONVER
U26 1G9117T63C IC CHIP REGULATOR
U27 1G108433TD IC CHIP REGULATOR
U28 1G108418TD IC CHIP REGULATOR
U29 1S281632DD IC CHIP SDRAM
U30 1NX8314HSQ IC CHIP MEDIA PROCES
U33 1320ET70NQ IC CHIP FLASH MEMORY
U34 1ST232CD-Q IC CHIP DRIVE
U35 1C1GU04GWD IC CHIP INVERTER
U36 1CD74HC53D IC CHIP LOGIC
U37 1C1GU04GWD IC CHIP INVERTER
U38 1A1334BTSD IC CHIP AUDIO DAC
U39 110046AHTD IC CHIP CHANNEL DECO
DESCRIPTION
1/10 0 OHM J 1608
1/10 0 OHM J 1608
1/10 100 OHM J 1608
1/10 22 OHM J 1608
1/10 4.7K OHM J 1608
1/10 4.7K OHM J 1608
1/10 47K OHM J 1608
1/10 10K OHM J 1608
1/10 75 OHM J 1608
1/10 10K OHM J 1608
1/10 100 OHM J 1608
1/10 100 OHM J 1608
1/10 100 OHM J 1608
1/10 100 OHM J 1608
1/10 75 OHM J 1608
1/10 75 OHM J 1608
1/10 100 OHM J 1608
1/10 75 OHM J 1608
1/10 75 OHM J 1608
1/10 100 OHM J 1608
1/10 10K OHM J 1608
1/10 33K OHM J 1608
1/10 15K OHM J 1608
1/10 22 OHM J 1608
1/10 47 OHM J 1608
1/10 18K OHM J 1608
1/10 100 OHM J 1608
1/16 8P 100 OHM 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 100 OHM 3216
1/16 8P 33 OHM J 3216
1/16 8P 100 OHM 3216
1/16 8P 100 OHM 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
1/16 8P 33 OHM J 3216
WM8521HC
TDA8931T
TDA1308T
TDA8931T
CD74HC4053M96
APW1172
G9117-18T63U 1.8V SOT-223
CD74HC4052M96
LM317BD2T ADJ 1.2V 37V 1.5
G9117T63U ADJ SOT-223
G9117-33T63U 3.3V SOT-223
LM317BD2T ADJ 1.2V 37V 1.5
G9117-33T63U 3.3V SOT-223
APW1172
G9117T63U ADJ SOT-223
GT1084-33T53UF 3.3V TO-263
G1084-18T53UF 1.8V TO-263
K4S281632F-UC75
PNX8314HS
M29W320ET70N6E
ST232CD
74AHC1GU04GW
CD74HC4053M96
74AHC1GU04GW
UDA1334BTS
TDA10046AHT
-88-
LOC PART CODE PART NAME
U40 1C1MAXSP2Q IC CHIP DE-SCRAMBLER
U41 1ST890BDRC IC CHIP CURRENT SWIT
U42 1VC573ADBD IC CHIP LATCH
U43 1VC573ADBD IC CHIP LATCH
U44 1C245APW-D IC CHIP TRANSCEIVER
U5 1TDA9886T- IC CHIP IF
U6 128164SB5D IC CHIP DDR SDRAM
U7 TFDS4953-C FET CHIP
U8 1T96889LDQ IC CHIP MICOM(+VIDEO
X5 5Z27R000TF CRYSTAL OSCILLATOR
ZZ310 PTUNSWG233 PCB UNION AS
100 2193110012 SOLDER WIRE
200 2193110024 SOLDER WIRE
300 2291050623 FLUX SOLDER LF
400 2291050312 FLUX SOLVENT
IC290 1TS0P34838 IC PREAMP
LED1 DSPR39MVW- LED
M232 4852333201 PANEL CTRL
M491 4854964311 BUTTON CH
M491A 7178301051 SCREW TAPPTITE
P911A 4859299720 CONN WAFER
P912A 4859299820 CONN WAFER
ZZ200 PTUNJ2G233 PCB UNION CHIP B AS
ZZ200 PTUNJ0G233 PCB UNION RHU AS
ZZ200 PTUNJBG233 PCB UNION M-10 AS
ZZ200 PTUNJRG233 PCB UNION RADIAL AS
SW201 5S50101Z90 SW TACT
SW202 5S50101Z90 SW TACT
SW203 5S50101Z90 SW TACT
SW204 5S50101Z90 SW TACT
SW205 5S50101Z90 SW TACT
SW206 5S50101Z90 SW TACT
SW207 5S50101Z90 SW TACT
ZZ200 PTUNJAG233 PCB UNION AXIAL AS
A002 4859815360 PCB UNION
C996 CCZJ1H104Z C CERA
R901 85801050GY WIRE COPPER
R902 RD-AZ152J- R CARBON FILM
R903 RD-AZ432J- R CARBON FILM
R904 85801050GY WIRE COPPER
R905 RD-AZ152J- R CARBON FILM
R906 RD-AZ432J- R CARBON FILM
R907 RD-AZ113J- R CARBON FILM
DESCRIPTION
CIMAX-SP2
ST890BDR
74LVC573ADB
74LVC573ADB
74LVC245APW
TDA9886T
V58C2128164SBI5 128M TSOP
FDS4953 SO-8 -30V -5A REEL
MST96889LD
4P 27.000MHZ 50PPM (BMS-87
DLT-32C6LMBD
SAC3000 •'3.0MM (LFA3C0-W3
SAC3005 •'1.6MM (LFA3-107-
SV-PBF-304P(0.823)
S-3000
TSOP34838SJ
SPR-39MVW (DUAL)
HIPS BK
ABS GY
TT2 WAS 3X10 MFZN 3CR
20017WR-05A
20017WR-06A
DLT-32C6LMBD
DLT-32C6LMBD
DLT-32C6LMBD
DLT-32C6LMBD
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
THVV502GDA
DLT-32C6LMBD
246X197 D1B
50V F 0.1MF Z AXL(1608)
1/0.5 TIN COATING
1/6 1.5K OHM J
1/6 4.3K OHM J
1/0.5 TIN COATING
1/6 1.5K OHM J
1/6 4.3K OHM J
1/6 11K OHM J
