 Adjusting the Picture Size and Position

Use the lens shift dials, the adjustable tilt foot levers, the zoom lever or the focus ring to adjust the picture size and
position.
Adjusting the position of a projected image
[Lens shift]
Adjusting the throw angle (the height of an image)
[Tilt foot] *
Adjusting the left and right tilt of an image
[Tilt foot]
In the above drawings, cables are omitted for clarity.
NOTE*: Adjust the throw angle (the height of an image) when the image position is higher than the lens shift adjustable range.
