Rainbow1 IP Phone User Manual
C. Dialed call
1) Press key.
2) Press key and
key.
3) Press key and
4) Press key and
the LCD display will be indicated "List is Empty".

3.12 Default Password

Password is needed to access menu and web.
The default password for accessing menu is 123.
There are 2 modes to access web: User mode and Admin mode. All the parameters
can be visible at Admin mode while part of them can be visible at User mode.
 User Mode
Username：user
 Admin Mode：
Username：admin

3.13 Check the Phone's IP address

Press key, then the status of the phone will be displayed on the screen and you
will see the current IP address of the phone.

3.14 Dial Plan

Dial plan defines the rule of dial. The syntax of dial plan for Rainbow1 is closely
similar as the corresponding syntax specified by MGCP and MEGACO.
Dial plan is stipulated by the below configurable parameters:
 Interdigit Long Timer——refer to
 Interdigit Short Timer——refer to
description
 Dial Plan
Dial plan contains a series of digit sequences, separated by the '|' character. The
collection of sequences is enclosed in parentheses '(' and ')'.
Default: (*xx.|xxxxxxxxxxxx.)
When user dials a series of digits, Rainbow1 will response in below way:
• No candidate sequences matched, the number will be rejected and "call ended" will
be displayed on the screen. For instance, if the default dial plan only supports digits,
any '*' character or letters input will be rejected.
ATCOM TECHNOLOGY CO., LIMITED
key to select "Call History" and then press "Select" soft
key to select "Dialed Calls" and then press "OK" soft key.
key to browse the dialed call records. If there is no record,
no default Password
no default Password
Interdigit long timer
Interdigit short timer
www.atcom.cn
for more detail description
for more detail
