  • Page 1 PROFESSIONAL AUDIO SYSTEM TREX OPERATING MANUAL Ver. TREX-EN-1.1 LSS Advanced Speaker Systems Via On. Longo 53-89024 Polistena (RC) ITALY Tel (39) 966 9321299 – Fax (39) 966 933007 Email: info@lss.it - Internet: www.lss.it...
  • Page 2 Every precaution has been taken in the preparation of this manual. Nevertheless, LSS assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in this publication.
  • Page 3: Table Of Contents

    INTRODUCTION ............................4 SAFETY AND WARNING ..........................5 APPLICATION ..............................6 PHYSICAL DESCRIPTION ........................... 6 TECHNICAL SPECIFICATIONS ........................7 INSTALLATION AND WIRING ........................8 WEEE DIRECTIVE ............................11 TROUBLESHOOTING ..........................12 DIMENSIONS ..............................13 NOTES ................................14 Operating Manual ver. TREX-EN-1.1 |3...
  • Page 4: Introduction

    LSS produces professional audio products – the result of exceptional engineering and meticulous craftsmanship. This manual is intended for use with LSS loudspeaker. This includes: safety precautions; installation, set-up and operating instruction. Please read this manual plus any accompanying manual and follow all relevant precautions and instructions.
  • Page 5: Safety And Warning

    LSS loudspeakers can produce sound levels capable of causing permanent hearing damage from prolonged exposure. The higher the sound level, the less exposure needed to cause such damage CAUTION: This product is energized as long as it is connected to the AC.
  • Page 6: Application

    The TREX powering mode is only bi-amplified operation with external digital processor. The TREX is ideal for concert touring applications, the 13° per side trapezoidal angles match the 60° horizontal coverage pattern allowing the creation of tight packed clusters. The comprehensive system fly points mounting tracks allows safe suspended installations.
  • Page 7: Technical Specifications

    Birch Plywood of 18 mm [0.71 Enclosure material inches] Finish Texture poliuretanic black paint 6 Fly point Mounting Tracks,16 MECHANYCAL Suspension Points Mounting Suspension Powder coated perforated steel Grille with anti-dust foam Connectors Neutrik Speakon NL4 Operating Manual ver. TREX-EN-1.1 |7...
  • Page 8: Installation And Wiring

    TREX_________________________________________________________________________________ INSTALLATION AND WIRING TREX can be installed stand alone or in stack configuration, in most cases with SUBTREX subwoofer. It must be installed only in vertical position. In the bottom of the case there are two plastic skeeds used as feet to support the speaker.
  • Page 9 In the connection panel there are two Speakon NL4 connectors referred as ‘IN’ and ‘OUT’. IN is the input connector and must be connected to the amplifier, ‘OUT’ is a LINK OUT and can be connected to other systems. Operating Manual ver. TREX-EN-1.1 |9...
  • Page 10 HF. Internal connection are made as follow: Speakon Pinout Transducer connector TREX system operating mode is only Bi-Amp (LF 1- 1+; HF 2- 2+) and needs an external digital processor with custom setup provided by LSS. on request it is possible to ask setting parameter in order to use third part processor.
  • Page 11: Weee Directive

    Warning: If the product is used for business purposes, the following steps to delete it: contact your LSS dealer for information about the product recall. Might be charged for the costs of collection and recycling. Small products (and amounts) might be taken back by your local collection facilities.
  • Page 12: Troubleshooting

    Poor system hissing, grounding or ground Check and correct the system grounding, as required. humming loop If these suggestions do not solve your problem, contact your nearest LSS dealer or LSS distributor. 12| Operating Manual ver. TREX-EN-1.1...
  • Page 13: Dimensions

    ______________________________________________________________________________ DIMENSIONS SIDE FRONT REAR 70cm 60cm 36cm BOTTOM Operating Manual ver. TREX-EN-1.1 |13...
  • Page 14: Notes

    TREX_________________________________________________________________________________ NOTES 14| Operating Manual ver. TREX-EN-1.1...
  • Page 15 ______________________________________________________________________________ CONTACT INFORMATION: LSS Advanced Speaker Systems Via On. Longo 53 89024 Polistena (RC) ITALY Tel (39) 966 9321299 – Fax (39) 966 933007 Email: info@lss.it - Internet: www.lss.it Operating Manual ver. TREX-EN-1.1 |15...
