Appendix B Information Commands Results

The following shows some of the output from diagnostic commands available through the CLI or the
Advanced page of the ExpressNAV interface.
DriveInfo [sled ID] [drive ID]
Displays information about all disk drives or detailed information about a specific disk drive. Detailed
information about an individual drive is obtained by supplying a drive identifier. VD ID is the Virtual Disk ID
Driveinfo for a JBOD configuration, verbose result
=========== Drive 1 ========== ========= Drive 2 ==============
Sled Capacity Errors TYPE ...VDID
=== ====== ..===== ===== =====
1 76292MB 0 JBOD 1
2 76292MB 0 JBOD 2
3 76292MB 0 JBOD 3
4 76292MB 0 JBOD 4
5 76292MB 0 JBOD 5
6 76292MB 0 JBOD 6
7 76292MB 0 JBOD 7
8 76292MB 0 JBOD 8
9 76292MB 0 JBOD 9
10 76292MB 0 JBOD 10
11 76292MB 0 JBOD 11
12 73307MB 0 JBOD 12
DriveInfo 7 2
JBOD VDID 19
Sled = 7, Drive = 2
Drive Model: Maxtor 98196H8
S/N: V80D15GC F/W Rev: ZAH814Y0 ATA Rev: 007e
Capacity: 76292 MB (09502790 blocks)
PIO: 03 MDMA: 07 UDMA: 07 QD: 00 CMDSet: 7c69 4309
Operations Blocks
Read 00000000 00000000
Write 00000000 00000000
Errors 00000000
DriveInfo RAID0 6
========= Drive 1 =========== ========= Drive 2 ==========
Sled Capacity Errors TYPE VDID Capacity Errors TYPE VDID
=== ======= ==== ==== ====== ======= ==== ===== =====
1 76292MB 0 RAID0 26
2 76292MB 0 RAID0 26
3 76292MB 0 RAID0 27
4 76292MB 0 RAID0 27
5 76292MB 0 RAID0 28
6 76292MB 0 RAID0 28
7 76292MB 0 RAID0 29
8 76292MB 0 RAID0 29
9 76292MB 0 RAID0 30
10 76292MB 0 RAID0 30
11 76292MB 0 RAID0 31
12 73307MB 0 R]AID0 31
Capacity Errors TYPE VDID
====== ===== =====. =====
76292MB 0 JBOD 13
76292MB 0 JBOD 14
76292MB 0 JBOD 15
76292MB 0 JBOD 16
76292MB 0 JBOD 17
76292MB 0 JBOD 18
76292MB 0 JBOD 19
76292MB 0 JBOD 20
76292MB 0 JBOD 21
76292MB 0 JBOD 22
76292MB 0 JBOD 23
73307MB 0 JBOD 24
76292MB 0 RAID0 26
76292MB 0 RAID0 26
76292MB 0 RAID0 27
76292MB 0 RAID0 27
76292MB 0 RAID0 28
76292MB 0 RAID0 28
76292MB 0 RAID0 29
76292MB 0 RAID0 29
76292MB 0 RAID0 30
76292MB 0 RAID0 30
76292MB 0 RAID0 31
73307MB 0 RAID0 31
