COMMAND DESCRIPTION
$ 0 9
[Name] Horizontal tab
[Format] ASCII
Hex
Decimal
[Description] Moves the print position to the next horizontal tab position.
[Notes] • Ignored unless the next horizontal tab position has been set.
• If the command is received when the printing position is at the right margin, the printer
executes print buffer full printing and horizontal tab processing from the beginning of the
next line.
• Horizontal tab positions are set using ESC D.
[Default]
[Reference] $1B $44
[Example]
$ 0 A
[Name] Print and line feed
[Format] ASCII
Hex
Decimal
[Description] Prints the data in the buffer and feeds one line based on the current line spacing.
[Notes] • Sets the print position to the beginning of the line.
• If the buffer is empty, the printing feeds of (character height + spacing gap) dot.
[Default]
[Reference] $1B $32, $1B $33, $0D
[Example]
$ 0 D
[Name] Print and carriage return
[Format] ASCII
Hex
Decimal
[Description] When autofeed is "CR enabled", this command functions in the same way as $0A,
otherwise it is disregarded.
[Notes] • Sets the print position to the beginning of the line.
[Default] See "Autofeed in setup" parameter.
[Reference] $0A
[Example]
$ 1 0 $ 0 4 n
[Name] Real-time status transmission
[Format] ASCII
Hex
Decimal
1 ≤ n ≤ 4, n = 20
[Range]
[Description] Transmits the selected printer status specified by n in real time according to the following
HT
09
9
LF
0A
10
CR
0D
13
DLE EOT
10 04
16 4
Commands Reference -
n
n
n
