TYPICAL PRODUCT PARAMETERS

TYPICAL PRODUCT PARAMETERS
Electrical Requirements:
Rated Current Input:
Sound Level:
Altitude:
*Oxygen Output
Concentration Levels:
Maximum Outlet Pressure:
Flow Range:
Low Flow Alarm:
Average Power
Consumption:
Pressure Relief Mechanism Operational at:
Change in maximum recommended flow
when back pressure of 7kPa is applied:
Filters:
Safety System:
Width:
Height:
Depth:
Weight:
Shipping Weight:
Operating Ambient Temperature:
Exhaust:
Oxygen Output:
Cabinet:
Perfecto V
™
2
120 VAC ± 10% (132 VAC/108 VAC), 60 Hz
3 A
43 ± 2 dBA Average
Perfecto V Model: Up to 8,000 ft. (2438 meters) above sea
2
level without degradation of concentration levels. From 8,000 ft.
(2438 meters) to 13,129 ft. (4000 meters) below 90% efficiency.
Unit while filling a HomeFill System: Up to 6,000 ft (1828
meters) above sea level without degradation of concentration
levels. From 6,000 ft (1828 meters) to 13,129 ft (4000 meters)
below 90% efficiency.
87% to 95.6% at 0.5 to 5 L/min
5 psi ± 0.5 psi. (34.5 kPa ± 3.45 kPa.)
0.5 to 5 L/min
For flowrates less than 1 L/min, we recommend the use of the
Invacare Pediatric Flowmeter IRCPF16 Accessory.
0 L/min to 0.5 L/min
Rapid Audible Alarm Beeping (No Accessories Connected).
325 W
35 psi ± 5 psi (241 kPa ± 34.5 kPa)
0.7 L/min
Cabinet, Outlet HEPA and Compressor Inlet
Current overload or line surge shutdown. High temperature
compressor shutdown. High Pressure Alarm with compressor
shutdown. Low Pressure Alarm with compressor shutdown. Bat-
tery Free Power Loss Alarm. SensO
Model) Low Flow Alarm.
15 in. ± 3/8 in (38.1 cm ± 1 cm)
23 in. ± 3/8 in (58.4 cm ± 1 cm)
12 in. ± 3/8 in (30.5 cm ± 1 cm)
40 lbs ± 2 lbs (18.1 kg ± 1 kg)
45 lbs ± 2 lbs (20.4 kg ± 1 kg)
50°F - 95°F (10°C - 35°C) at 20-60% relative humidity
Less than Ambient + 35°F (+19°C)
Less than Ambient + 6°F (+3°C)
Impact Resistant flame-retardant plastic cabinet that conforms to
UL94 V-0.
8
Oxygen System (SensO
2 2
Part No 1164934
