Using the BayStack 350 10/100/1000 Series Switch
Table 3-20. IGMP Configuration Screen Fields (continued)
Field
Query Time
Set Router Ports
Static Router Ports
3-50
Description
Allows a user to control the number of IGMP messages allowed on the subnet by
varying the Query Interval (the Query Interval is the interval between general
queries sent by the multicast router).
This field affects only the VLAN specified in the screen's VLAN field (for example, if
you change the Query Time value field on the VLAN specified in the screen's VLAN
field, other VLANs are not affected).
Default Value: 125 seconds
Range: 1 to 512 seconds
Sets the IGMP Snooping feature to operate according to the IGMPv1 or IGMPv2
standard (see RFC 2236).
This field affects all VLANs (for example, if you change the value of the Set Router
Ports field on the VLAN specified in the screen's VLAN field, ALL VLANs are
affected).
Default Value: Version 1
Range: Version 1, Version 2
Allows a user to assign switch ports to any port that has a path to a multicast router.
These configured ports do not filter any IP Multicast traffic. The Static Router Ports
fields are displayed in six-port groups (for example, 1-6, 7-12, 13-18). The number
of ports displayed depends on the switch model or type of optional MDA that is
installed in the Uplink Module slot.
This field affects all VLANs (for example, if you assign a port as a static router port in
this screen, the port becomes a static router port for the VLAN specified in the
screen's VLAN field, and also for any other VLAN where this port is a member).
Default Value: -
Range: -, X
