8. Accessories

8.1. Anti-tip protection /

anti-tip rollers
Always use the anti-tip protection as a pair.
To fit the anti-tip protection, please proceed as follows:
• Pull the rubber profiles off the tip assist.
• Push the round profile for the anti-tip protection onto
the side frame tube at the bottom.
• Fix the anti-tip protection with the M6x35 bolt and M6
self-locking nut in the hole in the frame provided (Fig.
28).
The anti-tip protection can also be used to assist tipping
when the anti-tip rollers are raised.

8.2. Safety belt

If required, a safety belt is available as an accessory. This
is fitted onto the side frame of the wheelchair with the
side part either temporarily removed or swung away (Fig.
29). Take the open end of the belt once around the side
frame tube and then fix it with the belt buckle.
You also use the belt buckle to adjust the length of the
belt. Adjust the belt length so that the belt is tight, but
does not apply pressure.
Bischoff & Bischoff GmbH • 27.08.2012
Pyro start
plus+
Fig. 28
Fig. 29
25
