7.4. Seat

7.4.1 Seat height
You can adapt the seat height to your individual needs in just
a few steps.
1. Height of the driving wheel
There are 4 positions to allow the seat height to be adap-
ted to the user's requirements. For the lowest one, the
castor bushing must be turned and fitted on the other
side.
Fig. 17
Driving wheel and steering wheel must be in the same
position in each case. TOP – MIDDLE – BOTTOM
• Take the driving wheels off using the quick-release
axles.
• Loosen the screws on the adapter (Allen key, SW 4 and
ring spanner SW 10) and pull them out completely.
• Place the adapter at the required seat height.
• Insert the screws into the adapter again and tighten up
the screws again.
Place the steering wheel in the same hole positi-
on as the drive axle. This is the only way to ensu-
re the directional stability of the wheelchair
