Copyright This manual is the intellectual property of ACTi and is protected by copyright. All rights are reserved. No part of this document maybe reproduced or transmitted for any purpose by any means including electronic or mechanical without the official written permission from ACTi.
typographical or technical errors and reserve the right to make changes to the product and manuals without prior notice. FCC/CE Regulation NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
1.2 FEATURES AND BENEFITS This 4-CH Video Server is a cutting-edge digital video transmission device. It can compress and transmit real time images with outstanding images quality at reasonable bandwidth through a standard TCP/IP network. That’s because it is Ethernet (LAN and WAN) ready and has the powerful ARM9 SoC and the MPEG-4 compression ASIC inside.
Page 7
(Point-to-Point over Ethernet) which has excellent transmission speed and enables the video server to connect to an ADSL or a cable modem. DDNS Supported The video server supports DDNS (Dynamic Domain Name Server), users can set the video server at a virtual domain name (such as cam1.Taipei.xxx) at dynamic IP.
1.3 Safety instructions Don’t use the power supply with other voltages This device is likely to be damaged or damage other equipments / personnel, if you use a power supply with different voltage than the one included with this device. All warranty of this product will be voided in the situations above.
Page 9
operating Instructions in this manual. Adjust only those controls that are covered by the instruction manual as an improper adjustment . Other controls may result in damage and will often require extensive work by a qualified technician to restore the video product to its normal operation.
1.4 PARTs’ NAMES and LOCATIONS ■ Front Panel Red LED LED indicating Power or H/W Reset Function Yellow LED LED indicating when RS-485 is active Green LED LED indicating when LAN/WAN is active Reset Button Get back to default value while forgetting Login Name & Password Procedure Switch off the video server by disconnecting the power cable...
Page 11
Non Connector Ground Pin Digital Input 1 Non Connector Ground Pin Terminal Blocks Pin 7~12 DESCRIPTION NAME RS-485 RS-232 Non Connector Non Connector Power Input (DC +12V) Ground Pin of Power Input WAN port The video server connects to the WAN (wide area network) via a standard RJ45 connector.
■ Rear Panel Cam1 Analog Video Input of Composite Signal with BNC Connector Cam2 Analog Video Input of Composite Signal with BNC Connector Cam3 Analog Video Input of Composite Signal with BNC Connector Cam4 Analog Video Input of Composite Signal with BNC Connector Monitor Out Analog Video Ouput of Composite Signal with BNC Connector...
2.2 Basic Connections Follow the procedures below to connect the video server to the respective apparatuses. Please refer to page 1-6 for more details. Connect an analog video source (eg. CCD Camera) to the video server’s CAM1 ~ CAM4(BNC connector). Connect an analog monitor to the video server’s Monitor-Out (BNC connector) Connect the video server’s LAN port to an Ethernet hub (RJ45...
